Description
With high-performance wired and wireless connectivity and dedicated user touchscreen. Ideal for high-volume, secure batch scanning for collaborative and complex workflows.
The metadata function can also read barcodes or specific strings of text to easily facilitate the separation and file naming of documents.
The document separation functionality also automatically detects and removes any scanned blank pages, thus reducing file sizes and document preparation time.
Key Features
- Scan up to 60 pages per minute
- 2-sided scan up to 60 pages per minute
- 100 sheet Automatic Document Feeder (ADF)
- 5GHz Wi-Fi and wired connectivity
- SuperSpeed USB3.
- Scan directly to USB host
Reasons To Buy
Brother ScanEssentials
Our ScanEssentials software provides you with additional features which you can tailor to your business. For added security, you can set up passwords and protect your workflows, with the option to save your documents in a variety of formats.The metadata function can also read barcodes or specific strings of text to easily facilitate the separation and file naming of documents.
Fast and reliable
With an in-built ultrasonic multifeed to eliminate misfeeds, the ADS-4900W has the largest sheet ADF capacity (100 sheets) and is the fastest in the range, scanning up to 60 pages per minute, or one every second. The separation switch enables very thick and thin documents, plastic cards and crumpled paper to smoothly feed through with ease.Advanced image capture and processing
Effortless and impressive image capture and processing - from easily referencing and locating scanned pages with the digital imprinter, to optimising image quality through the automatic vertical streaks and moiré reduction tools.The document separation functionality also automatically detects and removes any scanned blank pages, thus reducing file sizes and document preparation time.
Advanced connectivity
With 5GHz wireless connectivity, network, USB3.0 and USB host, you can securely scan documents and share with colleagues.Simple and intuitive
Set up a dedicated user interface with one-touch scanning and the ability to add up to 56 shortcuts to frequently used destinations. You can also use an optional external cardreader to make the scanning process even easier. Just tap the card and add your documents into the ADF to automatically and securely capture the information on the page.Industry recognised software
Increase post-scanning productivity with industry recognised software including Kofax and Newsoft, available as standard with device.Description
For uninterrupted high-volume, batch scanning. With the simplicity of one-touch scanning, securely capture, send and receive business documents with ease, whether they're at home or in the office. Large intuitive 10.9cm touchscreen with 56 configurable shortcuts Personalised multi-user experience Secure workgroup sharing Advanced image processing and batch scanning Features Auto Start Scan, Ultrasonic Multifeed Sensor, Separation Switch, Scan Preview, CIS Cleaning Alarm Includes Brother ScanEssentials software Driver compatibility with TWAIN (WIN and macOS), WIA, ISIS, Linux SANESpecifications
| Scanning | |
|---|---|
| Output greyscale depth | 8 bit |
| Maximum scan size | 8.5 x 14" (215.9 x 355.6 mm) |
| Optical scanning resolution | 600 x 600 DPI |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 48 bit |
| Output colour depth | 24 bit |
| Greyscale levels | 256 |
| ADF scan speed (b/w, A4) | 60 ppm |
| ADF scan speed (colour, A4) | 60 ppm |
| Duplex ADF scan speed (b/w, A4) | 120 ipm |
| Duplex ADF scan speed (colour, A4) | 120 ipm |
| Sensor type | Dual CIS |
| Light source | LED |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 9000 pages |
| Scan to | E-mail Server, FTP, HTTP, PC, SMB |
| Design | |
| Built-in display | Yes |
| Touchscreen | Yes |
| Scanner type | ADF + Sheet-fed scaner |
| Display diagonal | 4.3" |
| Display | LCD |
| Product colour | Black, White |
| Colour display | Yes |
| Control type | Touch |
| Performance | |
| Sensor type | Dual CIS |
| Light source | LED |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 9000 pages |
| Scan to | E-mail Server, FTP, HTTP, PC, SMB |
| Scan drivers | ISIS, SANE, TWAIN, WIA |
| Scanning noise level | 62 dB |
| Maximum duty cycle | 180000 pages per month |
| Ultrasonic sensor | Yes |
| Input capacity | |
| Auto document feeder (ADF) input capacity | 100 sheets |
| Paper handling | |
| Maximum scan width | 8.5" (21.6 cm) |
| Maximum scan length | 196.9" (5 m) |
| Maximum ISO A-series paper size | A4 |
| Media thickness (min) | 0.00315" (0.0800 mm) |
| Scanning media types supported | Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Auto Document Feeder (ADF) media weight | 25 - 413 g/m² |
| Long-paper mode | Yes |
| Card thickness (max) | 0.0520" (1.32 mm) |
| Paper tray media weight | 25 - 413 g/m² |
| Ports & interfaces | |
| USB port | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Network | |
| Supported network protocols (IPv6) | RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6 |
| Security algorithms | AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Supported network protocols (IPv4) | DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP |
| IPv6 support | Yes |
| Software | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Scan drivers | ISIS, SANE, TWAIN, WIA |
| Sound emission | |
| Scanning noise level | 62 dB |
| Power | |
| Auto power off | Yes |
| Power consumption (typical) | 34 W |
| Power consumption (standby) | 7.7 W |
| Power consumption (off) | 0.1 W |
| Power supply type | AC |
| Power consumption (sleep) | 1.7 W |
| Output voltage | 24 V |
| Output current | 1.9 A |
| Sleep mode | Yes |
| Weight & dimensions | |
| Width | 11.3" (288 mm) |
| Depth | 13.1" (334 mm) |
| Height | 15.5" (393 mm) |
| Weight | 8.4 lbs (3.81 kg) |
| Package depth | 11.3" (288 mm) |
| Package weight | 10.1 lbs (4.6 kg) |
| Package width | 15.5" (393 mm) |
| Package height | 13.1" (334 mm) |
| Packaging data | |
| Package depth | 11.3" (288 mm) |
| Package weight | 10.1 lbs (4.6 kg) |
| Package width | 15.5" (393 mm) |
| Package height | 13.1" (334 mm) |
| Quantity per pack | 1 pc(s) |
| Products per pallet | 40 pc(s) |
| Packaging content | |
| Cables included | AC, USB |
| Technical details | |
| Maximum scan width | 8.5" (21.6 cm) |
| Pallet gross height | 7.13" (18.1 cm) |
| Media thickness (min) | 0.00315" (0.0800 mm) |
| Security algorithms | AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3 |
| Scanner type | ADF + Sheet-fed scaner |
| Maximum duty cycle | 180000 pages per month |
| Country of origin | China |
| Product colour | Black, White |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Supported network protocols (IPv6) | RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6 |
| Master (outer) cases per pallet layer | 8 pc(s) |
| Harmonized System (HS) code | 84716070 |
| Pallet type | 800 x 1200 mm |
| Display | |
| Touchscreen | Yes |
| Display diagonal | 4.3" |
| Display | LCD |
| Security | |
| Cable lock slot | Yes |
| Features | |
| Country of origin | China |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Certificates | |
| Certification | GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0 |
| Other features | |
| Cable lock slot | Yes |
| Certification | GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0 |
| Spare part retention | 5 year(s) |
| Pallet gross weight | 410.1 lbs (186 kg) |
| Security algorithms | AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Scanner type | ADF + Sheet-fed scaner |
| Country of origin | China |
| Products per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Pallet gross weight | 410.1 lbs (186 kg) |
| Country of origin | China |
| Products per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross height | 7.13" (18.1 cm) |
| Master (outer) cases per pallet layer | 8 pc(s) |
| Harmonized System (HS) code | 84716070 |
