8 TB, SATA 6Gb/s, 3.5-inch, 256 MB, 7200 RPM, 4.16 ms, 101.6 x 147 x 26.1 mm, 715 g
Key Features
- Up to 8TB capacity supports traditional IT systems
- Excellent random and sequential performance
- Sustained transfer rate up to 255 MB/s for Advanced Format models
- Choice of 12 Gb/s SAS or 6 Gb/s SATA
- Self-Encrypting options (TCG/FIPS available on SAS models)
- Distributed file systems, like Apache™ Hadoop®, to support Big Data analytics
- Direct-Attached Storage (DAS)
- Enterprise Network-attached Storage (NAS)
- RAID Arrays
- Data centers and cloud computing applications that require higher access density (IOPS/TB)
- Legacy applications requiring 512n format (4TB)
Description
Delivering Economics and Access Speed to Data Center Applications and Workloads
As the industry evolves to develop purpose-built solutions for growing data storage requirements, IT managers continue to rely on mid-range capacity drives that are economical to acquire, yet deliver quick and reliable data access for traditional data center applications. Designed to handle workloads up to 550TB per year, the Ultrastar DC HC300 series is a proven air-platform design that delivers up to 8TB of capacity to help address the economic and access-density requirements of many data center workloads. Ideal for storage and server applications, as well as distributed and scalable computing (including block and file storage architectures), the Ultrastar DC HC300 series provides fast 7,200 RPM performance and lower acquisition cost to help ease budget constraints.
Economical Capacity
4TB, 6TB, and 8TB models for lower acquisition cost
High Performance
Fast data access with 7200 RPM speed, transferring up to 255 MB/s
Drop-In Ready
SAS and SATA options support traditional servers and storage
Specifications
| Certificates |
|---|
| Certification |
REACH, UL, CE/ICES/VCCI, BSMI, RCM, KCC |
| Hard drive |
|---|
| Component for |
PC |
| HDD sustained transfer rate |
243 MiB/s |
| HDD interface transfer rate |
4.8 Gbit/s |
| HDD average transfer rate |
255 MB/s |
| Write seek time |
8.6 ms |
| Read seek time |
8 ms |
| Average latency |
4.16 ms |
| Mean time between failures (MTBF) |
2000000 h |
| Start/stop cycles |
600000 |
| Certification |
REACH, UL, CE/ICES/VCCI, BSMI, RCM, KCC |
| HDD speed |
7200 RPM |
| HDD size |
3.5" |
| HDD capacity |
8 TB |
| Features |
|---|
| Type |
HDD |
| Component for |
PC |
| HDD sustained transfer rate |
243 MiB/s |
| HDD interface transfer rate |
4.8 Gbit/s |
| HDD average transfer rate |
255 MB/s |
| Interface |
Serial ATA III |
| Write seek time |
8.6 ms |
| Read seek time |
8 ms |
| Average latency |
4.16 ms |
| Mean time between failures (MTBF) |
2000000 h |
| Start/stop cycles |
600000 |
| Certification |
REACH, UL, CE/ICES/VCCI, BSMI, RCM, KCC |
| HDD speed |
7200 RPM |
| HDD size |
3.5" |
| HDD capacity |
8 TB |
| Storage drive buffer size |
256 MB |
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^15 bits read |
| 24/7 operation |
Yes |
| Noise level (idle) |
29 dB |
| Power |
|---|
| Power consumption (typical) |
8.8 W |
| Power consumption (idle) |
7.4 W |
| Operating voltage |
5 / 12 V |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 60 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating vibration |
0.67 G |
| Operating shock |
70 G |
| Non-operating vibration |
1.04 G |
| Non-operating shock |
300 G |
| Technical details |
|---|
| Quantity per pack |
1 pc(s) |
| Harmonized System (HS) code |
84717050 |
| Compliance certificates |
RoHS |
| Interface |
Serial ATA III |
| Mean time between failures (MTBF) |
2000000 h |
| Weight & dimensions |
|---|
| Width |
4" (101.6 mm) |
| Weight |
25.2 oz (715 g) |
| Height |
1.03" (26.1 mm) |
| Depth |
5.79" (147 mm) |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Harmonized System (HS) code |
84717050 |
| Other features |
|---|
| Interface |
Serial ATA III |
| Certification |
REACH, UL, CE/ICES/VCCI, BSMI, RCM, KCC |
| Compliance certificates |
RoHS |
