2.5", 500 GB, SATA 3, SSD, 512 MB Cache
Description
What is 3D V-NAND and how does it differ from existing technology?Samsung’s unique and innovative 3D V-NAND flash memory architecture is a breakthrough in overcoming the density limitations, performance and endurance of today’s conventional planar NAND architecture. 3D V-NAND is fabricated by stacking 32 cell layers vertically over one another rather than decreasing the cells dimensions and trying to fit itself onto a fixed horizontal space resulting in higher density and better performance utilising a smaller footprint.
Get into the fast lane with the improved RAPID modeSamsung’s Magician software which provides Rapid Mode for 2x faster processing data speeds on a system level by utilizing unused PC memory (DRAM) as cache storage. The newest Magician increased the maximum memory usage in Rapid mode from 1 GB, in the previous 840 EVO version, to up to 4 GB with the 850 EVO when implementing 16 GB of DRAM. You also get a 2x performance* boost in all random Queue depth.
Secure valuable data through advancedAES 256 encryptionThe 850 EVO comes fortified with the latest hardware-based full disk encryption engine. The AES 256 encryption-bit security technology secures data without any performance degradation and complies with TCG Opal 2.0. It is also compatible with Microsoft e-drive IEEE1667 so your data is protected at all times for your peace of mind.
Protect against overheating with a highly responsiveDynamic Thermal GuardThe 850 EVO’s Dynamic Thermal Guard constantly monitors and maintains ideal temperatures for the drive to operate in optimal conditions for the integrity of your data. When temperatures rise above an optimal threshold, the Thermal Guard automatically throttles temperatures down protecting your data while maintaining responsiveness to ensure your computer is always safe from overheating.
Level up to the 850 EVO simply without any hassleIn three simple steps the Samsung’s One-stop Install Navigator software easily allows you to migrate all the data and applications from the existing primary storage to the 850 EVO. The Samsung Magician software also allows you to optimize and manage your system best suited for your SSD.
Acquire an integrated in-house solution consisting of top-quality componentsSamsung is the only SSD brand to design and manufacture all its components in-house allowing complete optimized integration. The result – enhanced performance, lower power consumption with an up to 1 GB LPDDR2 DRAM cache memory and improved energy-efficiency with the MEX/MGX controller.
Specifications
| Hard drive |
|---|
| SSD capacity |
500 GB |
| Memory type |
MLC |
| Internal |
Yes |
| Performance |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Interface |
Serial ATA III |
| SSD capacity |
500 GB |
| Security algorithms |
256-bit AES |
| S.M.A.R.T. support |
Yes |
| TRIM support |
Yes |
| Memory type |
MLC |
| Mean time between failures (MTBF) |
1500000 h |
| Hardware encryption |
Yes |
| Data transfer rate |
6 Gbit/s |
| Storage drive buffer size |
512 MB |
| Data transmission |
|---|
| Data transfer rate |
6 Gbit/s |
| Design |
|---|
| Internal |
Yes |
| Product colour |
Black |
| SSD form factor |
2.5" |
| Security |
|---|
| Security algorithms |
256-bit AES |
| Endurance |
|---|
| Mean time between failures (MTBF) |
1500000 h |
| Features |
|---|
| Interface |
Serial ATA III |
| SSD capacity |
500 GB |
| Windows operating systems supported |
Yes |
| Security algorithms |
256-bit AES |
| S.M.A.R.T. support |
Yes |
| TRIM support |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Memory type |
MLC |
| Mean time between failures (MTBF) |
1500000 h |
| Hardware encryption |
Yes |
| Data transfer rate |
6 Gbit/s |
| SSD form factor |
2.5" |
| Storage drive buffer size |
512 MB |
| Power |
|---|
| Operating voltage |
5 V |
| Weight & dimensions |
|---|
| Width |
3.94" (100 mm) |
| Weight |
1.9 oz (54 g) |
| Height |
0.268" (6.8 mm) |
| Depth |
2.75" (69.8 mm) |
| Packaging data |
|---|
| Quick start guide |
Yes |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating shock |
1500 G |
| Non-operating shock |
1500 G |
| Technical details |
|---|
| Interface |
Serial ATA III |
| S.M.A.R.T. support |
Yes |
| Operating temperature (T-T) |
0 - 70 °C |
| TRIM support |
Yes |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating shock |
1500 G |
| Non-operating shock |
1500 G |
| Hardware encryption |
Yes |
| Product colour |
Black |
| SSD form factor |
2.5" |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Other features |
|---|
| Product colour |
Black |
| Internal |
Yes |
| Packaging content |
|---|
| Quick start guide |
Yes |
