StarTech.com 6ft (1.8m) Heavy Duty Extension Cord, IEC 320 C14 to IEC 320 C15 Black Extension Cord, 15A 250V, 14AWG, Extension Power Cable, Heavy Duty AC Power Cord, UL Listed (PXTC14C156)
Key Features
- HEAVY DUTY EXTENSION CORD: This 6ft (1.8m) 14AWG universal power cord with IEC 60320 C14 to IEC 60320 C15 connectors is suitable for workstations/home office / Indoor use / Rated to carry 250V at 15A
- PERFORMANCE AND SAFETY: UL listed (UL62 & UL817) / Fully molded strain relief on connectors for durability / Fire Rating: VW-1 / 3 Conductor Power cable made with 100% copper wire / Available in other lengths
- SPECS: 6ft (1.8m) AC Power Cord / IEC 60320 C14 to IEC 60320 C15 / 14AWG / 250V 15A (Max) / Jacket Type: SJT / Jacket Material: PVC / Black / Temperature Range: -4 to 140°F (-20 to 60°C) / Cable Outer Diameter: 0.36in (9.14mm)
- COMPATIBILITY: PC Power Cord C14 works with most computer hardware / Extend connections to servers, desktop computers, monitors, printers, and more / Replacement power extension cable/cord
- THE IT PRO’S CHOICE: Designed and built for IT Professionals, this power extension cable is backed for life, including free lifetime 24/5 multilingual technical assistance
Description
6ft (1.8m) Heavy Duty Extension Cord, IEC C14 to IEC C15
The PXTC14C156 C14 to C15 Power Cord (6 ft) features a C15 connector rated for high-temperature equipment, as well as 14 AWG wire suitable for high power connections - a reliable solution for connecting to C14 Power Distribution Units (PDU) located in switchgear rooms and data center environments, or large server applications that require a higher rated, heavier gauge cable.
Designed and constructed of high quality materials, this C14 to C15 power cable is backed by our Lifetime Warranty.
The StarTech.com Advantage
Specifications
| Ports & interfaces |
|---|
| Connector 2 |
C15 coupler |
| Connector 1 |
C14 coupler |
| Cable length |
70.9" (1.8 m) |
| Features |
|---|
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Number of conductors |
3 |
| Cable type |
SJT |
| AWG wire size |
14 |
| Jacket material |
Polyvinyl chloride (PVC) |
| Connector 2 |
C15 coupler |
| Connector 1 |
C14 coupler |
| Cable length |
70.9" (1.8 m) |
| Connector 1 standard |
IEC 60320 |
| Connector 2 standard |
IEC 60320 |
| Connector 2 gender |
Female |
| Connector 1 gender |
Male |
| Product colour |
Black |
| Power |
|---|
| Maximum current |
15 A |
| Input voltage |
250 V |
| Colour |
|---|
| Product colour |
Black |
| Operational conditions |
|---|
| Operating temperature (T-T) |
3 - 105 °C |
| Certificates |
|---|
| Compliance certificates |
CE, RoHS |
| Weight & dimensions |
|---|
| Width |
1.12" (28.5 mm) |
| Depth |
70.9" (1800 mm) |
| Height |
0.787" (20 mm) |
| Weight |
11 oz (312 g) |
| Diameter |
0.36" (9.14 mm) |
| Package width |
4.92" (125 mm) |
| Package depth |
8.86" (225 mm) |
| Package height |
1.97" (50 mm) |
| Package weight |
11.2 oz (317 g) |
| Packaging data |
|---|
| Package width |
4.92" (125 mm) |
| Package depth |
8.86" (225 mm) |
| Package height |
1.97" (50 mm) |
| Package weight |
11.2 oz (317 g) |
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Maximum current |
15 A |
| Jacket material |
Polyvinyl chloride (PVC) |
| Compliance certificates |
CE, RoHS |
| Logistics data |
|---|
| Products per master (outer) case |
75 pc(s) |
| Master (outer) case width |
13.6" (345 mm) |
| Master (outer) case length |
20.7" (525 mm) |
| Master (outer) case height |
9.92" (252 mm) |
