Swivel/Tilt Wall Mount for 26" to 55" TVs and Monitors
Key Features
- Fits most flat-panel displays from 26 to 55 in.
- One-touch adjustment for comfortable viewing
- 120° swivel, -15° to +15° tilt and -5° to +5° screen adjustment
- Supports up to 110 lbs (49.9 kgs)
Description
The VESA-compliant DWM2655M Swivel/Tilt Wall Mount allows you to mount your flat-panel television, monitor or other display on the wall. Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants, it fits most flat-panel displays from 26 to 55 inches.
Adjust the display’s viewing angle to fit your environment and comfort level. A 120° swivel, -15° to +15° tilt and -5° to +5° screen level adjustment capability minimizes glare and provides comfortable viewing from multiple angles.
Durable all-metal frame with scratch-resistant powder-coated finish supports up to 110 lbs (49.9 kgs). Mounting hardware included. Built-in bubble level allows accurate display leveling. Conforms to VESA-compliant displays with any of the following mounting hole patterns: 100 x 100 mm, 100 x 200 mm, 200 x 100 mm, 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm and 400 x 400 mm
Specifications
| Mounting |
|---|
| Mounting type |
Wall |
| Minimum screen size |
26" |
| Panel mounting interface |
200 x 200,300 x 300,400 x 200,400 x 400 |
| Number of displays supported |
1 |
| Minimum VESA mount |
7.87 x 7.87" (200 x 200 mm) |
| Maximum VESA mount |
15.7 x 15.7" (400 x 400 mm) |
| Maximum screen size |
55" |
| Maximum weight capacity |
109.8 lbs (49.8 kg) |
| Ergonomics |
|---|
| Cable management |
No |
| Tilt angle range |
-15 - 15° |
| Swivel angle |
120° |
| Technical details |
|---|
| Cable management |
No |
| Number of displays supported |
1 |
| Product colour |
Black |
| Mounting type |
Wall |
| Country of origin |
China |
| Compliance certificates |
RoHS |
| Design |
|---|
| Cable management |
No |
| Product colour |
Black |
| Packaging content |
|---|
| Mounting kit |
Yes |
| Manual |
Yes |
| Weight & dimensions |
|---|
| Width |
16.9" (428 mm) |
| Depth |
16.9" (428 mm) |
| Height |
7.67" (194.8 mm) |
| Weight |
17.7 lbs (8.02 kg) |
| Packaging data |
|---|
| Package width |
21.9" (556.3 mm) |
| Package depth |
9.2" (233.7 mm) |
| Package height |
4.6" (116.8 mm) |
| Package weight |
19.1 lbs (8.65 kg) |
| Mounting kit |
Yes |
| Manual |
Yes |
| Logistics data |
|---|
| Master (outer) case width |
22.4" (569 mm) |
| Master (outer) case length |
10" (254 mm) |
| Master (outer) case height |
9.8" (248.9 mm) |
| Master (outer) case gross weight |
38.4 lbs (17.4 kg) |
| Products per master (outer) case |
2 pc(s) |
| Master (outer) case GTIN (EAN/UPC) |
10037332183634 |
| Harmonized System (HS) code |
85299097 |
| Other features |
|---|
| Mounting type |
Wall |
| Country of origin |
China |
