8 x 2.5 GbE RJ45, 16 x 10GbE RJ45, 2 x 25G SFP28, 460 Gbps, 1.3" touchscreen, Rack mount (1U), SGCC steel, 442 x 480 x 44 mm
Description
Professional-grade, 24-port Layer 3 Etherlighting™ switch with (16) 10 GbE, (8) 2.5 GbE, and (2) 25G SFP28 ports.
Specifications
| Management features |
| Reset button |
Yes |
| Switch type |
Managed |
| Quality of Service (QoS) support |
Yes |
| Multicast support |
Yes |
| Switch layer |
L2/L3 |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
| Power connector |
AC/DC |
| SFP28 ports quantity |
2 |
| 2.5G Ethernet (copper) ports quantity |
8 |
| 10G Ethernet (copper) ports quantity |
16 |
| Network |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Port mirroring |
Yes |
| Number of VLANs |
1000 |
| Flow control support |
Yes |
| Broadcast storm control |
Yes |
| 10G support |
Yes |
| Virtual LAN features |
Interface-based VLAN, Voice VLAN |
| IPv4 routes |
256000 |
| IGMP snooping |
Yes |
| Access Control List (ACL) IPv4 entries |
256 |
| Data transmission |
| Packet buffer memory |
8 MB |
| MAC address table |
128000 entries |
| Switching capacity |
460 Gbit/s |
| Jumbo frames support |
Yes |
| Static route |
Yes |
| Forwarding rate |
342 Mpps |
| Throughput |
230 Gbit/s |
| Number of VLANs |
1000 |
| Security |
| Loop protection |
Yes |
| IGMP snooping |
Yes |
| Access Control List (ACL) IPv4 entries |
256 |
| DHCP features |
DHCP guarding, DHCP relay, DHCP server, DHCPv6 snooping |
| Multicast features |
| Multicast support |
Yes |
| Design |
| Reset button |
Yes |
| Display type |
LCM |
| Backlight display |
Yes |
| Form factor |
1U |
| Product colour |
Gray |
| Stackable |
Yes |
| Housing material |
SGCC |
| Rack mounting |
Yes |
| Power |
| Power consumption (max) |
150 W |
| Power supply included |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Redundant power supply (RPS) support |
Yes |
| Power source |
AC/DC |
| Power connector |
AC/DC |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Operational conditions |
| Operating temperature (T-T) |
-5 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Virtual LAN features |
| VLAN support |
Yes |
| Number of VLANs |
1000 |
| Virtual LAN features |
Interface-based VLAN, Voice VLAN |
| Weight & dimensions |
| Width |
17.4" (442 mm) |
| Depth |
18.9" (480 mm) |
| Height |
1.73" (44 mm) |
| Weight |
15.9 lbs (7.2 kg) |
| Packaging content |
| Rack mount kit |
Yes |
| Cables included |
Power |
| IPv4 & IPv6 features |
| Access Control List (ACL) IPv4 entries |
256 |
| Performance |
| Packet buffer memory |
8 MB |
| Stackable |
Yes |
| Technical details |
| Form factor |
1U |
| Product colour |
Gray |
| Stackable |
Yes |
| Housing material |
SGCC |
| Rack mounting |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Memory |
| Packet buffer memory |
8 MB |
| Certificates |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Packaging data |
| Rack mount kit |
Yes |
| Cables included |
Power |
