Intel Core 5 120U (12MB Cache), Intel Graphics, LAN, WLAN, Bluetooth, No OS
Key Features
- No OS
- Intel Core 5 120U (12MB Cache)
Description
Resilient and Pioneering Spirit of Your Business
Your business should be empowered to stop at nothing while navigating your journey with MSI Business & Productivity Series products.
Built for SustainabilityThe Cubi NUC Series blends business-centric design with environmental responsibility - an embodiment of MSI's dedication to sustainability. Our commitment extends to incorporating sustainable materials in both our product design and packaging, protecting the earth through our actions. By utilizing sustainable materials such as PCR plastics, recycled pulp from FSC™-certified forests, more active management of substances used in manufacturing processes, and the continued use of renewable energy in production processes, we ensure the products' durability and a commitment to a greener world.
The Cubi NUC Series embodies sustainable value and heightened productivity.
A Better Future with
EPEAT Registered MSI Desktops.EPEAT is the world’s premier global ecolabel for electronics. MSI desktops provide sustainable products inside out and participate in EPEAT/EPEAT ecolabel. Let’s protect the earth with actions.
Specifications
| Motherboard |
|---|
| Motherboard form factor |
NUC |
| Number of processors supported |
1 |
| Motherboard chipset |
Intel SoC |
| Processor |
|---|
| Built-in processor |
Yes |
| Processor model |
120U |
| Processor boost frequency |
5 GHz |
| Processor threads |
12 |
| Processor cores |
10 |
| Processor family |
Intel Core 5 |
| Number of processors supported |
1 |
| Motherboard chipset |
Intel SoC |
| Processor manufacturer |
Intel |
| Processor cache |
12 MB |
| Performance cores |
2 |
| Efficient cores |
8 |
| Performance-core Max Turbo Frequency |
5 GHz |
| Efficient-core Max Turbo Frequency |
3.8 GHz |
| Performance-core base frequency |
1.4 GHz |
| Efficient-core base frequency |
0.9 GHz |
| Processor cache type |
Smart Cache |
| Processor generation |
Intel Core (Series 1) |
| Memory |
|---|
| Memory slots type |
SO-DIMM |
| Number of memory slots |
2 |
| Supported memory types |
DDR5-SDRAM |
| Supported memory clock speeds |
5200 MHz |
| Maximum internal memory |
64 GB |
| Video |
|---|
| On-board graphics card |
Yes |
| Graphics card family |
Intel |
| Storage |
|---|
| Supported storage drive types |
HDD & SSD |
| Storage drive sizes supported |
2.5,M.2 |
| Storage drive interface |
M.2 |
| Number of storage drives supported |
3 |
| Compatible memory cards |
MicroSD (TransFlash) |
| Card reader integrated |
Yes |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| Graphics |
|---|
| Number of displays supported |
4 |
| On-board graphics card |
Yes |
| Graphics card family |
Intel |
| On-board graphics card model |
Intel Graphics |
| Audio |
|---|
| Built-in speaker(s) |
No |
| Network |
|---|
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Bluetooth version |
5.3 |
| Bluetooth |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| LAN controller |
Intel I226-V |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| DC-in jack |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| HDMI version |
1.4b/2.1 |
| VGA (D-Sub) ports quantity |
0 |
| USB 2.0 ports quantity |
0 |
| Microphone in |
No |
| HDMI ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| DVI port |
No |
| Thunderbolt 4 ports quantity |
2 |
| Expansion slots |
|---|
| Number of M.2 (M) slots |
2 |
| Design |
|---|
| Motherboard form factor |
NUC |
| VESA mounting |
Yes |
| Product type |
Mini PC barebone |
| Housing material |
Plastic |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| On/off switch |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Cooling type |
Active |
| Product colour |
Black |
| Chassis type |
0.84L sized PC |
| Certification |
FCC(Class B), CB/CE, UL(CUL), BSMI, VCCI, RCM(C-Tick) |
| Performance |
|---|
| Motherboard form factor |
NUC |
| Number of displays supported |
4 |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Operating system installed |
No |
| Number of processors supported |
1 |
| Motherboard chipset |
Intel SoC |
| Colour |
|---|
| Product colour |
Black |
| Technical details |
|---|
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Quick start guide |
Yes |
| Processor cores |
10 |
| Cooling type |
Active |
| Chassis type |
0.84L sized PC |
| Warranty period |
2 year(s) |
| Packaging data |
|---|
| Power cord included |
Yes |
| AC adapter included |
Yes |
| Package width |
8.07" (205 mm) |
| Package depth |
8.66" (220 mm) |
| Package height |
3.7" (94 mm) |
| Package weight |
0.0511 oz (1.45 g) |
| Certificates |
|---|
| Certification |
FCC(Class B), CB/CE, UL(CUL), BSMI, VCCI, RCM(C-Tick) |
| Software |
|---|
| Operating system installed |
No |
| Management features |
|---|
| On/off switch |
Yes |
| Features |
|---|
| Number of displays supported |
4 |
| Logistics data |
|---|
| Country of origin |
China |
| Power |
|---|
| Power supply type |
External AC adapter |
| Power supply |
120 W |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 35 °C |
| Operating relative humidity (H-H) |
0 - 85% |
| Weight & dimensions |
|---|
| Width |
5.22" (132.5 mm) |
| Depth |
5.34" (135.6 mm) |
| Height |
1.97" (50.1 mm) |
| Package width |
8.07" (205 mm) |
| Package depth |
8.66" (220 mm) |
| Package height |
3.7" (94 mm) |
| Package weight |
0.0511 oz (1.45 g) |
| Weight |
0.0220 oz (0.625 g) |
| Packaging content |
|---|
| Display included |
No |
| Power cord included |
Yes |
| AC adapter included |
Yes |
| Mouse included |
No |
| Quick start guide |
Yes |
| Keyboard included |
No |
| Other features |
|---|
| Chassis type |
0.84L sized PC |
| Country of origin |
China |
| Warranty period |
2 year(s) |
