High-Speed HDMI Cable, Digital Video with Audio (M/M), Black, 50 ft. (15.24 m)
Key Features
- Premium double-shielded digital audio/video cable
- Supports iPad2 Video Mirroring when used with Apple Digital AV Adapter
- Gold-plated connectors provide optimal signal transfer
- Bandwidth up to 10.2 Gbps - 4K resolution
- Standard Speed HDMI and HDCP compliant
- Supports UHD Video resolutions up to 4K
Description
Creates a pure digital connection between HDMI-enabled HDTV display devices and HDMI-enabled digital video sources
Supports iPad2 Video Mirroring when used with Apple Digital AV Adapter
Gold-plated connectors provide optimal signal transfer
Premium double-shielded cable protects against outside noise (EMI/RFI)
Impedance-matched twisted-pair construction reduces cross-talk and interference
Bandwidth up to 10.2 Gbps - 4K resolution
In most applications, a signal booster (B122-000-60) will need to be used with this cable to ensure a signal strong enough for your display
Specifications
| Features |
|---|
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Maximum refresh rate |
30 Hz |
| Audio Return Channel (ARC) |
Yes |
| Product colour |
Black |
| Cable length |
600" (15.2 m) |
| Connector 1 |
HDMI Type A (Standard) |
| Connector 2 |
HDMI Type A (Standard) |
| Connector 1 gender |
Male |
| Connector 2 gender |
Male |
| Connector contacts plating |
Gold |
| Magnetically shielded |
Yes |
| Data transfer rate |
10.2 Gbit/s |
| 3D |
Yes |
| Maximum resolution |
3840 x 2160 pixels |
| Supported graphics resolutions |
3840 x 2160 |
| Supported video modes |
1080p |
| HDCP |
Yes |
| Cable jacket material |
Polyvinyl chloride (PVC) |
| HDCP version |
1.4/2.2 |
| Unidirectional |
No |
| Colour sampling |
4:4:4 |
| Extended display identification data (EDID) |
Yes |
| Number of shielding layers |
2 |
| Bending radius (min) |
1.44" (3.65 cm) |
| Cable type |
Round cable |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 50 °C |
| Storage temperature (T-T) |
-15 - 60 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage relative humidity (H-H) |
0 - 90% |
| Certificates |
|---|
| Compliance certificates |
REACH, RoHS |
| Weight & dimensions |
|---|
| Weight |
2.2 lbs (1 kg) |
| Cable diameter |
0.287" (7.3 mm) |
| Package width |
12" (304.8 mm) |
| Package depth |
1" (25.4 mm) |
| Package height |
10" (254 mm) |
| Package weight |
2.2 lbs (1 kg) |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Packaging data |
|---|
| Package width |
12" (304.8 mm) |
| Package depth |
1" (25.4 mm) |
| Package height |
10" (254 mm) |
| Package weight |
2.2 lbs (1 kg) |
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Country of origin |
China |
| Compliance certificates |
REACH, RoHS |
| Other features |
|---|
| Country of origin |
China |
| Width |
12" (304.8 mm) |
| Height |
10" (254 mm) |
| Depth |
1" (25.4 mm) |
| Master (outer) case GTIN (EAN/UPC) |
20037332137856 |
| Logistics data |
|---|
| Country of origin |
China |
| Master (outer) case gross weight |
18.9 lbs (8.57 kg) |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
14" (355.6 mm) |
| Master (outer) case length |
14" (355.6 mm) |
| Master (outer) case height |
8.1" (205.7 mm) |
| Master (outer) case GTIN (EAN/UPC) |
20037332137856 |
| Harmonized System (HS) code |
84733080 |
