1/1.8" 8MP, 3840 x 2160 (16:9) 4K, Quad-core Arm Cortex-A53, 10x Hybrid, IR Night 30 m, two-way audio, IP66, IK04
Description
All-weather, 4K dual-lens camera with 10x hybrid zoom, 1/1.8" 8MP image sensor, Multi-TOPS AI Engine, and ultra-low latency pan-tilt-zoom control for motion tracking.
Specifications
| Performance |
|---|
| Infrared (IR) cut-off filter |
Yes |
| Processor model |
ARM Cortex-A53 |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| PTZ control |
Yes |
| Placement supported |
Indoor & outdoor |
| Day/night mode |
Yes |
| Built-in light |
Yes |
| Built-in processor |
Yes |
| Design |
|---|
| Weatherproof |
Yes |
| IK code |
IK04 |
| Form factor |
Spherical |
| Product colour |
Black |
| Mounting type |
Ceiling/Wall/Pole |
| LED indicators |
Yes |
| International Protection (IP) code |
IP66 |
| Housing material |
Aluminum, Polycarbonate (PC) |
| Camera |
|---|
| Angle of rotation |
350° |
| Camera pan control |
Yes |
| Camera tilt control |
Yes |
| Lens viewing angle, horizontal |
109.9° |
| Lens viewing angle, vertical |
56.7° |
| Lens viewing angle, diagonal |
134.1° |
| Image sensor |
|---|
| Optical sensor size |
1/1.8" |
| Lens system |
|---|
| Zoom capability |
Yes |
| Night vision |
|---|
| Night vision |
Yes |
| Night vision distance |
30 m |
| LED type |
IR |
| Video |
|---|
| Noise reduction |
Yes |
| Image quality adjustment |
Brightness, Contrast, HDR, Sharpness |
| Text caption overlay |
Yes |
| Privacy masking |
Yes |
| Noise reduction technology |
2D noise reduction, 3D noise reduction |
| Maximum resolution |
3864 x 2160 pixels |
| Frame rate |
30 fps |
| Total megapixels |
8 MP |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Built-in microphone |
Yes |
| Audio system |
2-way |
| Network |
|---|
| Bluetooth |
No |
| Ethernet interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Compatible memory cards |
MicroSD (TransFlash) |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Processor |
|---|
| Built-in processor |
Yes |
| Hard drive |
|---|
| Built-in HDD |
No |
| Technical details |
|---|
| Type |
IP security camera |
| Form factor |
Spherical |
| PTZ control |
Yes |
| Placement supported |
Indoor & outdoor |
| Product colour |
Black |
| Mounting type |
Ceiling/Wall/Pole |
| Day/night mode |
Yes |
| Reset button |
Yes |
| Built-in speaker(s) |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Security |
|---|
| Light sensor |
Yes |
| Intelligent Video Surveillance (IVS) system features |
Face detection, Human detection, Pet detection, Vehicle detection |
| Human and vehicle targets classification |
Yes |
| Material |
|---|
| Housing material |
Aluminum, Polycarbonate (PC) |
| Management features |
|---|
| Reset button |
Yes |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
24.5 W |
| DC output voltage |
42.5, 57 |
| Indication |
|---|
| LED indicators |
Yes |
| Certificates |
|---|
| International Protection (IP) code |
IP66 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-30 - 50 °C |
| Operating relative humidity (H-H) |
20 - 90% |
| Weight & dimensions |
|---|
| Height |
8" (203.2 mm) |
| Diameter |
4.21" (10.7 cm) |
| Weight |
2.2 lbs (1 kg) |
| Features |
|---|
| License plate recognition |
Yes |
| Sustainability |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Packaging content |
|---|
| Number of cameras |
1 |
| Screws included |
Yes |
| Mounting kit |
Yes |
| Manual |
Yes |
