| Processor |
|---|
| Processor generation |
Intel® Core™ i5 (14th gen) |
| Processor cache type |
Smart Cache |
| Processor cache |
24 MB |
| Processor model |
i5-14500 |
| Number of processors installed |
1 |
| Processor manufacturer |
Intel |
| Processor boost frequency |
5 GHz |
| Processor threads |
20 |
| Processor cores |
14 |
| Processor family |
Intel® Core™ i5 |
| Performance cores |
6 |
| Efficient cores |
8 |
| Performance-core base frequency |
2.6 GHz |
| Efficient-core base frequency |
1.9 GHz |
| Processor base power |
65 W |
| Maximum turbo power |
154 W |
| Efficient-core Max Turbo Frequency |
3.7 GHz |
| Performance-core Max Turbo Frequency |
5 GHz |
| Neural processor unit (NPU) |
|---|
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Memory |
|---|
| Non-ECC |
Yes |
| Internal memory |
8 GB |
| Maximum internal memory |
64 GB |
| Memory slots |
2x DIMM |
| Internal memory type |
DDR5-SDRAM |
| Memory data transfer rate |
5600 MT/s |
| Storage |
|---|
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Optical drive type |
No |
| SSD interface |
PCI Express |
| SSD capacity |
256 GB |
| Number of SSDs installed |
1 |
| Total storage capacity |
256 GB |
| SSD memory type |
TLC |
| SSD form factor |
M.2 |
| Total SSDs capacity |
256 GB |
| NVMe |
Yes |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card family |
Intel® UHD Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel UHD Graphics 770 |
| On-board GPU manufacturer |
Intel |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel® I219-LM |
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| Number of SATA III connectors |
2 |
| HDMI version |
2.1 |
| USB 2.0 ports quantity |
4 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
1 |
| DC-in jack |
Yes |
| DisplayPort version |
1.4a |
| Number of rear USB ports |
4 |
| Number of front USB ports |
4 |
| Expansion slots |
|---|
| PCI Express x1 (Gen 3.x) slots |
2 |
| PCI Express x16 (Gen 3.x) slots |
1 |
| Technical details |
|---|
| Cable lock slot type |
Kensington |
| Product type |
PC |
| Trusted Platform Module (TPM) |
Yes |
| Product colour |
Black |
| Chassis type |
Slim PC |
| Audio system |
High Definition Audio |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Sustainability certificates |
ENERGY STAR, EPEAT Climate +, EPEAT Gold |
| Doesn't contain |
PVC/BFR |
| Design |
|---|
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Chassis type |
Slim PC |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Performance |
|---|
| Audio chip |
Realtek ALC3204 |
| Market positioning |
Business |
| Product type |
PC |
| Trusted Platform Module (TPM) |
Yes |
| Audio system |
High Definition Audio |
| Trusted Platform Module (TPM) version |
2.0 |
| Software |
|---|
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Power |
|---|
| Power supply input frequency |
47/63 Hz |
| Power supply input voltage |
90 - 264 V |
| Power supply |
180 W |
| Operational conditions |
|---|
| Operating altitude |
-598.4 - 120000" (-15.2 - 3048 m) |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating temperature (T-T) |
10 - 35 °C |
| Non-operating altitude |
-598.4 - 420000" (-15.2 - 10668 m) |
| Operating vibration |
0.66 G |
| Non-operating vibration |
1.3 G |
| Operating shock |
110 G |
| Non-operating shock |
160 G |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Climate +, EPEAT Gold |
| Doesn't contain |
PVC/BFR |
| Weight & dimensions |
|---|
| Width |
3.74" (95 mm) |
| Depth |
11.5" (293 mm) |
| Height |
11.9" (303.5 mm) |
| Weight |
13 lbs (5.89 kg) |
| Packaging content |
|---|
| Cables included |
AC |
| Mouse included |
Yes |
| Display included |
No |
| Keyboard included |
Yes |
| Mouse connectivity |
Wired |
| Keyboard connectivity |
Wired |
| Display |
|---|
| Display included |
No |
| Other features |
|---|
| Trusted Platform Module (TPM) |
Yes |
| On-board graphics card |
Yes |
| Processor manufacturer |
Intel |
