Thermaltake The Tower 250 Mini Tower Black, White

The Tower 250 Mini Tower Chassis, SPCC, 1 x 3.5”, 2 x 2.5”, 7.1 kg

Description

The Tower 250 is the latest mini-ITX case in the Tower series, featuring a classic vertical design with an octagonal prism shape. The small form factor doesn't compromise on cooling performance, as it includes two CT120 fans and supports up to eight 120mm fans, as well as a 360mm AIO radiator on the right side. Users can also choose to add the separately sold 3.9" LCD Screen Kit and Chassis Stand Kit to make The Tower 250 more visually appealing.

Small Form, Big Performance
The Tower 250, the latest mini-ITX case in The Tower Series, inherits the classic vertical case design and comes in an octagonal prism shape. It has incredible hardware compatibility, accommodating the high-end GPU up to 360mm, a standard ATX or SFX power supply up to 200mm and a 360mm AIO radiator. What's more, it can accommodate up to eight 120mm or five 140mm fans in the chassis. If you want to make The Tower 250 more visually appealing, you can purchase the separately sold 3.9" LCD Screen Kit and Chassis Stand Kit to upgrade the build; the former to display real-time component information and the latter for a unique view with a special horizontal placement.

Classic Vertical Body Design
The Tower 250 retains the iconic contours of its predecessors, with a vertical body design but in an octagonal prism shape, allowing the chassis to have a smaller footprint and providing flexibility while minimizing obstructions to your gaming and workspace.

A Unique View - Horizontal Case Placement
With the optional chassis stand kit, which includes a bottom cover panel and a display stand for horizontal case placement, The Tower 250 allows for easy customization of the case for a unique viewing experience.


How to Install

1. Unscrew the original feet located on the base of the chassis
2. Install the new bottom cover of the chassis and carefully place The Tower 250 on the stand
*Note: It is recommended to position the radiator higher than the AIO pump.

Supports up to a 360mm Radiator on the Right
The Tower 250 delivers exceptional cooling by supporting up to a 360mm radiator on the right side, which effectively reduces the temperature inside the chassis and maintains optimal system performance.

Tool Free Panels for Easy Access
The Tower 250 features three 3mm tempered glass panels on the front and two perforated panels on each side. All are easily removable without tools.

Two CT120 PC Cooling Fans Pre-installed
The Tower 250 features two 120mm PWM fans on the top to provide good cooling performance.

Visually Pleasing, Totally Interactive
Maximize your Tower 250’s visual effects by upgrading it with our LCD Screen Kit.

The 3.9” LCD Display allows you to monitor real-time information and upload any images or GIFs to add extra flair using the TT RGB Plus software. It also allows you to interact with the cooling components that feature the same LCD displays. The latest version includes weather mode and time mode for users to expand the usage of our LCD displays.

Personalize Your LCD Display
Through the TT RGB Plus, the 3.9'' LCD display presents real-time information and plays JPG and GIF files with 128*480 resolution. What’s more is users can even show the time and weather information on the display, bringing great visual aesthetics and highly customizable functions to your Tower 250 chassis.

Choose The Way You Install
On the right side, The Tower 250 has the capacity to support either three 120mm or two 140mm fans or a 360mm/280mm AIO radiator. Installation is a breeze thanks to the removable fan bracket, which simplifies the process.

Air Intake and Exhaust
Featuring a vertical chassis design, The Tower 250 still has well-designed cold air intakes and hot air exhausts to keep the internal temperature low at all times.

We've Tested Everything, So You Don’t Have To
At Thermaltake, we always stress test our products under harsh conditions to ensure product quality. The Tower 250 products were tested at 100% full load for 30 minutes, with the most high-end CPU, GPU, and motherboard at the time of test, while paring with a consumer-style setup, allowing us to test how the chassis performs under real-world situations.

Massive Airflow & Incredible Performance
Thermal images were taken during thermal testing. Thanks to two CT120 PC Cooling Fans pre-installed, we were able to ensure that The Tower 250 comes with massive airflow, which guarantees amazing cooling performance and a low interior temperature while using the most upscale components.

Perfect Dust Protection
The Tower 250 has well-designed filters on the top, rear, inner sides, and inner bottom layer to protect the system from dust.

Hardware Support and Cooling Solution
The Tower 250 has good hardware support. It can support a CPU cooler with a maximum height of 210mm, a GPU with a maximum length of 360mm (without power cover), a power supply with a length of up to 200mm (including brackets for both ATX and SFX PSU), two 2.5'' SSDs or one 3.5'' HDD behind the motherboard tray. Despite being a mini-ITX case, the Tower 250 is designed for effective cooling. On the top of the case comes with two pre-installed CT120 fans, which can improve thermal efficiency. Users can also add an additional 120mm or 140mm on top of the PSU cover, and the right side of the case accommodates up to a 360mm/280mm all-in-one CPU cooler.

How Much Storage Is Totally Up To You
For storage compatibility, The Tower 250 gives maximum support of up to two 2.5‘’ SSDs or one 3.5‘’ HDD in total.

Handy I/O Ports
One USB 3.2 (Gen 2) Type-C and two USB 3.0 ports are placed on the top panel to grant direct access when needed.

DMD: Dismantlable Modular Design
No more unreachable screw corners or gaps, installation can be a breeze with our Dismantlable Modular Design.

Specifications

Technical details
Number of 3.5" bays	1
Number of 2.5" bays	2
Supported motherboard form factors	Mini-ITX
Supported HDD sizes	2.5,3.5"
Side window	Yes
Product colour	Black, White
Number of expansion slots	3
Maximum CPU cooler height	8.27" (21 cm)
Maximum graphics card length	14.2" (36 cm)
Maximum PSU length	7.87" (20 cm)
Type	PC
Form factor	Mini Tower
Material
Material	SPCC
Design
Anti-dust filter	Yes
Material	SPCC
Number of 3.5" bays	1
Number of 2.5" bays	2
Supported motherboard form factors	Mini-ITX
Side window	Yes
Product colour	Black, White
Number of expansion slots	3
Maximum CPU cooler height	8.27" (21 cm)
Maximum graphics card length	14.2" (36 cm)
Maximum PSU length	7.87" (20 cm)
Type	PC
Form factor	Mini Tower
Display
Built-in display	Yes
Display type	LCD
Display diagonal	3.9"
Display resolution	128 x 480 pixels
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Cooling
Front fans installed	2x 120 mm
Number of front fans supported (max)	2
Front fans diameters supported	120 mm
Number of side fans supported (max)	3
Side fans diameters supported	120,140 mm
Number of rear fans supported (max)	2
Rear fans diameters supported	120,140 mm
Side radiator sizes supported	120,140,240,280,360 mm
Storage
Supported HDD sizes	2.5,3.5"
Weight & dimensions
Width	11.8" (300 mm)
Depth	11.1" (281 mm)
Height	19.9" (506 mm)
Weight	15.7 lbs (7.1 kg)
