Intel/AMD, 2 x 3DHP / Aluminum Fins, 2x 120 mm, 0-2050 RPM / 0-1850 RPM, 107.2 m³/h / 85.8 m³/h, 2.69 mmH₂O / 1.77 mmH2O, PWM, 12 VDC, 133 x 114 x 161 mm, Black
Key Features
- Cooler Master Proprietary 3DHP technology
- Excellent thermal dissipation
- Pre-installed ring blade fans
- Larger contact surface area
Description
V4 Alpha 3DHP BlackAdvanced Cooling, ElevatedThe Cooler Master V4 Alpha 3DHP Black CPU air cooler delivers exceptional cooling performance and sleek aesthetics, featuring the company’s proprietary 3DHP Technology for rapid heat dissipation and peak system efficiency to rival the performance of conventional four-heat-pipe coolers. Using just two heat pipes, it is engineered to maintain optimal processor temperatures under heavy workloads. The V4 Alpha 3DHP Black has been crafted in the shape of a classic V automotive engine but delivers performance comparable to that of one of the most efficient electric cars available. The V4 Alpha 3DHP Black CPU air cooler stands out with its innovative design and excellent performance. Built for enthusiasts and perfected for professionals, V4 Alpha 3DHP Black isn’t just a cooler, it’s the heartbeat of your high-performance machine.
Less heat pipes. More cooling efficiency.
Less noise. More reliability.
The Advanced 3DHP Internal Structure3DHP heat pipes use a hybrid internal structure that combines sintered powder and grooved channels in varying textures and sizes. Each section is optimized for a specific phase—evaporation, condensation, or liquid return—resulting in more efficient heat transfer than traditional designs.
*Image for reference only; actual internal configuration may vary in the final product design.
Cooler Master Proprietary 3DHP Technology3DHP technology redefines heat pipe design by adding a third dimension—an extra pipe that fills the dead zone in standard U-shaped layouts. This added connection improves heat transfer in a slimmer, more efficient design.
It delivers the cooling power of a four-pipe solution with a more streamlined layout—giving you lower temps, quieter fans, and more flexibility, whether you’re building for silence or pushing your system to the limit.
Quieter. Stronger. Smarter.Fewer pipes, better performance. 3DHP’s efficient heat transfer reduces radiator turbulence and lowers fan noise across the system. Whether you’re building for silence or tuning for peak output, 3DHP delivers.
Pre-Installed Ring Blade FansThe included Mobius 120 fans features a ring blade design that cuts high-frequency noise and keeps operation smooth and quiet—especially when paired with the 3DHP module.
Minimalist DesignThe V4 Alpha 3DHP Black draws inspiration from a classic V-style automotive engine—bold, compact, and built for performance. Its unique form factor supports efficient airflow and reliable cooling, all in a design that stands out
Excellent Thermal DissipationKeeps temperatures lower under the same CPU workload, helping maintain system stability and long-term reliability.
Larger Contact Surface for Maximum Heat TransferUnlike most four-pipe coolers with direct contact, our solid copper base covers more surface area. Combined with wider 3DHP heat pipes, it ensures efficient heat transfer from the CPU to the cooling array.
CRYOFUZE THERMAL PASTEIncluded high-performance thermal paste relies on nanoparticles for maximal heat transfer.
AMD & INTEL COMPATIBILITYFeatures compatibility with AMD and Intel CPU sockets.
Specifications
| Performance |
|---|
| Suitable location |
Processor |
| Fan connector |
4-pin |
| Pulse-width modulation (PWM) support |
Yes |
| Fins material |
Aluminum |
| Bearing type |
Loop Dynamic Bearing (LDB) |
| Type |
Air cooler |
| Fan diameter |
4.72" (12 cm) |
| Supported processor sockets |
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 1851, Socket AM4, Socket AM5 |
| Maximum airflow |
63.1 cfm |
| Maximum air pressure |
2.69 mmH2O |
| Airflow |
107.2 m³/h |
| Number of fans |
2 fan(s) |
| Quantity per pack |
1 pc(s) |
| Fan 2 rotational speed (min) |
0 RPM |
| Fan 2 rotational speed (max) |
1850 RPM |
| Fan 2 maximum airflow |
50.5 cfm |
| Fan 2 maximum air pressure |
1.77 mmH2O |
| Fan noise level (min) |
20 dB |
| Fan noise level (max) |
22.6 dB |
| Fan speed (min) |
0 RPM |
| Fan speed (max) |
2050 RPM |
| Fan's mean time to failure (MTTF) |
200000 h |
| Design |
|---|
| Fan connector |
4-pin |
| Fins material |
Aluminum |
| Number of fans |
2 fan(s) |
| Product colour |
Black |
| Radiator material |
Aluminum |
| Base plate material |
Copper |
| Technical details |
|---|
| Type |
Air cooler |
| Fan diameter |
4.72" (12 cm) |
| Supported processor sockets |
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 1851, Socket AM4, Socket AM5 |
| Maximum airflow |
63.1 cfm |
| Maximum air pressure |
2.69 mmH2O |
| Airflow |
107.2 m³/h |
| Number of fans |
2 fan(s) |
| Fan connector |
4-pin |
| Warranty period |
5 year(s) |
| Ports & interfaces |
|---|
| Fan connector |
4-pin |
| Power |
|---|
| Safety current |
0.35 Ah |
| Rated voltage |
12 V |
| Rated current |
0.12 A |
| Fan power consumption |
1.44 W |
| Colour |
|---|
| Product colour |
Black |
| Weight & dimensions |
|---|
| Fan dimensions (W x D x H) |
4.72 x 4.72 x 0.984" (120 x 120 x 25 mm) |
| Package depth |
6.1" (155 mm) |
| Package width |
6.1" (155 mm) |
| Package height |
8.46" (215 mm) |
| Width |
4.49" (114 mm) |
| Depth |
5.24" (133 mm) |
| Height |
6.34" (161 mm) |
| Packaging data |
|---|
| Package depth |
6.1" (155 mm) |
| Package width |
6.1" (155 mm) |
| Package height |
8.46" (215 mm) |
| Package type |
Box |
| Packaging content |
|---|
| Package type |
Box |
| Other features |
|---|
| Safety current |
0.35 Ah |
