Description
With high-speed wired and wireless connectivity and dedicated user touchscreen. Ideal for complex workflows and sharing documents with colleagues.
The metadata function can also read barcodes or specific strings of text to easily facilitate the separation and file naming of documents.
The document separation functionality also automatically detects and removes any scanned blank pages, thus reducing file sizes and document preparation time.
Key Features
- Scan up to 40 pages per minute
- 2-sided scan up to 40 pages per minute
- 80 sheet Automatic Document Feeder (ADF)
- Wireless and wired connectivity
- SuperSpeed USB3.
- Scan directly to USB host
Reasons To Buy
Simple and intuitive
Set up a dedicated user interface with one-touch scanning and the ability to add up to 56 shortcuts to frequently used destinations. You can also use an optional external cardreader to make the scanning process even easier. Just tap the card and add your documents into the ADF to automatically and securely capture the information on the page.Brother ScanEssentials
Our ScanEssentials software provides you with additional features which you can tailor to your business. For added security, you can set up passwords and protect your workflows, with the option to save your documents in a variety of formats.The metadata function can also read barcodes or specific strings of text to easily facilitate the separation and file naming of documents.
Advanced image capture and processing
Effortless and impressive image capture and processing - from easily referencing and locating scanned pages with the digital imprinter, to optimising image quality through the automatic vertical streaks and moiré reduction tools.The document separation functionality also automatically detects and removes any scanned blank pages, thus reducing file sizes and document preparation time.
Advanced connectivity
With USB3.0, USB host, network and wireless connectivity, you can securely scan documents and share with colleagues.Fast and reliable
With an in-built ultrasonic multifeed to eliminate misfeeds, the ADS-4700W has a large 80 sheet ADF capacity and rapidly scans up to 40 pages per minute. The separation switch enables very thick and thin documents, plastic cards and crumpled paper to smoothly feed through with ease.Industry recognised software
Increase post-scanning productivity with industry recognised software including Kofax and Newsoft, available as standard with device.Description
Designed to enable businesses to simplify complex workflow or operational processes. Securely capture your documents to easily share and collaborate with colleagues whether they're at home or in the office. Large intuitive 10.9cm touchscreen with 56 configurable shortcuts Personalised multi-user experience Secure workgroup sharing Advanced image processing and batch scanning Features Auto Start scan, ultrasonic multifeed sensor, Separation Switch, Scan Preview, CIS Cleaning Alarm Includes Brother ScanEssentials software Driver compatibility with TWAIN (WIN and macOS), WIA, ISIS, Linux SANESpecifications
| Scanning | |
|---|---|
| Output greyscale depth | 8 bit |
| Maximum scan size | 14 x 8.5" (355.6 x 215.9 mm) |
| Optical scanning resolution | 600 x 600 DPI |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 48 bit |
| Output colour depth | 24 bit |
| Greyscale levels | 256 |
| ADF scan speed (b/w, A4) | 40 ppm |
| ADF scan speed (colour, A4) | 40 ppm |
| Duplex ADF scan speed (b/w, A4) | 80 ipm |
| Duplex ADF scan speed (colour, A4) | 80 ipm |
| Sensor type | Dual CIS |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 6000 pages |
| Scan to | PC |
| Design | |
| Built-in display | Yes |
| Touchscreen | Yes |
| Scanner type | ADF + Sheet-fed scaner |
| Display diagonal | 4.3" |
| Display | LCD |
| Product colour | Black, White |
| Colour display | Yes |
| Control type | Buttons |
| Performance | |
| Sensor type | Dual CIS |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 6000 pages |
| Scan to | PC |
| Scan drivers | ISIS, TWAIN, WIA |
| Supported network protocols | DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP, RA, ICMPv6 |
| Scanning noise level | 59 dB |
| Maximum duty cycle | 120000 pages per month |
| Internal memory | 512 MB |
| Ultrasonic sensor | Yes |
| Input capacity | |
| Auto document feeder (ADF) input capacity | 80 sheets |
| Paper handling | |
| Maximum scan width | 8.5" (21.6 cm) |
| Maximum scan length | 14" (35.6 cm) |
| Maximum ISO A-series paper size | A4 |
| Media thickness (min) | 0.00315" (0.0800 mm) |
| Scanning media types supported | Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Legal | Yes |
| Long-paper mode | Yes |
| Card thickness (max) | 0.0520" (1.32 mm) |
| Paper tray media weight | 40 - 200 g/m² |
| Ports & interfaces | |
| USB port | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Network | |
| Security algorithms | WEP, WPA-PSK, WPA2-PSK, WPA3 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g |
| Supported network protocols | DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP, RA, ICMPv6 |
| IPv6 support | Yes |
| Software | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 x64, Windows 8.1, Windows 8.1 x64 |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Scan drivers | ISIS, TWAIN, WIA |
| Sound emission | |
| Scanning noise level | 59 dB |
| Power | |
| Auto power off | Yes |
| Power consumption (typical) | 26 W |
| Power consumption (standby) | 8.6 W |
| Power consumption (off) | 0.1 W |
| Input voltage | 100-240 V |
| Power supply type | AC |
| Power consumption (PowerSave) | 1.7 W |
| Power consumption (sleep) | 1.7 W |
| Output voltage | 24 V |
| Output current | 1.9 A |
| AC input frequency | 50 - 60 Hz |
| Sleep mode | Yes |
| Weight & dimensions | |
| Width | 9.57" (243 mm) |
| Depth | 12.6" (320 mm) |
| Height | 15.4" (391 mm) |
| Weight | 7.12 lbs (3.23 kg) |
| Package depth | 9.57" (243 mm) |
| Package weight | 8.55 lbs (3.88 kg) |
| Package width | 15.4" (391 mm) |
| Package height | 12.6" (320 mm) |
| Packaging data | |
| Package depth | 9.57" (243 mm) |
| Package weight | 8.55 lbs (3.88 kg) |
| Package width | 15.4" (391 mm) |
| Package height | 12.6" (320 mm) |
| Quantity per pack | 1 pc(s) |
| Products per pallet | 40 pc(s) |
| Technical details | |
| Maximum scan width | 8.5" (21.6 cm) |
| Pallet gross height | 6.89" (17.5 cm) |
| Media thickness (min) | 0.00315" (0.0800 mm) |
| Security algorithms | WEP, WPA-PSK, WPA2-PSK, WPA3 |
| Scanner type | ADF + Sheet-fed scaner |
| Maximum duty cycle | 120000 pages per month |
| Country of origin | China |
| Product colour | Black, White |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Master (outer) cases per pallet layer | 8 pc(s) |
| Harmonized System (HS) code | 84716070 |
| Pallet type | 800 x 1200 mm |
| Memory | |
| Internal memory | 512 MB |
| Display | |
| Touchscreen | Yes |
| Display diagonal | 4.3" |
| Display | LCD |
| Media formats | |
| Legal | Yes |
| Features | |
| Country of origin | China |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 x64, Windows 8.1, Windows 8.1 x64 |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Certificates | |
| Certification | GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0 |
| Other features | |
| Certification | GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0 |
| Spare part retention | 5 year(s) |
| Pallet gross weight | 375.7 lbs (170.4 kg) |
| Security algorithms | WEP, WPA-PSK, WPA2-PSK, WPA3 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g |
| Scanner type | ADF + Sheet-fed scaner |
| Country of origin | China |
| Products per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Pallet gross weight | 375.7 lbs (170.4 kg) |
| Country of origin | China |
| Products per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross height | 6.89" (17.5 cm) |
| Master (outer) cases per pallet layer | 8 pc(s) |
| Harmonized System (HS) code | 84716070 |
