Description
All-in-one 41 MP camera for extreme detail
See all the details
Built on a dual Axis system-on-chip, this device delivers extreme detail over great distances and excellent forensic value. It offers 41 MP at 15 fps or 8K at up to 30 fps. And a 4/3” image sensor ensures exceptional low-light performance. With a custom-made, tele Canon lens, it’s perfect for long-distance surveillance and delivers extremely high pixel density. Electronic image stabilization (EIS) ensures smooth video in situations where a camera is subject to vibrations, for instance, at sports arenas or windy harbors. Furthermore, Axis Zipstream reduces bandwidth and storage requirements without compromising image quality.
All-in-one and ready for everything
This powerful camera offers everything you need and is out-of-the-box ready to use. Enclosed in a robust aluminum casing, it also includes a mounting arm for easy installation. And a spacious back box ensures secure cable management. It features a custom-made, tele (50 – 150 mm) Canon lens and 21°-7° horizontal field of view. With 3x zoom, it’s ideal for identification purposes. In addition, thanks to PoE out, you can connect and power another device without any additional cabling. This eliminates the need to rent extra ports and simplifies installation.
Secure and robust surveillance
AXIS Q1809-LE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. This robust, weather-protected, outdoor-ready camera is IP66-, IP67-, IK10- and NEMA 4X-rated and features a IK08-rated impact-resistant glass front window. It has an operating temperature range from -40 °C to 55 °C (-40 °F to 131 °F). Furthermore, surge protection minimizes damage in the case of a power surge.
Key Features
- Out-of-the-box and outdoor-ready
- Superior image quality in 8K
- High light-sensitive 4/3” sensor
- Extreme detail at great distances
- Built-in cybersecurity with Axis Edge Vault
Description
Ideal for long distance surveillance, this all-in-one, outdoor-ready bullet camera delivers superior image quality in 41 MP with high light sensitivity and extremely high pixel density.See all the details
Built on a dual Axis system-on-chip, this device delivers extreme detail over great distances and excellent forensic value. It offers 41 MP at 15 fps or 8K at up to 30 fps. And a 4/3” image sensor ensures exceptional low-light performance. With a custom-made, tele Canon lens, it’s perfect for long-distance surveillance and delivers extremely high pixel density. Electronic image stabilization (EIS) ensures smooth video in situations where a camera is subject to vibrations, for instance, at sports arenas or windy harbors. Furthermore, Axis Zipstream reduces bandwidth and storage requirements without compromising image quality.
All-in-one and ready for everything
This powerful camera offers everything you need and is out-of-the-box ready to use. Enclosed in a robust aluminum casing, it also includes a mounting arm for easy installation. And a spacious back box ensures secure cable management. It features a custom-made, tele (50 – 150 mm) Canon lens and 21°-7° horizontal field of view. With 3x zoom, it’s ideal for identification purposes. In addition, thanks to PoE out, you can connect and power another device without any additional cabling. This eliminates the need to rent extra ports and simplifies installation.
Secure and robust surveillance
AXIS Q1809-LE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. This robust, weather-protected, outdoor-ready camera is IP66-, IP67-, IK10- and NEMA 4X-rated and features a IK08-rated impact-resistant glass front window. It has an operating temperature range from -40 °C to 55 °C (-40 °F to 131 °F). Furthermore, surge protection minimizes damage in the case of a power surge.
Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| PTZ modes | Digital PTZ |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Certification | CSA, UL/cUL, CE, EAC, VCCI, RCM |
| Design | |
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Protection features | Impact resistant |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminum, Glass |
| Camera | |
| Minimum illumination | 0.04 lx |
| Tilt angle range | 0 - 90° |
| Pan range | -180 - 180° |
| Angle of rotation | 270° |
| Camera shutter speed | 1/15500 - 2 s |
| Camera pixel size | 2.315 µm |
| Lens viewing angle, horizontal | 21 - 7° |
| Lens viewing angle, vertical | 12 - 4° |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 4/3" |
| Number of sensors | 1 |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 4 |
| Recognize distance (wide) | 6724.4" (170.8 m) |
| Recognize distance (tele) | 20086.6" (510.2 m) |
| Observe distance (wide) | 13338.6" (338.8 m) |
| Observe distance (tele) | 39866.1" (1012.6 m) |
| Identify distance (wide) | 3362.2" (85.4 m) |
| Identify distance (tele) | 10047.2" (255.2 m) |
| Detect distance (wide) | 33614.2" (853.8 m) |
| Detect distance (tele) | 100456.7" (2551.6 m) |
| Closest focusing distance | 196.9" (5 m) |
| Focus | Motorized |
| Zoom capability | Yes |
| Focal length range | 50 - 150 mm |
| Night vision | |
| Night vision | Yes |
| LED type | IR |
| Infra-red wavelength | 900 nm |
| Video | |
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Mirror, Sharpness |
| Text caption overlay | Yes |
| Image stabilizer | Yes |
| Gain control type | Auto |
| Bit rate control | Variable Bit Rate (VBR) |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Video compression formats | H.264, H.265 |
| Maximum resolution | 7680 x 4320 pixels |
| Video formats supported | AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Supported graphics resolutions | 160 x 120, 160 x 90, 1280 x 800, 3840 x 2160 |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 41 MP |
| Audio | |
| Sample rate | 48 kHz |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Audio formats supported | AAC-LC, ADPCM, G.711, G.726, LPCM, PCM |
| Network | |
| Bluetooth | No |
| Networking standards | IEEE 802.1AE, IEEE 802.1x |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSd , HTTP/2, TLSd , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage | |
| ROM capacity | 4096 MB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 8192 MB |
| Ports & interfaces | |
| Terminal block port | Yes |
| Microphone in | Yes |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Memory | |
| Flash memory | 8192 MB |
| Hard drive | |
| Built-in HDD | No |
| Technical details | |
| Focus | Motorized |
| Video compression formats | H.264, H.265 |
| Type | IP security camera |
| Form factor | Bullet |
| PTZ control | Yes |
| Placement supported | Outdoor |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Protection features | Impact resistant |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Compliance certificates | REACH, RoHS |
| Security | |
| Alert notification type | |
| Security algorithms | EAP-TLS, HTTPS |
| Password protection | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Material | |
| Housing material | Aluminum, Glass |
| Management features | |
| Remotely operated | Yes |
| Cloud-managed | Yes |
| Power | |
| Power source type | DC, PoE |
| Power consumption (max) | 35 W |
| Power consumption (Power over Ethernet (PoE)) | 18.9 W |
| Power consumption (typical) | 17.6 W |
| DC-in jack | Yes |
| Certificates | |
| International Protection (IP) code | IP66, IP67 |
| Certification | CSA, UL/cUL, CE, EAC, VCCI, RCM |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 55 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Depth | 16.2" (411 mm) |
| Height | 7.2" (183 mm) |
| Diameter | 7.2" (18.3 cm) |
| Weight | 7.05 lbs (3.2 kg) |
| Sustainability | |
| Compliance certificates | REACH, RoHS |
| Packaging content | |
| Number of cameras | 1 |
| Other features | |
| Focus | Motorized |
| Video compression formats | H.264, H.265 |
