ADF, 50.8 x 69 mm - 304.8 x 431.8 mm, 2x CCD, 600dpi, USB 3.1, 11 kg
Description
Fujitsu fi-7600, Heavy-duty & flexible production scanner for professional use- Instant processing performance at 100 ppm / 200 ipm (A4, landscape, colour, 200/300 dpi)
- Mixed batch scanning – A8 to A3 from 20-413 g/m²
- Folded documents up to A1 and longer
- 300 sheet ADF
- 30,000 document daily duty cycle
- Paper Protect function which protects jam by detecting abnormalities in sound (iSOP: Intelligent Sonic Paper
- Protection) and document length
- LCD panel for easy operation
- Independent Side Guides for easily aligning mixed size document
- Comes with PaperStream IP (TWAIN/ISIS) and PaperStream Capture; Fujitsu developed scanner driver and
- Image enhancement plus batch capture software application.
Flexible – durable – high volume scanningWith scanning speeds of 100 ppm/200 ipm (200/300 dpi), the fi-7600 greatly improves process efficiency. Large volumes of information can be captured from various media, including thin paper, plastic cards, envelopes and long page documents.
Smooth paper flowThe fi-7600 automatically adjusts to paper weights from 20-413 g/m². The straight paper path reduces the load on a document and assures reliable scanning regardless of the condition and type of a document. By simply sliding a lever to non-separation mode, you can easily scan thick and long documents folded in half, multi-layered document sets
and envelopes.
Innovative paper feeding mechanismsSkew Reducer automatically handles sheets of paper in a stack individually, so that if one sheet is fed-in skewed, subsequent sheets are not forced into physical skew. This ensures that all information in the documents is captured correctly, even in batches with mixed document formats.
The Paper Protection function monitors document movement and automatically stops feeding when any irregularities are detected.
Form follows functionThe fi-7600 is equipped with an operation panel on both sides allowing for right and left handed use. The LCD on the operation panel reveals the scanner status at a glance and enables instant operation.
Lower workload before and after scanningThe Automatic Document Feeder’s (ADF) independent side guides move to exactly the position required for each batch. The adjustable stacker side guides support neat alignment of processed documents.
PaperStream IP and PaperStream CaptureThe fi-7600 comes bundled with PaperStream IP, an integrated scanner driver and image enhancement module that is built on TWAIN/ISIS standards offering user friendly operability, intuitive high quality image creation and real time processing that will benefit post scan routines like OCR. PaperStream Capture enhances the document capture process from adjusting scanning settings to performing batch scanning, verifying data and releasing to directories, repositories or subsequent process routines. Users can complete data capture tasks easily with the extremely user-friendly graphical user interface (GUI). Moving scanned batches into a queue for later retrieval is possible as well.
Service and SupportA one year Advance Exchange is offered as a standard warranty and this includes online support along with parts/labour and shipping costs. Advance Exchange involves the delivery of a refurbished scanner which replaces the faulty scanner.
Service upgrades are available that extends the warranty period to 3 years and additionally offers the possibility for items like onsite service with impressive response and repair times, accidental damage cover and remote desktop support.
Specifications
| Scanning |
|---|
| Output greyscale depth |
8 bit |
| Output monochrome depth |
1 bit |
| Selectable background colour |
Yes |
| Background colours |
Black, White |
| Black/white scanning colour modes |
Grayscale, Monochrome |
| Maximum scan size |
12 x 17" (304.8 x 431.8 mm) |
| Optical scanning resolution |
600 x 600 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Output colour depth |
24 bit |
| ADF scan speed (b/w, A4) |
100 ppm |
| Duplex ADF scan speed (b/w, A4) |
200 ipm |
| Duplex ADF scan speed (colour, A4) |
200 ipm |
| Sensor type |
Dual CCD |
| Light source |
White LED (4x) |
| Daily duty cycle (max) |
30000 pages |
| Design |
|---|
| Built-in display |
Yes |
| Scanner type |
ADF scanner |
| Display |
LCD |
| Product colour |
Black, White |
| Performance |
|---|
| Sensor type |
Dual CCD |
| Light source |
White LED (4x) |
| Daily duty cycle (max) |
30000 pages |
| Scan drivers |
ISIS, TWAIN |
| Input capacity |
|---|
| Auto document feeder (ADF) input capacity |
300 sheets |
| Paper handling |
|---|
| Maximum ISO A-series paper size |
A3 |
| Scanning media types supported |
Envelopes, Plain paper, Plastic Card, Thin paper |
| Auto Document Feeder (ADF) media weight |
20 - 413 g/m² |
| Multi feed detection |
Yes |
| ISO A-series sizes (A0...A9) |
A3, A3+, A4, A5, A6, A7, A8 |
| Minimum scan area (Flatbed) |
2 x 2.72" (50.8 x 69 mm) |
| Ports & interfaces |
|---|
| Standard interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) |
| USB port |
Yes |
| USB version |
3.2 Gen 2 (3.1 Gen 2) |
| Software |
|---|
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Server operating systems supported |
Windows Server 2008, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016 x64 |
| Scan drivers |
ISIS, TWAIN |
| Drivers included |
Yes |
| Power |
|---|
| Power consumption (typical) |
64 W |
| Power consumption (standby) |
0.35 W |
| Input voltage |
100 - 240 V |
| Power supply type |
AC |
| Display |
|---|
| Display |
LCD |
| Media formats |
|---|
| ISO A-series sizes (A0...A9) |
A3, A3+, A4, A5, A6, A7, A8 |
| Technical details |
|---|
| Black/white scanning colour modes |
Grayscale, Monochrome |
| Scanner type |
ADF scanner |
| Product colour |
Black, White |
| Sustainability certificates |
ENERGY STAR |
| Compliance certificates |
RoHS |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Server operating systems supported |
Windows Server 2008, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016 x64 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Weight & dimensions |
|---|
| Width |
9.29" (236 mm) |
| Depth |
17" (432 mm) |
| Height |
8.43" (214 mm) |
| Weight |
24.3 lbs (11 kg) |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
AC, USB |
| Stacker |
Yes |
| ADF paper chute |
Yes |
| AC adapter included |
Yes |
| Drivers included |
Yes |
| Other features |
|---|
| Scanner type |
ADF scanner |
