2.4/5 GHz, Bluetooth, VLAN, 300+ connected devices, W-iFi 6
Key Features
- WiFi 6
- 6 spatial streams
- 115 m² (1,250 ft²) coverage
- 300+ connected devices
- Powered with standard AC wall outlet
- Wireless uplink to UniFi WiFi
Description
Easy-to-deploy WiFi 6 coverage extender that fits a standard wall outlet.
Specifications
| Data transmission |
|---|
| Maximum data transfer rate |
4800 Mbit/s |
| Performance |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Reset button |
Yes |
| Number of users |
300 user(s) |
| Web-based management |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Certification |
CE, FCC, IC |
| Maximum data transfer rate |
4800 Mbit/s |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Network |
|---|
| Number of users |
300 user(s) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Management features |
|---|
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Features |
|---|
| 6 GHz |
No |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Number of users |
300 user(s) |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Maximum data transfer rate |
4800 Mbit/s |
| Bluetooth |
Yes |
| Transmitting power (FCC) |
26 dBm |
| Transmitting power (CE) |
22 dBm |
| Dynamic Frequency Selection (DFS) |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Maximum data transfer rate (2.4 GHz) |
573.5 Mbit/s |
| Maximum data transfer rate (5 GHz) |
4800 Mbit/s |
| Security |
|---|
| Security algorithms |
WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 |
| Power |
|---|
| Power consumption (max) |
11 W |
| Power over Ethernet (PoE) |
No |
| Input current |
0.3 A |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Design |
|---|
| Housing material |
Polycarbonate (PC) |
| Placement |
Wall |
| Product colour |
White |
| Reset button |
Yes |
| LED indicators |
Yes |
| Certification |
CE, FCC, IC |
| Antenna |
|---|
| Antenna gain level (max) |
6 dBi |
| Technical details |
|---|
| Reset button |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Certificates |
|---|
| Certification |
CE, FCC, IC |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Indication |
|---|
| LED indicators |
Yes |
| Software |
|---|
| Dynamic Frequency Selection (DFS) |
Yes |
| Weight & dimensions |
|---|
| Width |
4.42" (112.2 mm) |
| Depth |
1.27" (32.2 mm) |
| Weight |
10.2 oz (290 g) |
| Height |
6.68" (169.7 mm) |
| Packaging data |
|---|
| Quick start guide |
Yes |
| Package type |
Box |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Quantity per pack |
1 pc(s) |
| Package type |
Box |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-10 - 50 °C |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
