500GB, SATA 6Gb/s, 520 MB/sec, V-NAND
Description
V-NAND TechnologySamsung's V-NAND flash memory helps to overcome the limitations of conventional planar NAND architecture. It stacks 48 cell layers vertically over one another rather than trying to fit itself onto a fixed horizontal space, in order to provide high density and performance with a small footprint.
TurboWrite TechnologySamsung’s TurboWrite technology helps to maximize your computing ability. The 850 EVO delivers exceptionally high performance in sequential read (540MB/s) and write (520MB/s) speeds, as well as optimized random performance for high-end computing on client PCs.
Rapid ModeSamsung’s Magician software provides a Rapid Mode for fast processing speeds on a system level by utilizing unused PC memory (DRAM) as cache storage, as well as high performance at various random queue depths.
5-Year Limited WarrantyThe 850 EVO offers endurance and reliability with a high TBW (Total Bytes Written), all backed by a 5-year limited warranty up to 150TBW. It also minimizes performance degradation over time, in order to provide sustained performance for business users.
Specifications
| Hard drive |
|---|
| SSD capacity |
500 GB |
| Memory type |
MLC |
| Data transmission |
|---|
| Read speed |
540 MB/s |
| Write speed |
520 MB/s |
| Random write (4KB) |
40000 IOPS |
| Random read (4KB) |
10000 IOPS |
| Data transfer rate |
6 Gbit/s |
| Security |
|---|
| Security algorithms |
256-bit AES |
| Endurance |
|---|
| Mean time between failures (MTBF) |
1500000 h |
| Performance |
|---|
| Interface |
Serial ATA III |
| Maximum write (4KB) |
90000 IOPS |
| Maximum read (4KB) |
98000 IOPS |
| TBW rating |
150 |
| SSD capacity |
500 GB |
| Security algorithms |
256-bit AES |
| S.M.A.R.T. support |
Yes |
| Read speed |
540 MB/s |
| Write speed |
520 MB/s |
| Memory type |
MLC |
| Random write (4KB) |
40000 IOPS |
| Random read (4KB) |
10000 IOPS |
| Mean time between failures (MTBF) |
1500000 h |
| Data transfer rate |
6 Gbit/s |
| Design |
|---|
| Product colour |
Black |
| SSD form factor |
2.5" |
| Features |
|---|
| Interface |
Serial ATA III |
| Maximum write (4KB) |
90000 IOPS |
| Maximum read (4KB) |
98000 IOPS |
| TBW rating |
150 |
| SSD capacity |
500 GB |
| Security algorithms |
256-bit AES |
| S.M.A.R.T. support |
Yes |
| Read speed |
540 MB/s |
| Write speed |
520 MB/s |
| Memory type |
MLC |
| Random write (4KB) |
40000 IOPS |
| Random read (4KB) |
10000 IOPS |
| Mean time between failures (MTBF) |
1500000 h |
| Data transfer rate |
6 Gbit/s |
| SSD form factor |
2.5" |
| Power |
|---|
| Power consumption (write) |
3.6 W |
| Power consumption (read) |
3.1 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating shock |
1500 G |
| Non-operating shock |
1500 G |
| Non-operating vibration |
20 G |
| Technical details |
|---|
| Interface |
Serial ATA III |
| S.M.A.R.T. support |
Yes |
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating shock |
1500 G |
| Non-operating shock |
1500 G |
| Non-operating vibration |
20 G |
| Product colour |
Black |
| SSD form factor |
2.5" |
| Weight & dimensions |
|---|
| Width |
3.94" (100 mm) |
| Weight |
1.94 oz (55 g) |
| Height |
2.75" (69.8 mm) |
| Depth |
0.268" (6.8 mm) |
| Other features |
|---|
| Product colour |
Black |
