SATA III, 1 TB, 3.5-inch, AF, RoHS
Description
24x7 reliability.These drives are designed to last in always-on, streaming digital audio/video environments such as PVRs, DVRs and surveillance video recorders.
Reduced power consumption.With the combination of WD's IntelliSeek, IntelliPark, and IntelliPower technologies, WD has reduced power consumption by up to 40 percent compared to competitors' drives.
Whisper quiet.Noise levels have been minimized to less than one sone – virtually below the threshold of human hearing.
Compatible.Tested for compatibility in a broad range of AV products including set top boxes, DVD recorders, and mainstream surveillance systems.
IntelliPark.Delivers lower power consumption by automatically unloading the heads during idle to reduce aerodynamic drag.
Long-Term Reliability.These drives are designed to last in high temperature always-on streaming digital audio/video environments such as PVR/DVR, DVR recorders and surveillance video recorders.
SilkStream.Optimized for smooth, continuous digital video playback of up to twelve simultaneous HD streams. SilkStream is compatible with the ATA streaming command set so CE customers can use standard streaming management and error recovery options.
Preemptive Wear Leveling (PWL).The drive arm frequently sweeps across the disk to reduce uneven wear on the drive surface common to audio video streaming applications.
Ideal for:PVRs, DVRs, set-top boxes (STBs), and surveillance video recording.
IntelliSeek.Calculates optimum seek speeds to lower power consumption, noise and vibration.
Advanced Format Technology (AF).Technology being adopted by WD and other drive manufacturers as one of multiple ways to continue growing hard drive capacities. AF is a more efficient media format that enables increased areal densities.
Specifications
| Hard drive |
|---|
| Data transfer rate |
6 Gbit/s |
| Component for |
PC |
| Read seek time |
65 ms |
| Track to track seek time |
30 ms |
| IntelliPower |
Yes |
| Hot-swap |
No |
| Drive ready time |
14.5 s |
| Certification |
RoHS |
| HDD speed |
Variable |
| HDD size |
3.5" |
| HDD capacity |
1 TB |
| Sound emission |
|---|
| Acoustic pressure emissions |
23 dB |
| Certificates |
|---|
| Certification |
RoHS |
| Features |
|---|
| Type |
HDD |
| Component for |
PC |
| Interface |
Serial ATA III |
| Read seek time |
65 ms |
| Track to track seek time |
30 ms |
| IntelliPower |
Yes |
| Native Command Queuing (NCQ) |
Yes |
| Hot-swap |
No |
| Drive ready time |
14.5 s |
| Certification |
RoHS |
| HDD speed |
Variable |
| HDD size |
3.5" |
| HDD capacity |
1 TB |
| Storage drive buffer size |
64 MB |
| Power |
|---|
| Power consumption (standby) |
0.7 W |
| Power consumption (write) |
5.3 W |
| Power consumption (read) |
5.3 W |
| Power consumption (idle) |
3.3 W |
| Start-up current |
1.28 A |
| Operating voltage |
5 / 12 V |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 60 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating shock |
65 G |
| Non-operating shock |
300 G |
| Technical details |
|---|
| Harmonized System (HS) code |
84717050 |
| Interface |
Serial ATA III |
| HDD transfer rate |
110 Mbit/s |
| Dimensions (WxDxH) |
4 x 5.79 x 1.03" (101.6 x 147 x 26.1 mm) |
| Product colour |
Black |
| Width (imperial) |
4" |
| Operating temperature (T-T) |
32 - 140 °F |
| Number of products included |
1 pc(s) |
| Native Command Queuing (NCQ) |
Yes |
| Internal |
Yes |
| Hot-swap |
No |
| Height (imperial) |
1.028" |
| External power adapter |
No |
| Depth (imperial) |
5.787" |
| Cartridge load/Unload cycles |
300000 |
| Packaging content |
|---|
| User guide |
Yes |
| Weight & dimensions |
|---|
| Width |
4" (101.6 mm) |
| Weight |
21.2 oz (600 g) |
| Height |
1.03" (26.1 mm) |
| Depth |
5.79" (147 mm) |
| Weight (imperial) |
1.32 lbs |
| Dimensions (W x D x H) (imperial) |
4 x 5.787 x 1.028" |
| Packaging data |
|---|
| User guide |
Yes |
| Storage |
|---|
| Card reader integrated |
No |
| Logistics data |
|---|
| Harmonized System (HS) code |
84717050 |
| Other features |
|---|
| Interface |
Serial ATA III |
| HDD transfer rate |
110 Mbit/s |
| IntelliPower |
Yes |
| Dimensions (WxDxH) |
4 x 5.79 x 1.03" (101.6 x 147 x 26.1 mm) |
| Product colour |
Black |
| Width (imperial) |
4" |
| Operating temperature (T-T) |
32 - 140 °F |
| Number of products included |
1 pc(s) |
| Native Command Queuing (NCQ) |
Yes |
| Internal |
Yes |
| Height (imperial) |
1.028" |
| External power adapter |
No |
| Drive ready time |
14.5 s |
| Depth (imperial) |
5.787" |
| Data transfer rate |
6 Gbit/s |
| Certification |
RoHS |
| Card reader integrated |
No |
| Acoustic pressure emissions |
23 dB |
| Weight (imperial) |
1.32 lbs |
| Dimensions (W x D x H) (imperial) |
4 x 5.787 x 1.028" |
| Cartridge load/Unload cycles |
300000 |
