8-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE+, 16 Gbps, Fanless, 65 W
Key Features
- 8× 10/100/1000 Mbps RJ45 ports
- 8× PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE power up to 30 W for each PoE port
- Supports PoE power up to 65 W for all PoE ports
- Up to 250m (820ft) data and power transmitting range under Extend Mode
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play. No configuration or central management required
Description
Omada 8-Port Gigabit Desktop Switch with 8-Port PoE+
Specifications
| Management features |
|---|
| Reset button |
Yes |
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Yes |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Power connector |
DC-in jack |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Network |
|---|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Networking standards |
IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Auto MDI/MDI-X |
Yes |
| 10G support |
No |
| Auto-negotiation |
Yes |
| IGMP snooping |
Yes |
| Data transmission |
|---|
| Jumbo frames |
16 |
| MAC address table |
4000 entries |
| Switching capacity |
16 Gbit/s |
| Store-and-forward |
Yes |
| Jumbo frames support |
Yes |
| Forwarding rate |
11.904 Mpps |
| Security |
|---|
| IGMP snooping |
Yes |
| Design |
|---|
| Reset button |
Yes |
| Product colour |
Black |
| Housing material |
Steel |
| Performance |
|---|
| Fanless |
Yes |
| Auto-negotiation |
Yes |
| Power |
|---|
| Power consumption (max) |
75.75 W |
| Power supply included |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Input voltage |
53.5 V |
| Power source |
AC/DC |
| Power connector |
DC-in jack |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port |
30 W |
| Total Power over Ethernet (PoE) budget |
65 W |
| Power over Ethernet (PoE) ports quantity |
8 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Heat dissipation |
258.46 BTU/h |
| Weight & dimensions |
|---|
| Width |
6.22" (158 mm) |
| Depth |
3.98" (101 mm) |
| Height |
0.984" (25 mm) |
| Packaging content |
|---|
| User guide |
Yes |
| Cables included |
Power |
| Rubber feet |
Yes |
| Packaging data |
|---|
| Rubber feet |
Yes |
| User guide |
Yes |
| Cables included |
Power |
| Technical details |
|---|
| Product colour |
Black |
| Housing material |
Steel |
| Compliance certificates |
CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), RoHS, UKCA |
| Certificates |
|---|
| Compliance certificates |
CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), RoHS, UKCA |
| Other features |
|---|
| Input voltage |
53.5 V |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
