| Processor |
|---|
| Processor generation |
8th gen Intel® Core™ i5 |
| Processor base frequency |
2.8 GHz |
| Processor manufacturer |
Intel |
| Cooler included |
No |
| Processor codename |
Coffee Lake |
| Memory bandwidth supported by processor (max) |
41.6 GB/s |
| Thermal Design Power (TDP) |
65 W |
| Processor cache |
9 MB |
| Processor ARK ID |
126687 |
| Processor model |
i5-8400 |
| Processor threads |
6 |
| System bus rate |
8 GT/s |
| Processor operating modes |
64-bit |
| Processor boost frequency |
4 GHz |
| Bus type |
DMI3 |
| Component for |
PC |
| Processor lithography |
14 nm |
| Processor family |
Intel® Core™ i5 |
| Processor cores |
6 |
| Processor socket |
LGA 1151 (Socket H4) |
| Processor code |
SR3QT |
| Processor cache type |
Smart Cache |
| Generation |
8th Generation |
| Package type |
Tray |
| Memory |
|---|
| Maximum internal memory supported by processor |
64 GB |
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
2666 MHz |
| Memory bandwidth supported by processor (max) |
41.6 GB/s |
| Supported memory types |
DDR4-SDRAM |
| Memory channels |
Dual-channel |
| ECC |
No |
| Graphics |
|---|
| On-board graphics card outputs supported |
DisplayPort, Embedded DisplayPort (eDP), HDMI |
| On-board graphics card maximum resolution (DisplayPort) |
4096 x 2304 pixels |
| Number of execution units |
23 |
| On-board graphics card ID |
0x3E92 |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) |
4096 x 2304 pixels |
| On-board graphics card 4K support |
Yes |
| On-board graphics card refresh rate at maximum resolution (HDMI) |
24 Hz |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) |
60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) |
60 Hz |
| Maximum on-board graphics card memory |
64 GB |
| Number of displays supported (on-board graphics) |
3 |
| On-board graphics card maximum resolution (HDMI) |
4096 x 2304 pixels |
| On-board graphics card DirectX version |
12.0 |
| On-board graphics card OpenGL version |
4.5 |
| On-board graphics card model |
Intel® UHD Graphics 630 |
| On-board graphics card |
Yes |
| On-board graphics card dynamic frequency (max) |
1050 MHz |
| On-board graphics card base frequency |
350 MHz |
| Maximum graphics card memory |
64 GB |
| Power |
|---|
| Thermal Design Power (TDP) |
65 W |
| Technical details |
|---|
| Intel Stable Image Platform Program (SIPP) |
No |
| Thermal solution specification |
PCG 2015C |
| Intel TSX-NI |
No |
| Intel® Secure Key |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel Trusted Execution Technology |
No |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® InTru™ 3D Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Idle States |
Yes |
| Execute Disable Bit |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| PCI Express slots version |
3.0 |
| PCI Express configurations |
1x16, 2x8, 1x8+2x4 |
| Supported instruction sets |
SSE4.1, SSE4.2, AVX 2.0 |
| Scalability |
1S |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Enhanced Halt State |
Yes |
| Embedded options available |
No |
| CPU configuration (max) |
1 |
| Processor code |
SR3QT |
| Product type |
Processor |
| Processor cache |
9216 KB |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel 64 |
Yes |
| Thermal Design Power (TDP) |
65 W |
| Supported memory types |
DDR4-SDRAM |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Yes |
| Status |
Discontinued |
| Maximum resolution & refresh rate (Integrated Flat Panel) |
4096x2304@60Hz |
| Maximum resolution & refresh rate (HDMI) |
4096x2304@24Hz |
| Maximum resolution & refresh rate (DisplayPort) |
4096x2304@60Hz |
| Market segment |
Desktop |
| Launch date |
Q4'17 |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Stable Image Platform Program (SIPP) version |
0.00 |
| Intel Secure Key Technology version |
1.00 |
| Intel Identity Protection Technology version |
1.00 |
| Processor cache type |
Smart Cache |
| Bus type units |
GT/s |
| Bus bandwidth |
8 |
| Maximum memory |
128 GB |
| Intel TSX-NI version |
0.00 |
| Processor brand name |
8th Gen Intel Core i5
8th Gen Intel Core i5 Processor |
| Last change |
63903513 |
| Product family |
Intel Core Processors |
| Maximum graphics card memory |
64 GB |
| Processor ID |
0x3E92 |
| Bus speed |
8 GT/s |
| Features |
|---|
| On-board graphics card ID |
0x3E92 |
| Maximum number of PCI Express lanes |
16 |
| Thermal Design Power (TDP) |
65 W |
| Processor package size |
37.5 x 37.5 mm |
| Processor ARK ID |
126687 |
| Thermal solution specification |
PCG 2015C |
| Thermal Monitoring Technologies |
Yes |
| Idle States |
Yes |
| Execute Disable Bit |
Yes |
| PCI Express slots version |
3.0 |
| PCI Express configurations |
1x16, 2x8, 1x8+2x4 |
| Supported instruction sets |
SSE4.1, SSE4.2, AVX 2.0 |
| Scalability |
1S |
| Embedded options available |
No |
| CPU configuration (max) |
1 |
| Processor code |
SR3QT |
| Market segment |
Desktop |
| Harmonized System (HS) code |
8542310001 |
| Export Control Classification Number (ECCN) |
5A992C |
| Commodity Classification Automated Tracking System (CCATS) |
G077159 |
| PCI Express CEM revision |
3.0 |
| Processor special features |
|---|
| Intel Clear Video Technology |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel 64 |
Yes |
| Conflict-Free processor |
Yes |
| Intel® Memory Protection Extensions (Intel® MPX) |
Yes |
| Intel® Device Protection Technology (Intel® DPT) with Boot Guard |
Yes |
| Intel® Optane™ Memory Ready |
Yes |
| Intel® OS Guard |
Yes |
| Intel Stable Image Platform Program (SIPP) |
No |
| Intel TSX-NI |
No |
| Intel® Secure Key |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel Trusted Execution Technology |
No |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® InTru™ 3D Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Enhanced Halt State |
Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Stable Image Platform Program (SIPP) version |
0.00 |
| Intel Secure Key Technology version |
1.00 |
| Intel Identity Protection Technology version |
1.00 |
| Intel TSX-NI version |
0.00 |
| Intel® Boot Guard |
Yes |
| Intel® vPro™ Platform Eligibility |
No |
| Intel® Turbo Boost Technology 2.0 frequency |
4 GHz |
| Intel® Transactional Synchronization Extensions |
No |
| Operational conditions |
|---|
| Tjunction |
100 °C |
| Packaging data |
|---|
| Package type |
Tray |
| Logistics data |
|---|
| Harmonized System (HS) code |
8542310001 |
| Weight & dimensions |
|---|
| Processor package size |
37.5 x 37.5 mm |
| Other features |
|---|
| Maximum internal memory |
128 GB |
| Maximum internal memory |
65536 MB |
| CPU configuration (max) |
1 |
| Processor code |
SR3QT |
