Description
2*4 dBi, 2.4 GHz, 5 GHz, 574 Mbps, 2402 Mbps, WEP, White
3000Mbps high speed, 160MHz large bandwidth
Double the internet speed for smoother video conferencing
With a new generation of WiFi 6 technology, it supports a large 160MHz bandwidth with a concurrent wireless rate of up to 3000Mpbs, doubling the transmission performance compared to 80MHz bandwidth, and equipped with OFDMA, MU-MIMO and other technologies, 80 terminals can be accessed at the same time, and the network speed is still fast and smooth.
High performance antennas with external independent FEMs
Strong and powerful signal, 400㎡ coverage with zero blind spot
2.4GHz/5GHz full band configured high power independent signal amplifier, built-in 4dBi high gain antennas, strong signal, easily penetrate the wall, even weak signal can be received , easily cover 400㎡. The reasonable layout of the antenna reduces interference from the same frequency, so that the Internet can be accessed even if you are at the edge of the range.
Small Delicate Elegant
Space-saving, Blend into any decoration
The 176*176*43.5mm size design is compact, elegant and stylish, which can perfectly fit into various scenes without destroying the decoration and can greatly save space. The hidden port design allows the network cable to be connected from the ceiling to the network port hidden at the back of the AP, making the wiring neat and simple.
Supports both ceiling and wall mounted
Adaptable to a variety of scenes, easy to install
Support ceiling/wall mounting, flexible choice according to the site environment, no restrictions, can be installed either on the wall or ceiling, how to install convenient, to meet the needs of different scenes of use. Round mounting bracket design, clockwise rotation can be fixed, easy to install.
Automatic RF optimization to reduce signal interference
Enjoy stable WiFi every time, every day
When there are overlapping frequency bands in the working channels of neighbouring APs, the power of one AP will cause signal interference to the neighbouring APs. Through the RF optimization function, the channel and power of APs can be planned automatically to intelligently reduce the signal interference between APs and ensure the high-speed operation of wireless network.
Intelligent load balance
Ultra-low failure rate for better Internet experience
Supports inter-AP load balancing, for wireless user dense areas, i27 works with AP controller, based on t.WaveWeOuterW15Prohe AP's band capacity to do balancing, wireless terminals are assigned to different APs, balance the access load pressure, greatly ensure the stability of the AP and connection availability.
Seamless roaming at 50 ms
From upstairs to downstairs, automatically switch to the best WiFi
When moving within the coverage area, the Internet device automatically connects to the AP node with the best signal, with a switching latency as low as 50ms. Whether it's a video conference or a voice call, you can walk freely and unrestrictedly, with seamless WiFi signal switching, having smooth and stable Internet speed as always.
Supports standard PoE power supply
No external power supply required, easier to install
Supports 802.3at standard PoE network cable power supply, no external power supply needed. One network cable can connect to the switch and gain PoE power supply and data transmission. Real plug and play, no need to consider the socket location, power cable alignment, etc., convenient wiring, flexible networking, more convenient installation.
Description
i27 is designed based on the new Wi-Fi 6 technology. It realizes a bandwidth of 160 MHz and a 5 GHz rate as high as 2.4 Gbps, a rate three times higher than that of ordinary Wi-Fi 5 APs and two times that of ordinary Wi-Fi 6 APs. The application of such new technologies as OFDMA, spatial multiplexing, and MU-MIMO drives the network capacity of a single i27 to 4 times higher. i27 is a perfect choice for such locations as businesses and hotels to deploy high-performance Wi-Fi networks.3000Mbps high speed, 160MHz large bandwidth
Double the internet speed for smoother video conferencing
With a new generation of WiFi 6 technology, it supports a large 160MHz bandwidth with a concurrent wireless rate of up to 3000Mpbs, doubling the transmission performance compared to 80MHz bandwidth, and equipped with OFDMA, MU-MIMO and other technologies, 80 terminals can be accessed at the same time, and the network speed is still fast and smooth.
High performance antennas with external independent FEMs
Strong and powerful signal, 400㎡ coverage with zero blind spot
2.4GHz/5GHz full band configured high power independent signal amplifier, built-in 4dBi high gain antennas, strong signal, easily penetrate the wall, even weak signal can be received , easily cover 400㎡. The reasonable layout of the antenna reduces interference from the same frequency, so that the Internet can be accessed even if you are at the edge of the range.
Small Delicate Elegant
Space-saving, Blend into any decoration
The 176*176*43.5mm size design is compact, elegant and stylish, which can perfectly fit into various scenes without destroying the decoration and can greatly save space. The hidden port design allows the network cable to be connected from the ceiling to the network port hidden at the back of the AP, making the wiring neat and simple.
Supports both ceiling and wall mounted
Adaptable to a variety of scenes, easy to install
Support ceiling/wall mounting, flexible choice according to the site environment, no restrictions, can be installed either on the wall or ceiling, how to install convenient, to meet the needs of different scenes of use. Round mounting bracket design, clockwise rotation can be fixed, easy to install.
Automatic RF optimization to reduce signal interference
Enjoy stable WiFi every time, every day
When there are overlapping frequency bands in the working channels of neighbouring APs, the power of one AP will cause signal interference to the neighbouring APs. Through the RF optimization function, the channel and power of APs can be planned automatically to intelligently reduce the signal interference between APs and ensure the high-speed operation of wireless network.
Intelligent load balance
Ultra-low failure rate for better Internet experience
Supports inter-AP load balancing, for wireless user dense areas, i27 works with AP controller, based on t.WaveWeOuterW15Prohe AP's band capacity to do balancing, wireless terminals are assigned to different APs, balance the access load pressure, greatly ensure the stability of the AP and connection availability.
Seamless roaming at 50 ms
From upstairs to downstairs, automatically switch to the best WiFi
When moving within the coverage area, the Internet device automatically connects to the AP node with the best signal, with a switching latency as low as 50ms. Whether it's a video conference or a voice call, you can walk freely and unrestrictedly, with seamless WiFi signal switching, having smooth and stable Internet speed as always.
Supports standard PoE power supply
No external power supply required, easier to install
Supports 802.3at standard PoE network cable power supply, no external power supply needed. One network cable can connect to the switch and gain PoE power supply and data transmission. Real plug and play, no need to consider the socket location, power cable alignment, etc., convenient wiring, flexible networking, more convenient installation.
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 2976 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Reset button | Yes |
| Spread spectrum method | OFDMA |
| Number of users | 254 user(s) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 2976 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Network | |
| Spread spectrum method | OFDMA |
| Number of users | 254 user(s) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at |
| Features | |
| 6 GHz | No |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Spread spectrum method | OFDMA |
| Number of users | 254 user(s) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 2976 Mbit/s |
| Fast roaming | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2402 Mbit/s |
| Virtual LAN features | Tagged VLAN |
| BeamForming | Yes |
| Security | |
| Number of SSID supported | 8 |
| Security algorithms | SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Access Control List (ACL) | Yes |
| Service Set Identifier (SSID) features | Hidden SSID |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power consumption (max) | 14.04 W |
| Power over Ethernet (PoE) | Yes |
| Design | |
| Placement | Ceiling, Wall |
| Product colour | White |
| Reset button | Yes |
| Antenna | |
| Antenna type | External |
| Antennas quantity | 2 |
| Antenna gain level (max) | 4 dBi |
| Technical details | |
| Reset button | Yes |
| Software | |
| Access Control List (ACL) | Yes |
| Fast roaming | Yes |
| Weight & dimensions | |
| Width | 7.01" (178 mm) |
| Depth | 1.5" (38 mm) |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -10 - 45 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
