HPE ProLiant DL20 Gen11 E-2436 2.9GHz 6-core 1P 32GB-DR MR408i-o 4SFF 2x500W RPS NA Server, 2.9 GHz, E-2436, 32 GB, DDR5-SDRAM, 1.92 TB, Rack (1U)
Reasons To Buy
Compact, Secure, and Reliable Design for an Affordable Solution
HPE ProLiant DL20 Gen11 server is a short-depth chassis of 15.05 inches, providing mobility and easy deployment in a wide variety of environments.
HPE ProLiant DL20 Gen11 server has great quality and design features that are a hallmark of the HPE ProLiant family such as tool-less access to system components and enhanced serviceability.
Handle a range of light workloads to more demanding requirements with affordable configuration choices and a wide variety of Hewlett Packard Enterprise qualified options.
Right Balance of Performance, Flexibility, Reliability, and Manageability for Growing Business Needs
HPE ProLiant DL20 Gen11 server offers a wide choice of dual-core, quad-core, hexa-core or octa-core Intel Xeon E processors with up to 128 GB of DDR5 ECC memory to handle your workload demands.
Experience outstanding configuration flexibility with support for up to two large form factor (LFF) or six small form factor (SFF) drives, four DDR5 ECC UDIMMs, 290W, 500W, 800W or 1000W power supplies, and a more efficient deployment of options via HPE PCIe and OCP slots - now supporting PCIe 5.0.
The reliable HPE ProLiant DL20 Gen11 server combines a dense and compact form factor with redundant power supply capability, which keeps your business running and provides data protection and accessibility even in the event of a power supply failure.
Along with an embedded 4 x 1GbE, you have a choice of HPE PCIe standup adapters that offer a choice of networking bandwidth (1GbE to 10GbE) and fabric, so you can adapt and grow to changing business needs.
HPE iLO6 provides a more efficient and easier server management. It enables large-scale firmware deployment, improved GUI to simplify management with industry-standard APIs, and easy system debug access.
Security Innovations
Only Hewlett Packard Enterprise offers industry-standard servers, such as the HPE ProLiant DL20 Gen11server, with major firmware anchored directly into the silicon and with security protection built in across the server life-cycle, starting with Silicon Root of Trust from HPE.
Millions of lines of firmware code run before the server operating system boots. With Runtime Firmware Verification, enabled by the optional HPE iLO Advanced Premium Security Edition, the server’s firmware is checked every 24 hours, verifying validity and credibility of essential system firmware.
Secure Recovery allows server firmware to roll back to the last known good state or factory settings after detection of compromised server.
Additional security options are available with Trusted Platform Module (TPM) to avoid unauthorized access to the server and store artifacts used to authenticate the server platforms, while the Intrusion Detection Kit logs and alerts when the server hood is removed for further protection.
Industry-leading Services and Ease of Deployment
HPE ProLiant DL20 Gen11 server comes standard with a complete set of services from HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability.
HPE Services simplify the stages of your IT journey. Advisory and Transformation Services professionals understand customer challenges and design an ideal solution. Professional Services enables rapid deployment of solutions.
Operational Services from HPE Services includes: HPE Complete Care, HPE Tech Care and project-based services, such as Integration and Performance services. Additional services can be added to customize your experience at any stage of your IT lifecycle.
HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.
Description
HPE ProLiant DL20 Gen11 E-2436 2.9GHz 6-core 1P 32GB-DR MR408i-o 4SFF 2x500W RPS NA Server. Processor family: Intel® Xeon®, Processor frequency: 2.9 GHz, Processor model: E-2436. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory layout (slots x size): 1 x 32 GB. Total storage capacity: 1.92 TB. Ethernet LAN. Power supply: 500 W, Redundant power supply (RPS) support. Chassis type: Rack (1U)
Specifications
| Processor |
|---|
| Processor cache |
18 MB |
| Processor frequency |
2.9 GHz |
| Number of processors installed |
1 |
| Processor model |
E-2436 |
| Processor boost frequency |
5 GHz |
| Processor cores |
6 |
| Processor manufacturer |
Intel |
| Motherboard chipset |
Intel C262 |
| Processor family |
Intel® Xeon® |
| Memory |
|---|
| Internal memory |
32 GB |
| Memory layout (slots x size) |
1 x 32 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
4800 MHz |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR5-SDRAM |
| ECC |
Yes |
| Storage |
|---|
| Supported RAID controllers |
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller |
| Number of SSDs supported |
4 |
| Total storage capacity |
1.92 TB |
| Number of HDDs installed |
2 |
| SSD interface |
SATA III |
| SSD capacity |
960 GB |
| RAID support |
Yes |
| RAID levels |
0, 1, 1 ADM, 5, 6, 10 ADM, 10, 50, 60 |
| Optical drive type |
No |
| Number of SSDs installed |
2 |
| SSD size |
2.5" |
| Supported SSD sizes |
2.5" |
| Graphics |
|---|
| On-board graphics card model |
Matrox G200 |
| Maximum graphics card memory |
16 MB |
| On-board graphics card |
Yes |
| Network |
|---|
| LAN controller |
Broadcom BCM5719 |
| Ethernet LAN |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| VGA (D-Sub) ports quantity |
1 |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
4 |
| DisplayPorts quantity |
1 |
| Optical drive |
|---|
| Optical drive type |
No |
| Design |
|---|
| Rack mounting |
Yes |
| Optical drive type |
No |
| Chassis type |
Rack (1U) |
| Performance |
|---|
| Compatible operating systems |
Microsoft Windows Server
VMware ESXi
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Canonical Ubuntu |
| Remote administration |
iLO 6 ASIC |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Operating system installed |
No |
| Software |
|---|
| Compatible operating systems |
Microsoft Windows Server
VMware ESXi
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Canonical Ubuntu |
| Operating system installed |
No |
| Power |
|---|
| Number of main power supplies |
2 |
| Number of redundant power supplies installed |
2 |
| Redundant power supply (RPS) support |
Yes |
| Power supply |
500 W |
| Management features |
|---|
| Remote administration |
iLO 6 ASIC |
| Technical details |
|---|
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Rack mounting |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Chassis type |
Rack (1U) |
| Weight & dimensions |
|---|
| Width |
17.1" (434.6 mm) |
| Height |
1.7" (43.2 mm) |
| Depth |
14.9" (378.4 mm) |
