StarTech.com ICUSB232INT1 interface cards/adapter Internal Serial

Roll over image to zoom in Click on image to zoom

StarTech.com ICUSB232INT1 interface cards/adapter Internal Serial

Name: StarTech.com ICUSB232INT1 interface cards/adapter Internal Serial
Brand: StarTech.com
SKU: ICUSB232INT1
Price: 14.66 USD
Availability: OutOfStock

StarTech.com

Price:

$14.66

Stock:

Sold out

Quantity:

StarTech.com Internal USB Motherboard Header to USB Serial Adapter - DB9 - FTDI USB to Serial Adapter - RS232 Adapter - 1-Port

Description

Add an RS232 serial port to any system with an available USB motherboard header

The ICUSB232INT1 USB to RS232 Serial Adapter lets you add an RS232 port to any desktop system that is equipped with an available USB motherboard header. Unlike standard USB to serial cables, this cable is designed for use inside the PC case, affording an entirely internal solution with no mess or extra adapters needed. This compact and simple USB adapter offers a cost-effective solution that bridges the compatibility gap between modern computers and legacy serial peripherals. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Specifications

Ports & interfaces
Internal	Yes
Output interface	Serial
Serial interface type	RS-232
Serial ports quantity	1
Host interface	IDC
Technical details
Chipset	FTDI - FT232RL
FIFO (First In, First Out)	256 B
Performance
Stop bits	1, 2
Data bits	7, 8
Baud rate	115.2 Kbit/s
Chipset	FTDI - FT232RL
FIFO (First In, First Out)	256 B
Product colour	Black, Green, Silver
Harmonized System (HS) code	84733020
Certificates
Certification	Microsoft WHQL, CE, FCC
Colour
Product colour	Black, Green, Silver
Design
Internal	Yes
Product colour	Black, Green, Silver
Certification	Microsoft WHQL, CE, FCC
Features
Stop bits	1, 2
Data bits	7, 8
Baud rate	115.2 Kbit/s
Chipset	FTDI - FT232RL
FIFO (First In, First Out)	256 B
Harmonized System (HS) code	84733020
Operational conditions
Operating temperature (T-T)	-10 - 85 °C
Storage temperature (T-T)	-20 - 100 °C
Operating relative humidity (H-H)	5 - 85%
System requirements
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows CE, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supported	Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Weight & dimensions
Width	4.84" (123 mm)
Depth	1.77" (45 mm)
Height	0.472" (12 mm)
Weight	1.09 oz (31 g)
Package width	5.63" (143 mm)
Package depth	6.81" (173 mm)
Package height	1.26" (32 mm)
Package weight	5.64 oz (160 g)
Packaging data
Mounting brackets included	Yes
Manual	Yes
Drivers included	Yes
Package width	5.63" (143 mm)
Package depth	6.81" (173 mm)
Package height	1.26" (32 mm)
Package weight	5.64 oz (160 g)
Logistics data
Products per master (outer) case	50 pc(s)
Master (outer) case width	14" (355 mm)
Master (outer) case length	26.9" (682 mm)
Master (outer) case height	12.6" (319 mm)
Harmonized System (HS) code	84733020
Packaging content
Mounting brackets included	Yes
Manual	Yes
Drivers included	Yes
Other features
Chipset	FTDI - FT232RL
