10Gb/40Gb/100Gb Duplex Multimode 50/125 OM4 LSZH Fiber Patch Cable (LC/LC), Aqua, 1M (3.3 ft.)
Key Features
- Designed for 40/100-Gig Ethernet applications...OM4 Rated
- Backward compatible with existing 50/125 fiber
- Max 40/100Gb distance of 300 meters @850nm
- Low-Smoke, Zero Halogen (LSZH) Aqua jacket
Description
1 Meter ( 3ft ) LC/LC, OM4 Rated
40/100gb Ethernet speed to 300 meters @850nm
Use with VCSEL and LED laser light sources
High-Speed, High-Bandwidth, Low-Cost
Backward compatible with legacy LAN's
Ideal for Fibre Channel (SAN) applications
IEEE 802.3ae and TIA LOMMF compliant
Specifications
| Features |
|---|
| Connector 1 |
LC |
| Connector 2 |
LC |
| Cable length |
39.4" (1 m) |
| Full duplex |
Yes |
| Core diameter |
50 µm |
| Cladding diameter |
125 µm |
| Product colour |
Blue |
| Connector 2 gender |
Male |
| Connector 1 gender |
Male |
| Country of origin |
China |
| Harmonized System (HS) code |
85447000 |
| Weight & dimensions |
|---|
| Weight |
0.705 oz (20 g) |
| Cable length |
39.4" (1 m) |
| Package width |
6" (152.4 mm) |
| Package depth |
8" (203.2 mm) |
| Package height |
0.252" (6.4 mm) |
| Package weight |
0.705 oz (20 g) |
| Packaging data |
|---|
| Package width |
6" (152.4 mm) |
| Package depth |
8" (203.2 mm) |
| Package height |
0.252" (6.4 mm) |
| Package weight |
0.705 oz (20 g) |
| Technical details |
|---|
| Connector 1 |
LC |
| Connector 2 |
LC |
| Cable length |
39.4" (1 m) |
| Full duplex |
Yes |
| Core diameter |
50 µm |
| Cladding diameter |
125 µm |
| Master (outer) case GTIN (EAN/UPC) |
10037332165210 |
| Logistics data |
|---|
| Master (outer) case width |
7" (177.8 mm) |
| Master (outer) case length |
7.2" (182.9 mm) |
| Master (outer) case height |
4" (101.6 mm) |
| Master (outer) case gross weight |
9.52 oz (270 g) |
| Products per master (outer) case |
10 pc(s) |
| Country of origin |
China |
| Harmonized System (HS) code |
85447000 |
| Master (outer) case GTIN (EAN/UPC) |
10037332165210 |
