2-Port USB/VGA Cable KVM Switch with Cables and USB Peripheral Sharing
Key Features
- Built-in 3-ft. (0.91 m) VGA and USB cables
- Supports video resolutions up to 2048 x 1536
- Supports most mouse drivers and multifunction mice
- Easy remote port switching through built-in selector
- Compatible with Windows®, Mac®, Sun and Linux®
Description
Access and Control 2 Computers with One Keyboard/Mouse/MonitorRecommended for home, office and multimedia applications
Switch between computers using built-in remote port selector
Supports video resolutions up to 2048 x 1536
Built-in 3 ft. VGA and USB cables
Independent USB 1.1 Peripheral SharingAdding an optional USB hub (sold separately) to the USB console mouse port allows connection of peripherals, such as printers, hard drives, scanners, webcams and thumb drives
Easy Plug-and-Play Setup and UseCompatible with Windows, Mac, Sun and Linux
No external power supply, software or drivers to install
Supports most mouse drivers and multifunction mice
Takes up no valuable desk space
Specifications
| Ports & interfaces |
|---|
| USB connector type |
USB Type-A |
| Number of computers controlled |
2 |
| Keyboard port type |
USB |
| Mouse port type |
USB |
| Video port type |
VGA |
| Audio connections |
Yes |
| USB 2.0 ports quantity |
2 |
| VGA (D-Sub) ports quantity |
2 |
| Cable length |
35.8" (0.91 m) |
| Performance |
|---|
| Plug and Play |
Yes |
| Maximum resolution |
2048 x 1536 pixels |
| Number of users |
1 user(s) |
| Maximum cable length |
35.8" (0.91 m) |
| Technical details |
|---|
| Product colour |
Black |
| Plug and Play |
Yes |
| Number of users |
1 user(s) |
| Compliance certificates |
RoHS |
| Design |
|---|
| Maximum cable length |
35.8" (0.91 m) |
| Product colour |
Black |
| Cable length |
35.8" (0.91 m) |
| Certification |
CE, FCC, REACH |
| Country of origin |
China |
| Display |
|---|
| Built-in display |
No |
| Video |
|---|
| Maximum resolution |
2048 x 1536 pixels |
| Features |
|---|
| Country of origin |
China |
| Sustainability |
|---|
| Compliance certificates |
RoHS |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Weight & dimensions |
|---|
| Width |
1.02" (25.9 mm) |
| Depth |
2.6" (66 mm) |
| Height |
3.11" (79 mm) |
| Weight |
10.6 oz (300 g) |
| Package width |
6.6" (167.6 mm) |
| Package depth |
9.5" (241.3 mm) |
| Package height |
2.4" (61 mm) |
| Package weight |
14.5 oz (410 g) |
| Packaging data |
|---|
| Package width |
6.6" (167.6 mm) |
| Package depth |
9.5" (241.3 mm) |
| Package height |
2.4" (61 mm) |
| Package weight |
14.5 oz (410 g) |
| Packaging content |
|---|
| Cables included |
Audio (3.5mm), USB, VGA |
| Manual |
Yes |
| Certificates |
|---|
| Certification |
CE, FCC, REACH |
| Logistics data |
|---|
| Country of origin |
China |
| Master (outer) case width |
13" (330.2 mm) |
| Master (outer) case length |
19.2" (487.7 mm) |
| Master (outer) case height |
7.4" (188 mm) |
| Master (outer) case gross weight |
11.6 lbs (5.28 kg) |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case GTIN (EAN/UPC) |
10037332200386 |
| Harmonized System (HS) code |
8471.80.1000 |
