Product Description
Kingston’s UV500 SSD dramatically improves your system’s responsiveness with incredible boot, loading, and transfer times compared to mechanical hard drives. It uses a Marvell 88SS1074 controller and 3D NAND Flash to power through daily tasks and improve productivity. UV500 also provides end-to-end data protection using 256-bit AES Hardware-based encryption and support for TCG Opal 2.0 security management solutions. The UV500’s available in multiple capacities from 120GB–960GB giving you options to meet your system’s needs.
Technical Details
|
Form factor
|
M.2 2280/mSATA
|
|
Interface
|
SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s)
|
|
Capacities1
|
120GB, 240GB, 480GB, 960GB, 1.92TB
|
|
Controller
|
Marvell 88SS1074 Controller
|
|
NAND
|
3D TLC
|
|
Encryption
|
Encryption Support (AES 256-bit)
|
|
Sequential Read/Write2
|
120GB — up to 520/320MB/s
240GB — up to 520/500MB/s
480GB — up to 520/500MB/s
960GB — up to 520/500MB/s
1.92TB — up to 520/500MB/s
|
|
Maximum 4K Read/Write2
|
120GB — up to 79,000/18,000 IOPS
240GB — up to 79,000/25,000 IOPS
480GB — up to 79,000/35,000 IOPS
960GB — up to 79,000/45,000 IOPS
1.92TB — up to 79,000/50,000 IOPS
|
|
Power Consumption
|
0.195W Idle / 0.5W Avg / 1.17W (MAX) Read / 2.32 W (MAX) Write
|
|
Dimensions
|
100.1mm x 69.85mm x 7mm (2.5”)
80mm x 22mm x 3.5mm (M.2)
50.8mm x 29.85mm x 4.85mm (mSATA)
|
|
Operating temperature
|
0°C~70°C
|
|
Storage temperature
|
-40°C~85°C
|
|
Weight
|
120GB — 480GB — 41g (2.5”)
960GB — 57g (2.5”)
1.92TB — 52g (2.5”)
120GB — 6.6g (M.2)
240GB — 6.7g (M.2)
480GB — 7.7g (M.2)
960GB — 7.8g (M.2)
120GB — 6.2g (mSATA)
240GB — 480GB — 6.7g (mSATA)
|
|
Vibration operating
|
2.17G Peak (7–800Hz)
|
|
Vibration non-operating
|
20G Peak (10–2000Hz)
|
|
Life expectancy
|
1 million hours MTBF
|
|
Warranty/support3
|
Limited 5-year warranty with free technical support
|
|
Total Bytes Written (TBW)4
|
120GB — 60TB
240GB — 100TB
480GB — 200TB
960GB — 480TB
1.92TB — 800TB
|
Product Information
|
Brand
|
Kingston
|
|
Series
|
Kingston UV500
|
|
Item model number
|
SUV500MS/480G
|
|
Hardware Platform
|
Laptop
|
|
Item Weight
|
0.704 ounces
|
|
Product Dimensions
|
1.52 x 0.14 x 0.9 inches
|
|
Item Dimensions LxWxH
|
1.52 x 0.14 x 0.9 inches
|
|
Computer Memory Type
|
DDR3L-1600 SDRAM
|
|
Flash Memory Size
|
480
|
|
Manufacturer
|
Kingston Digital, Inc.
|
|
Is Discontinued By Manufacturer
|
No
|
|
Date First Available
|
April 24, 2018
|
