Tripp Lite P136-001 video cable adapter 11.8" (0.3 m) DisplayPort HDMI Black

DisplayPort to HDMI Video Adapter Video Converter (M/F), HDCP, Black, 1 ft.

Key Features

• Continue using your current HDMI display without the expense of a new DP monitor
• Delivers HD picture quality at resolutions up to 1920 x 1080 (1080p) @ 60 Hz
• Supports 7.1-channel surround sound to enhance your streaming experience
• Compact 1 ft. cable fits easily into pocket, briefcase or laptop bag for use anywhere
• Plug-and-play operation with no software required for easy, immediate installation

Description

Save Money by Connecting Your New DisplayPort Laptop to an Existing HDMI Display
This DisplayPort to HDMI passive adapter (M/F) allows you to play stereo audio and high-definition video from your DisplayPort computer or laptop on an HDMI television, monitor or projector. You can continue using your existing HDMI display and HDMI cable without the time, effort or expense of replacing it with a new DP monitor. This one-foot (0.3 meters) cable is an easy, inexpensive way to play 1080p video in classrooms, conference rooms, trade shows and other on-the-road presentations.

Transmits Outstanding 1080p Video for High-Definition Presentations
Ideal for classrooms, lecture halls and anywhere else you may give a presentation, this DisplayPort to HDMI converter supports computer video resolutions up to 1920 x 1080 (at 60 Hz) and HDTV resolutions up to 1080p with 36-bit Deep Color. Watching videos and playing games on a large-screen HDMI monitor is enhanced by the cable's support of 7.1-channel surround sound.

Passive Adapters Require DisplayPort++ for HDMI Pass Through
Because it is a passive adapter, the P136-001 requires that the connected source device have a DisplayPort++ (DP++) dual-mode port, which allows HDMI signals to pass through. Check your DisplayPort source's documentation for compatibility.

Ready to Use Right Out of the Package
Ideal for displaying video on a large monitor or digital sign, each P136-001 cable is perfectly sized for carrying in your briefcase or laptop bag for convenient use anywhere. Just connect the male DP end to your computer's DisplayPort and the female HDMI end to an HDMI cable to begin sharing HD audio/video signals. The plug-and-play adapter requires no software, drivers or external power.

Specifications

Features
Country of origin	Vietnam
Colour depth	36 bit
HDMI version	1.3
DisplayPort version	1.1a
Product colour	Black
Cable length	11.8" (0.3 m)
Connector 1	DisplayPort
Connector 2	HDMI
Connector 1 gender	Male
Connector 2 gender	Male
Connector contacts plating	Gold
Jacket material	Acrylonitrile butadiene styrene (ABS), Polyvinyl chloride (PVC)
AWG wire size	30
Maximum resolution	1920 x 1080 pixels
HDCP	Yes
Certification	CE, FCC, REACH
Connector 1 form factor	Straight
Connector 2 form factor	Straight
Maximum refresh rate	60 Hz
HDCP version	1.3
Supported audio channels	7.1
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 85%
Storage relative humidity (H-H)	5 - 90%
Certificates
Certification	CE, FCC, REACH
Compliance certificates	RoHS
Technical details
Country of origin	Vietnam
Harmonized System (HS) code	84733080
Compliance certificates	RoHS
Weight & dimensions
Cable diameter	0.217" (5.5 mm)
Package width	9" (228.6 mm)
Package depth	0.5" (12.7 mm)
Package height	7" (177.8 mm)
Package weight	1.41 oz (40 g)
Packaging data
Package width	9" (228.6 mm)
Package depth	0.5" (12.7 mm)
Package height	7" (177.8 mm)
Package weight	1.41 oz (40 g)
Quantity per pack	1 pc(s)
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Master (outer) case width	13.7" (348 mm)
Master (outer) case length	1" (25.4 mm)
Master (outer) case height	15.7" (398.8 mm)
Master (outer) case gross weight	14.8 oz (420 g)
Products per master (outer) case	10 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332242584
Harmonized System (HS) code	84733080
