APC Basic Rack PDU, 0U, Beige, NEMA 5-15P, 14 x NEMA 5-15R, 141.7" (3.6 m), 120 V
Description
APC Basic Rack PDU. Rack capacity: 0U, Product color: Beige. Input connection type: NEMA 5-15P, Output connections: 14 x NEMA 5-15R. Cable length: 141.7" (3.6 m). Nominal input voltage: 120 V, AC input frequency: 50 - 60 Hz, Nominal output voltage: 120 V. Certification: cUL/CSA/ETI/UL 1363
Specifications
| Design |
|---|
| Product colour |
Beige |
| Certification |
cUL/CSA/ETI/UL 1363 |
| Rack capacity |
0U |
| Ports & interfaces |
|---|
| Output connections |
14 x NEMA 5-15R |
| Input connection type |
NEMA 5-15P |
| Features |
|---|
| Cable length |
141.7" (3.6 m) |
| Certification |
cUL/CSA/ETI/UL 1363 |
| Ergonomics |
|---|
| Cable length |
141.7" (3.6 m) |
| Power |
|---|
| Nominal input voltage |
120 V |
| Nominal output voltage |
120 V |
| Output voltage |
120 V |
| Maximum total current draw per phase |
15 A |
| Load capacity |
1800 VA |
| AC input frequency |
50 - 60 Hz |
| Certificates |
|---|
| Certification |
cUL/CSA/ETI/UL 1363 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-25 - 65 °C |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 95% |
| Weight & dimensions |
|---|
| Weight |
4.81 lbs (2.18 kg) |
| Weight (imperial) |
4.8 lbs |
| Width |
1.73" (44 mm) |
| Depth |
1.73" (44 mm) |
| Height |
24" (610 mm) |
| Package width |
7.01" (178 mm) |
| Package depth |
5.98" (152 mm) |
| Package height |
25.5" (648 mm) |
| Package weight |
6.42 lbs (2.91 kg) |
| Packaging data |
|---|
| Package width |
7.01" (178 mm) |
| Package depth |
5.98" (152 mm) |
| Package height |
25.5" (648 mm) |
| Package weight |
6.42 lbs (2.91 kg) |
| Technical details |
|---|
| Total carbon footprint (kg of CO2e) |
55.22 |
| Logistics data |
|---|
| Total carbon footprint (kg of CO2e) |
55.22 |
