| Processor |
|---|
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cache type |
Smart Cache |
| Processor cache |
24 MB |
| Processor model |
235 |
| Number of processors installed |
1 |
| Processor manufacturer |
Intel |
| Processor boost frequency |
5 GHz |
| Processor threads |
14 |
| Processor cores |
14 |
| Processor family |
Intel Core Ultra 5 |
| Performance cores |
6 |
| Efficient cores |
8 |
| Performance-core base frequency |
3.4 GHz |
| Efficient-core base frequency |
2.9 GHz |
| Processor base power |
65 W |
| Maximum turbo power |
121 W |
| Efficient-core Max Turbo Frequency |
4.4 GHz |
| Performance-core Max Turbo Frequency |
5 GHz |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
27 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
6 TOPs |
| Memory |
|---|
| Internal memory |
16 GB |
| Maximum internal memory |
64 GB |
| Memory slots |
2x SO-DIMM |
| Internal memory type |
DDR5-SDRAM |
| Storage |
|---|
| Storage media |
SSD |
| Number of storage drives supported |
2 |
| Optical drive type |
No |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Total storage capacity |
512 GB |
| SSD form factor |
M.2 |
| Total SSDs capacity |
512 GB |
| NVMe |
Yes |
| Graphics |
|---|
| Discrete graphics card |
Yes |
| Discrete graphics card memory |
4 GB |
| On-board graphics card family |
Intel Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card model |
NVIDIA RTX A400 |
| Discrete graphics memory type |
GDDR6 |
| On-board graphics card model |
Intel Graphics |
| Discrete GPU manufacturer |
NVIDIA |
| On-board GPU manufacturer |
Intel |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel® I219-LM |
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Thunderbolt 3 ports quantity |
0 |
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
3 |
| DC-in jack |
Yes |
| DisplayPort version |
1.4a |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| Number of rear USB ports |
5 |
| Number of front USB ports |
3 |
| Number of front audio ports |
1 |
| Technical details |
|---|
| Cable lock slot type |
Kensington |
| Product type |
PC |
| Trusted Platform Module (TPM) |
Yes |
| Product colour |
Black |
| Chassis type |
Micro PC |
| Audio system |
High Definition Audio |
| Cable lock slot |
Yes |
| Motherboard chipset |
Intel W880 |
| Design |
|---|
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Chassis type |
Micro PC |
| Cable lock slot |
Yes |
| Performance |
|---|
| Audio chip |
Realtek ALC3204 |
| Market positioning |
Business |
| Product type |
PC |
| Trusted Platform Module (TPM) |
Yes |
| Audio system |
High Definition Audio |
| Motherboard chipset |
Intel W880 |
| Trusted Platform Module (TPM) version |
2.0 |
| Software |
|---|
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Power |
|---|
| Power supply input frequency |
50 / 60 Hz |
| Power supply input voltage |
100 - 240 V |
| Power supply |
280 W |
| Operational conditions |
|---|
| Operating altitude |
-598.4 - 120000" (-15.2 - 3048 m) |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating temperature (T-T) |
0 - 35 °C |
| Non-operating altitude |
-598.4 - 420000" (-15.2 - 10668 m) |
| Operating vibration |
0.66 G |
| Non-operating vibration |
1.3 G |
| Operating shock |
110 G |
| Non-operating shock |
160 G |
| Weight & dimensions |
|---|
| Width |
3.12" (79.3 mm) |
| Depth |
7.01" (178 mm) |
| Height |
8.11" (206 mm) |
| Weight |
5.6 lbs (2.54 kg) |
| Packaging content |
|---|
| Mouse included |
Yes |
| Display included |
No |
| Keyboard included |
Yes |
| Mouse connectivity |
Wired |
| Keyboard connectivity |
Wired |
| Display |
|---|
| Display included |
No |
| Other features |
|---|
| Trusted Platform Module (TPM) |
Yes |
| On-board graphics card |
Yes |
| Processor manufacturer |
Intel |
