Description
1/2.8" CMOS, 1920x1080px, 2MP, 60 fps, 2GB RAM, 8GB Flash, PoE, 10W
AXIS P3285-LVE offers excellent image quality and forensic details in 2 MP under any light conditions. Thanks to Lightfinder 2.0 and Forensic WDR, it ensures true colors and great detail in near darkness or challenging light. And OptimizedIR enables surveillance in pitch darkness without the need for extra lighting. Axis Zipstream with support for AV1, H.264, and H.265 significantly reduces bandwidth and storage requirements without compromising image quality. Furthermore, this dome camera is available with either a high-performing and light-sensitive 10 mm lens or a powerful and flexible 29 mm tele lens for surveillance from a distance.
Powerful analytics
Featuring a deep learning processing unit (DLPU), this AI-based camera runs advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. Now combined with ARTPEC 9, this application offers enhanced performance with greater accuracy. With an acoustic sensor and support for AXIS Audio Analytics, you be notified whenever something relevant happens, even when there's no visual indication. For instance, it can detect screams, shouts, as well as changes in sound level. Additionally, AXIS Live Privacy Shield makes it easy to remotely monitor activities while protecting privacy.
Robust with strong security
This robust, IK10-, IP66-, and NEMA 4X-rated outdoor-ready camera is both vandal- and impact-resistant. It has an operating temperature range from -40°C to 50 °C (-40°F to 122°F). And a built-in intrusion switch can detect tampering. Axis Edge Vault, our hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. It also offers secure key storage with FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. What’s more, this dome camera is easy to install, maintain, and operate.
Key Features
- Excellent image quality in 2 MP
- Next-generation AI-powered analytics
- Wide or tele lenses available
- AXIS Audio Analytics preinstalled
- Built-in cybersecurity with Axis Edge Vault
Description
Excellent image qualityAXIS P3285-LVE offers excellent image quality and forensic details in 2 MP under any light conditions. Thanks to Lightfinder 2.0 and Forensic WDR, it ensures true colors and great detail in near darkness or challenging light. And OptimizedIR enables surveillance in pitch darkness without the need for extra lighting. Axis Zipstream with support for AV1, H.264, and H.265 significantly reduces bandwidth and storage requirements without compromising image quality. Furthermore, this dome camera is available with either a high-performing and light-sensitive 10 mm lens or a powerful and flexible 29 mm tele lens for surveillance from a distance.
Powerful analytics
Featuring a deep learning processing unit (DLPU), this AI-based camera runs advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. Now combined with ARTPEC 9, this application offers enhanced performance with greater accuracy. With an acoustic sensor and support for AXIS Audio Analytics, you be notified whenever something relevant happens, even when there's no visual indication. For instance, it can detect screams, shouts, as well as changes in sound level. Additionally, AXIS Live Privacy Shield makes it easy to remotely monitor activities while protecting privacy.
Robust with strong security
This robust, IK10-, IP66-, and NEMA 4X-rated outdoor-ready camera is both vandal- and impact-resistant. It has an operating temperature range from -40°C to 50 °C (-40°F to 122°F). And a built-in intrusion switch can detect tampering. Axis Edge Vault, our hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. It also offers secure key storage with FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. What’s more, this dome camera is easy to install, maintain, and operate.
Specifications
| Performance | |
|---|---|
| PTZ modes | Digital PTZ |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Auto-tracking | Yes |
| Tour recording | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Certification | UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC |
| Design | |
| Weatherproof | Yes |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Protection features | Impact resistant, Vandal proof |
| LED indicators | Yes |
| International Protection (IP) code | IP66 |
| Housing material | Plastic, Polycarbonate (PC) |
| Camera | |
| Minimum illumination | 0.02 lx |
| Tilt angle range | -45 - 80° |
| Pan range | -190 - 190° |
| Angle of rotation | 190° |
| Camera shutter speed | 1/37000 - 2 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Camera pixel size | 2.9 µm |
| Lens viewing angle, horizontal | 29.1° |
| Lens viewing angle, vertical | 16.4° |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 1/2.8" |
| Number of sensors | 1 |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 1.76 |
| Auto focus | Yes |
| Recognize distance (wide) | 1181.1" (30 m) |
| Recognize distance (tele) | 3110.2" (79 m) |
| Observe distance (wide) | 2322.8" (59 m) |
| Observe distance (tele) | 6181.1" (157 m) |
| Identify distance (wide) | 590.6" (15 m) |
| Identify distance (tele) | 1535.4" (39 m) |
| Detect distance (wide) | 5866.1" (149 m) |
| Detect distance (tele) | 15511.8" (394 m) |
| Closest focusing distance | 118.1" (3 m) |
| Minimum aperture number | 1.7 |
| Zoom capability | Yes |
| Lens diameter | 1.14" (2.9 cm) |
| Focal length range | 10.8 - 28.2 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 45 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video | |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Text caption overlay | Yes |
| Flip & mirror | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Maximum resolution | 1920 x 1080 pixels |
| Video formats supported | AV1, AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Supported graphics resolutions | 1280 x 800 (WXGA), 1440 x 1080, 1920 x 1080 (HD 1080) |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Total megapixels | 2 MP |
| Audio | |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Audio detection | Yes |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 8000 MB |
| RAM capacity | 2000 MB |
| Ports & interfaces | |
| Terminal block port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Memory | |
| Flash memory | 8000 MB |
| Technical details | |
| Type | IP security camera |
| Form factor | Dome |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Protection features | Impact resistant, Vandal proof |
| Auto-tracking | Yes |
| Tour recording | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Doesn't contain | CFR, PVC, PVC/BFR |
| Compliance certificates | REACH, RoHS, Trade Agreements Act (TAA) |
| Security | |
| Privacy protection | Yes |
| Alert notification type | |
| Video motion detection | Yes |
| Security algorithms | 256-bit AES-XTS, EAP-TLS, HTTPS, MSCHAPv2, PEAP |
| Active tampering alarm | Yes |
| Pixel counter | Yes |
| Human and vehicle targets classification | Yes |
| Material | |
| Housing material | Plastic, Polycarbonate (PC) |
| Management features | |
| Behavior analysis | Line crossing detection |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 10 W |
| Power consumption (typical) | 3.4 W |
| Indication | |
| LED indicators | Yes |
| Certificates | |
| International Protection (IP) code | IP66 |
| Certification | UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 50 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 7.2" (183 mm) |
| Depth | 6.14" (156 mm) |
| Height | 5.87" (149 mm) |
| Weight | 30.3 oz (860 g) |
| Sustainability | |
| Compliance certificates | REACH, RoHS, Trade Agreements Act (TAA) |
| Packaging content | |
| Number of cameras | 1 |
| Sun shield included | Yes |
| Manual | Yes |
| Other features | |
| Doesn't contain | CFR, PVC, PVC/BFR |
