Description
2.5 Gbps IPS, 8 x 1 GbE, 2 x 5 GbE
NEXT-GENERATION FIREWALL (NGFW)
Protect your small business or branch location from intrusion, malware and ransomware with an easy-to-use, integrated security solution designed specifically for your needs. SonicWall TZ firewalls deliver enterprise-grade protection without the cost or complexity.
‘Single-pane-of-glass’ Management & Reporting
Manage everything from one location with Network Security Manager, a unified firewall management system that scales for any environment.
SD-WAN and Zero-Touch Deployment Capabilities
SonicWall Secure SD-WAN integrates with TZ firewalls without requiring an additional license, and scales quickly with Zero-Touch Deployment capability.
Deep Memory Inspection
Block even the most advanced attacks with Real-Time Deep Memory Inspection (RTDMI™) and Capture Advanced Threat Protection (ATP).
SSL/TLS Decryption and Inspection
Leverage industry-leading decryption and inspection of TLS/SSL-encrypted traffic in real time, along with TLS 1.3 support.
Superior Performance and Features
Get advanced threat protection at lightning speeds without compromising on performance. The latest generation of TZ firewalls offer expandable storage, redundant power, SonicExpress App onboarding, and more.
Integrated Security Solution
Choose optional PoE and Wi-Fi options with deep integration of SonicOS operating system to deliver an integrated gateway security solution.
Key Features
- Get lightning-fast performance with security processors optimized for speed
- Gain a deeper level of threat prevention through Real-Time Deep Memory Inspection (RTDMI™)
- Leverage shared threat intelligence for continuously updated security
- Rely on a wide range of rich features in SonicWall’s powerful SonicOS operating system
- Leverage multi-core, parallel-processing hardware architecture
- Achieve fast performance using gigabit and multi-gigabit Ethernet interfaces
- Take advantage of single-pass, stream-based inspection
- Inspect simultaneous network streams using deep packet inspection
- Get your firewall up and running quickly with Zero-Touch Deployment
- Grow your distributed network while lowering costs with Secure SD-WAN
- Power your PoE-enabled devices with integrated PoE/PoE+ support
- Gain insight into and control over application usage across the network
- Access resources behind the firewall remotely and securely using native 802.11ac wireless SSL VPN
- Connect from virtually any operating system
- Detect and remove hidden threats over the VPN connection
Description
TZ SERIESNEXT-GENERATION FIREWALL (NGFW)
Protect your small business or branch location from intrusion, malware and ransomware with an easy-to-use, integrated security solution designed specifically for your needs. SonicWall TZ firewalls deliver enterprise-grade protection without the cost or complexity.
‘Single-pane-of-glass’ Management & Reporting
Manage everything from one location with Network Security Manager, a unified firewall management system that scales for any environment.
SD-WAN and Zero-Touch Deployment Capabilities
SonicWall Secure SD-WAN integrates with TZ firewalls without requiring an additional license, and scales quickly with Zero-Touch Deployment capability.
Deep Memory Inspection
Block even the most advanced attacks with Real-Time Deep Memory Inspection (RTDMI™) and Capture Advanced Threat Protection (ATP).
SSL/TLS Decryption and Inspection
Leverage industry-leading decryption and inspection of TLS/SSL-encrypted traffic in real time, along with TLS 1.3 support.
Superior Performance and Features
Get advanced threat protection at lightning speeds without compromising on performance. The latest generation of TZ firewalls offer expandable storage, redundant power, SonicExpress App onboarding, and more.
Integrated Security Solution
Choose optional PoE and Wi-Fi options with deep integration of SonicOS operating system to deliver an integrated gateway security solution.
Specifications
| Data transmission | |
|---|---|
| IPS/IDS throughput | 2500 Mbit/s |
| Maximum firewall connections per second | 25000 |
| SSL inspection throughput | 750 Mbit/s |
| IPSec VPN throughput | 1.8 Gbit/s |
| Threat protection throughput | 2000 Mbit/s |
| Firewall throughput | 4 Gbit/s |
| Performance | |
| Mean time between failures (MTBF) | 384819.181 h |
| Heat dissipation | 44.7 BTU/h |
| Network | |
| Wi-Fi | No |
| VPN tunnels quantity | 200 |
| Local user database | 250 |
| Quality of Service (QoS) support | Yes |
| Number of VLANs | 256 |
| DHCP server | Yes |
| Protocols | |
| Routing protocols | BGP, OSPF, RIP-1, RIP-2 |
| Management features | |
| LED indicators | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| SFP+ module slots quantity | 2 |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Connectivity technology | Wired |
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 8 |
| Ethernet LAN data rates | 1000,5000 Mbit/s |
| Console port | RJ-45 |
| Number of console ports | 1 |
| Design | |
| Form factor | Desktop |
| Built-in display | No |
| Power | |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Redundant power supply (RPS) support | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Form factor | Desktop |
| Heat dissipation | 44.7 BTU/h |
| Display | |
| Built-in display | No |
| Endurance | |
| Mean time between failures (MTBF) | 384819.181 h |
| Features | |
| SSL inspection throughput | 750 Mbit/s |
