2.4GHz (1376 Mbps), 5GHz (5760 Mbps), 6GHz (11520 Mbps), 802.11 a/b/g/n/ac/ax/be, 2× 10G Ethernet Ports, 280 x 280 x 46.5 mm
Key Features
- BE19000 Tri-Band Wi-Fi 7: 11520 Mbps (6 GHz) + 5760 Mbps (5 GHz) + 1376 Mbps (2.4 GHz). Buffering will no longer be a problem
- Clear 6 GHz Band: Brings cleaner and wider band resources to your Wi-Fi
- 2× 10G Port: Unlock the full potential of Wi-Fi 7
- 320 MHz Bandwidth: Up to 320 MHz bandwidth enables many more simultaneous transmissions at the fastest possible speeds
- Low Latency and Interference: Multi-Link Operation, and Multi-RUs ensure high performance of your network
- Advanced Functions：Supports centralized management, mesh, and seamless roaming
Description
Multi-Link Operation (MLO)
Enables devices to simultaneously send and receive data across different frequency bands and channels.
Two 10G PoE++ Ports
Boosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.
Auto Channel Selection and Power Adjustment
Boost WiFi performance and minimize interference for your network.
Intelligent Power Management
Offers more reliable network operation for your business.
Centralized Cloud Management
Manage the whole network locally or from the cloud.
Omada Mesh Technology
More flexible and convenient wireless deployment.△
PoE++ Power
Supports both 12V DC and 802.3bt PoE++ for flexible installations.
Specifications
| Data transmission |
|---|
| Ethernet LAN data rates |
10000 Mbit/s |
| Maximum data transfer rate |
19000 Mbit/s |
| Performance |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Flow control support |
Yes |
| Automatic channel selection |
Yes |
| Reset button |
Yes |
| Frequency band |
2.4 - 6 GHz |
| Number of users |
760 user(s) |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates |
10000 Mbit/s |
| Maximum data transfer rate |
19000 Mbit/s |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Band steering |
Yes |
| Airtime Fairness (ATF) |
Yes |
| Wireless LAN features |
|---|
| Frequency band |
2.4 - 6 GHz |
| Network |
|---|
| Number of users |
760 user(s) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Management features |
|---|
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Quality of Service (QoS) support |
Yes |
| Features |
|---|
| 6 GHz |
Yes |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Flow control support |
Yes |
| Automatic channel selection |
Yes |
| Frequency band |
2.4 - 6 GHz |
| Number of users |
760 user(s) |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates |
10000 Mbit/s |
| Maximum data transfer rate |
19000 Mbit/s |
| Automatic channel scanning |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Band steering |
Yes |
| Airtime Fairness (ATF) |
Yes |
| Maximum data transfer rate (2.4 GHz) |
1376 Mbit/s |
| Maximum data transfer rate (5 GHz) |
5760 Mbit/s |
| Maximum data transfer rate (6 GHz) |
11520 Mbit/s |
| BeamForming |
Yes |
| Security |
|---|
| Security algorithms |
WPA, WPA2, WPA3 |
| Access Control List (ACL) |
Yes |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
2 |
| DC-in jack |
Yes |
| Power |
|---|
| Power over Ethernet (PoE) |
Yes |
| DC voltage range |
12 V |
| Design |
|---|
| Placement |
Ceiling, Wall |
| Product colour |
White |
| Reset button |
Yes |
| LED indicators |
Yes |
| Antenna |
|---|
| Antenna type |
Internal |
| Technical details |
|---|
| Reset button |
Yes |
| Indication |
|---|
| LED indicators |
Yes |
| Software |
|---|
| Automatic channel scanning |
Yes |
| Access Control List (ACL) |
Yes |
| Weight & dimensions |
|---|
| Width |
11" (280 mm) |
| Depth |
11" (280 mm) |
| Height |
1.83" (46.5 mm) |
| Packaging data |
|---|
| Quick start guide |
Yes |
| Mounting kit |
Yes |
| Package type |
Box |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Package type |
Box |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
