HPE Aruba Networking 9114 Hybrid, Black, 1U, Rack mounting, 280165 h, 1000,10000 Mbit/s, 20000 Mbit/s
Description
HPE Aruba Networking 9114 Hybrid. Product color: Black, Rack capacity: 1U, Mounting type: Rack mounting. Mean time between failures (MTBF): 280165 h. Ethernet LAN data rates: 1000,10000 Mbit/s, Firewall throughput: 20000 Mbit/s, 3DES/AES throughput: 20 Gbit/s. Console port: RJ-45. Power consumption (max): 185 W, Input voltage: 100 - 240 V, Input frequency: 50 - 60 Hz
Specifications
| Design |
|---|
| Mounting type |
Rack mounting |
| Rack capacity |
1U |
| Product colour |
Black |
| Features |
|---|
| Mean time between failures (MTBF) |
280165 h |
| Network |
|---|
| Ethernet LAN data rates |
1000,10000 Mbit/s |
| Firewall throughput |
20000 Mbit/s |
| 3DES/AES throughput |
20 Gbit/s |
| Security |
|---|
| MAC address filtering |
Yes |
| Access Control List (ACL) |
Yes |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Console port |
RJ-45 |
| SFP+ ports quantity |
4 |
| Combo SFP ports quantity |
4 |
| Power |
|---|
| Output voltage |
12 V |
| Input voltage |
100 - 240 V |
| Input frequency |
50 - 60 Hz |
| Power consumption (max) |
185 W |
| Weight & dimensions |
|---|
| Weight |
13.7 lbs (6.2 kg) |
| Width |
17.4" (442 mm) |
| Height |
1.72" (43.7 mm) |
| Depth |
13.8" (351 mm) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
10 - 95% |
| Technical details |
|---|
| Mean time between failures (MTBF) |
280165 h |
| Performance |
|---|
| Mounting type |
Rack mounting |
| Rack capacity |
1U |
| Product colour |
Black |
