4.7" touchscreen, BLE 4.2, NFC, face, PIN, PoE, 1x GbE RJ45 port, 48V DC, 6W, Proximity sensor, Polycarbonate, glass, IP55, black
Key Features
- Unlock using the NFC card, PIN, UniFi Identity mobile app, face unlock and Touch Pass
- Doorbell for unlock with video of visitor and two-way intercom
- Video works at ADA-compliant mounting height
- IP55-rated weather resistance (-10 to 45° C)
- Connects to UniFi Access Hub using PoE
Description
Third-generation, indoor/outdoor NFC reader and intercom with Apple Touch Pass support.
Specifications
| Technical details |
|---|
| Recommended usage |
Indoor & outdoor |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Type |
Face recognition terminal |
| Authentication type |
Access chip/card, Face recognition |
| Fingerprint reader |
No |
| Access code reader |
No |
| Access chip/card reader |
Yes |
| Product colour |
Black |
| Housing material |
Glass, Polycarbonate (PC) |
| International Protection (IP) code |
IP55 |
| Near Field Communication (NFC) |
Yes |
| LED indicators |
Status |
| Bluetooth version |
4.2 |
| Bluetooth |
Yes |
| Compliance certificates |
Americans with Disabilities Act (ADA), CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA |
| Display |
|---|
| Touchscreen |
Yes |
| Display diagonal |
4.7" |
| Built-in display |
Yes |
| Screen shape |
Flat |
| Camera |
|---|
| Front camera |
Yes |
| Front camera type |
Single camera |
| Viewing angle, vertical |
123.15° |
| Viewing angle, horizontal |
96.67° |
| Performance |
|---|
| Built-in speaker(s) |
Yes |
| Number of speakers |
1 |
| Speaker power |
1.5 W |
| Ports & interfaces |
|---|
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Near Field Communication (NFC) |
Yes |
| Bluetooth version |
4.2 |
| Bluetooth |
Yes |
| Cabling technology |
10/100/1000 |
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) ports quantity |
1 |
| DC voltage range |
48 V |
| Power consumption (max) |
6 W |
| Weight & dimensions |
|---|
| Width |
1.59" (40.4 mm) |
| Weight |
4.8 oz (136 g) |
| Height |
6.3" (160 mm) |
| Depth |
1.6" (40.5 mm) |
| Packaging content |
|---|
| Mounting bracket(s) included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 45 °C |
| Operating relative humidity (H-H) |
5 - 90% |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) ports quantity |
1 |
