Nemesis II Series, Texas Instruments DLP, 4000 lm, 30000 h Light Source Life
Key Features
- Incredible Longevity with Virtually Maintenance-Free Operation
- True-to-Life Visuals for an Immersive and Compelling Visual Experience
- Seamless Integration Capabilities with Enhanced Connectivity Options
- 360 Degree And Portrait Projection
Description
The Quantum Laser Nemesis II Series projectors are the perfect combination of energy efficiency and outstanding visual performance, offering brilliant brightness and deep contrast for applications that demand high-quality visuals. Ideal for corporate environments, houses of worship, exhibitions, museums, and art installations, it delivers stunning, immersive imagery with ultimate flexibility. With 360-degree projection, image correction capabilities, and an incredible lifespan, the Quantum Laser Nemesis II Series ensures flawless setup and adaptability in any space, making it the go-to solution for static and dynamic displays.
Specifications
| Projector |
|---|
| Projector native resolution |
WXGA (1280x800) |
| Native aspect ratio |
16:10 |
| Supported aspect ratios |
16:10, 16:9, 4:3 |
| Projection distance |
39.4 - 393.7" (1 - 10 m) |
| Contrast ratio (typical) |
400000:1 |
| Contrast ratio (dynamic) |
2000000:1 |
| Vertical synchronization (min) |
0.024 kHz |
| Vertical synchronization (max) |
0.12 kHz |
| Uniformity |
85% |
| Matrix size |
0.65" |
| Keystone correction, vertical |
-15 - 15° |
| Keystone correction, horizontal |
-15 - 15° |
| Horizontal synchronization (min) |
15 kHz |
| Horizontal synchronization (max) |
100 kHz |
| Projection technology |
DLP |
| Projector brightness |
4000 ANSI lumens |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
30000 h |
| Lens system |
|---|
| Fixed focal length |
0.296" (7.51 mm) |
| Zoom ratio |
1:1 |
| Zoom capability |
Yes |
| Focus |
Manual |
| Offset |
112% |
| F-number (relative aperture) |
2.8 |
| Zoom type |
Manual |
| Video |
|---|
| Full HD |
No |
| Supported graphics resolutions |
1920 x 1200 (WUXGA) |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
2 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| Serial interface type |
RS-232 |
| HDMI version |
1.4 |
| DVI port |
No |
| USB 2.0 Type-A ports quantity |
1 |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi |
No |
| Ethernet LAN (RJ-45) ports |
1 |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Noise level |
32 dB |
| Certification |
CB, CE, EAC, cTUVus, CCC, FCC, UKCA
WEEE, RoHS |
| International Protection (IP) code |
IPX6 |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
15 W |
| Design |
|---|
| Market positioning |
Portable |
| Product type |
Short throw projector |
| Cable lock slot type |
Kensington |
| Product colour |
White |
| Cable lock slot |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (max) |
195 W |
| Power source |
AC |
| Power consumption (typical) |
145 W |
| Power consumption (standby) |
2 W |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 85% |
| Storage temperature (T-T) |
-10 - 60 °C |
| Storage relative humidity (H-H) |
10 - 85% |
| Operating temperature (T-T) |
5 - 40 °C |
| Operating altitude |
0 - 120000" (0 - 3048 m) |
| Weight & dimensions |
|---|
| Package width |
11" (280 mm) |
| Package depth |
15.7" (400 mm) |
| Package height |
6.1" (155 mm) |
| Weight |
6.83 lbs (3.1 kg) |
| Width |
8.5" (216 mm) |
| Depth |
10.9" (278 mm) |
| Height |
4.57" (116 mm) |
| Package weight |
10.1 lbs (4.6 kg) |
| Packaging content |
|---|
| Remote control included |
Yes |
| Manual |
Yes |
| Cables included |
AC, HDMI |
| AC adapter included |
Yes |
| Other features |
|---|
| F-number (relative aperture) |
2.8 |
