Sharp M431-2 Kiosk design 43" LCD 500 cd/m² 4K Ultra HD Black Built-in processor

43 ", IPS, 16:9, 60Hz, 8 ms, 500 cd/m2

Description

Create pixel-perfect imagery with the high-end panel quality of the fully professional NEC M Series large format displays. By focusing on customer needs while also offering professional reliability, the M series displays give customers a digital signage display lineup without all the costs. The M series can support both landscape and portrait orientations while also allowing the modularity possibilities to customize their needs dependent on their application and use. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters – the message. Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. The NEC M series boasts 500 cd/m² brightness which is ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget. Share your message, your way.

Specifications

Display
LED backlight	Yes
Display number of colours	1.073 billion colors
Panel type	IPS
LED backlighting type	Direct-LED
Touchscreen	No
Active display area (W x H)	37.1 x 20.8" (941.2 x 529.4 mm)
Display technology	LCD
Display diagonal	43"
Display resolution	3840 x 2160 pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display diagonal (metric)	42.5" (108 cm)
Vertical scan range	23 - 86 Hz
Native aspect ratio	16:9
Horizontal scan range	26 - 135 kHz
Native refresh rate	60 Hz
Haze rate	25%
Ports & interfaces
USB port	Yes
DisplayPorts in	1
Wi-Fi	No
DisplayPorts quantity	1
Ethernet LAN	Yes
HDMI ports quantity	2
Ethernet LAN data rates	100 Mbit/s
DVI port	No
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
USB version	2.0
USB ports quantity	1
HDMI input ports quantity	2
Audio
RMS rated power	10 W
Built-in speaker(s)	Yes
Design
Product design	Kiosk design
Placement supported	Indoor
Orientation	Horizontal/Vertical
Bezel width (top)	0.547" (1.39 cm)
Bezel width (side)	0.547" (1.39 cm)
Bezel width (bottom)	0.547" (1.39 cm)
Product colour	Black
Panel mounting interface	200 x 200 mm
VESA mounting	Yes
Performance
Purpose	Retail
HDCP	Yes
Web browser	Yes
Wi-Fi	No
Power
Power consumption (max)	175 W
Power consumption (typical)	80 W
Power consumption (standby)	0.5 W
Energy efficiency class (SDR)	G
Computer system
Computer system	Yes
Processor manufacturer	Intel
Built-in processor	Yes
Weight & dimensions
Display width	38.3" (973 mm)
Display depth	2.46" (62.6 mm)
Display height	22.1" (561.2 mm)
Display weight	30.6 lbs (13.9 kg)
Packaging data
Package width	44.1" (1120 mm)
Package depth	7.99" (203 mm)
Package height	27.6" (700 mm)
Package weight	43.2 lbs (19.6 kg)
Batteries included	Yes
Remote control included	Yes
Cables included	HDMI, Power
Packaging content
Batteries included	Yes
Remote control included	Yes
Cables included	HDMI, Power
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 80%
Technical details
VESA mounting	Yes
Panel type	IPS
DisplayPorts in	1
LED backlighting type	Direct-LED
Features
Base material	Metal
Other features
Panel type	IPS
DisplayPorts in	1
Wi-Fi	No
Power consumption (max)	175 W
Display technology	LCD
Bezel width (top)	0.547" (1.39 cm)
Bezel width (side)	0.547" (1.39 cm)
Bezel width (bottom)	0.547" (1.39 cm)
