StarTech.com 20ft (6m) Power Extension Cord, NEMA 5-15R to NEMA 5-15P Black Extension Cord, 13A 125V, 16AWG, Outlet Extension Power Cable, NEMA 5-15R to NEMA 5-15P AC Power Cord - UL Listed (PAC10120)
Key Features
- POWER EXTENSION CORD: This 20ft (6m) 16AWG AC power extension cable with NEMA 5-15R and NEMA 5-15P connectors is suitable for workstations/home office / Indoor use / Rated to carry 125V at 13A
- PERFORMANCE AND SAFETY: UL listed (UL62 & UL817) / Fully molded strain relief on connectors for durability / Fire Rating: VW-1 / 3 Conductor extension cord with 100% copper wire / This cable is available in other lengths
- SPECS: 20ft (6m) AC Power Cord / NEMA 5-15R to NEMA 5-15P / 16AWG / 125V 13A (Max) / Jacket Type: SJT / Jacket Material: PVC / Black / Temperature Range: 37°F to 140°F (3°C to 60°C) / Cable Outer Diameter: 0.33in (8.5mm)
- COMPATIBILITY: PC Power Extension Cord NEMA 5-15P works with North American outlets / Extend a 3-prong power connection from your desktop computer, server, or printer / Replacement power supply cable/cord
- THE IT PRO’S CHOICE: Designed and built for IT Professionals, this extension cord is backed for life, including free lifetime 24/5 multi-lingual technical assistance
Description
20ft (6m) Power Extension Cord, NEMA5-15R to NEMA5-15P
This 20-foot Computer Power Cord Extension Cable instantly turns a large, awkward power connector into a smaller, streamlined connector.
The power adapter will fit into any socket, maximizing the space on your power strip, surge protector, or wall outlet.
The power adapter also doubles as a power cord extender, giving you an extra 20ft of reach for your monitor, computer case, or any other powered device.
The StarTech.com Advantage
Specifications
| Ports & interfaces |
|---|
| Connector 2 |
NEMA 5-15R |
| Connector 1 |
NEMA 5-15P |
| Cable length |
240.2" (6.1 m) |
| Features |
|---|
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Number of conductors |
3 |
| Cable type |
SJT |
| AWG wire size |
16 |
| Jacket material |
Polyvinyl chloride (PVC) |
| Connector 2 |
NEMA 5-15R |
| Connector 1 |
NEMA 5-15P |
| Cable length |
240.2" (6.1 m) |
| Connector 2 gender |
Female |
| Connector 1 gender |
Male |
| Product colour |
Black |
| Power |
|---|
| Maximum current |
13 A |
| Input voltage |
125 V |
| Colour |
|---|
| Product colour |
Black |
| Operational conditions |
|---|
| Operating temperature (T-T) |
3 - 60 °C |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Weight & dimensions |
|---|
| Width |
0.984" (25 mm) |
| Height |
1.38" (35 mm) |
| Weight |
25.4 oz (721 g) |
| Diameter |
0.335" (8.5 mm) |
| Package width |
9.84" (250 mm) |
| Package depth |
12.8" (325 mm) |
| Package height |
1.38" (35 mm) |
| Package weight |
26.2 oz (743 g) |
| Packaging data |
|---|
| Package width |
9.84" (250 mm) |
| Package depth |
12.8" (325 mm) |
| Package height |
1.38" (35 mm) |
| Package weight |
26.2 oz (743 g) |
| Technical details |
|---|
| Maximum current |
13 A |
| Jacket material |
Polyvinyl chloride (PVC) |
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Products per master (outer) case |
24 pc(s) |
| Master (outer) case width |
18.1" (460 mm) |
| Master (outer) case length |
18.1" (460 mm) |
| Master (outer) case height |
9.84" (250 mm) |
