ProArt Display PA32UCXR Professional Monitor – 32-inch, 4K UHD (3840 x 2160), 2,304 zones Mini LED Backlight, Built-in Motorized Colorimeter, Self / Auto Calibration, HDR-10, HLG, Dolby Vision, 99% Adobe RGB, 97% DCI-P3, ΔE < 1, Thunderbolt 4 PD 90W, VESA DisplayHDR 1400, Hardware Calibration, Calman Ready, ColourSpace Integration, Ergonomic Stand, Green Sustainability
Key Features
- 32-inch mini LED backlight panel with 2304-zone local dimming for a 1,000,000:1 contrast ratio, with 1600 nits peak brightness and 1000 nits of sustained full-screen brightness
- True 10-bit color depth and Quantum Dot technology provide 100% sRGB, 99% Adobe RGB, 97% DCI-P3 and Rec. 2020 color gamut, along with industry-leading Delta E < 1 color accuracy
- Built-in colorimeter supports Self / Auto calibration, as well as Calman and Light Illusion ColourSpace CMS professional calibration software
- Multiple HDR format support, including Dolby Vision®, HLG and HDR10
- Rich connectivity including dual Thunderbolt™ 4 up to 90W Power Delivery, HDMI®, DisplayPort™, and a built-in USB Hub
- Recyclable paper packaging, plus energy-efficient performance that meets environmental standards
Description
ProArt Display PA32UCXR
1600 Nits Mini-LED Monitor with Built-in Colorimeter for Ultimate RealismASUS ProArt Display PA32UCXR features mini-LED backlighting with 2304-zone local dimming, 1600 nits peak brightness, and up to 1000 nits sustained brightness without partial patch limitation. It boasts an industry-leading Delta E < 1 color difference, and features a built-in motorized flip colorimeter to ensure professional-grade color accuracy. Two Thunderbolt™ 4 ports and a host of other connectivity options enable seamless and efficient creative workflows, making this monitor ideal for content creators.
Specifications
| Display |
|---|
| HDCP |
Yes |
| Display brightness (typical) |
1000 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
1.073 billion colors |
| Native aspect ratio |
16:9 |
| Colour gamut |
97% |
| Maximum refresh rate |
60 Hz |
| sRGB coverage (typical) |
100% |
| HD type |
4K Ultra HD |
| Display technology |
LCD |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.00726 x 0.00726" (0.184 x 0.184 mm) |
| Viewable size, horizontal |
27.9" (70.8 cm) |
| Viewable size, vertical |
15.7" (39.9 cm) |
| Digital horizontal frequency |
135 - 135 kHz |
| Digital vertical frequency |
40 - 60 Hz |
| Backlight type |
Mini LED |
| Display resolution |
3840 x 2160 pixels |
| Response time |
5 ms |
| Display diagonal |
32" |
| Display brightness (peak) |
1600 cd/m² |
| Touchscreen |
No |
| High Dynamic Range (HDR) supported |
Yes |
| Panel type |
IPS |
| High Dynamic Range (HDR) technology |
DisplayHDR 1400, Dolby Vision, High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG) |
| Hardware calibration |
Yes |
| Colour gamut standard |
DCI-P3 |
| Anti-glare screen |
Yes |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
6 W |
| Performance |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
6 W |
| Built-in camera |
No |
| VESA Adaptive Sync support |
Yes |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Multimedia |
|---|
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| RMS rated power |
6 W |
| Built-in camera |
No |
| Design |
|---|
| Feet colour |
Black |
| Product colour |
Black |
| Camera |
|---|
| Built-in camera |
No |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 2 (3.1 Gen 2) |
| USB Type-A downstream ports quantity |
3 |
| USB Type-C downstream ports quantity |
1 |
| Headphone out |
Yes |
| HDMI ports quantity |
2 |
| DisplayPorts quantity |
1 |
| HDCP |
Yes |
| Headphone outputs |
1 |
| HDMI |
Yes |
| HDMI version |
2.0 |
| DisplayPort version |
1.4 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
90 W |
| Thunderbolt 4 ports quantity |
2 |
| HDCP version |
2.2 |
| Technical details |
|---|
| Height (without stand) |
17.5" (445 mm) |
| Depth (without stand) |
3.54" (90 mm) |
| Width (without stand) |
28.6" (727 mm) |
| Feet colour |
Black |
| Cable lock slot |
Yes |
| HDMI |
Yes |
| Product colour |
Black |
| Weight (with stand) |
30.4 lbs (13.8 kg) |
| Touchscreen |
No |
| Ergonomics |
|---|
| Wall mountable |
Yes |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Swivelling |
Yes |
| Swivel angle range |
-30 - 30° |
| Tilt angle range |
-5 - 23° |
| Pivot |
Yes |
| Pivot angle |
-90 - 90° |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
3.94" (10 cm) |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (typical) |
46.62 W |
| Power consumption (off) |
0 W |
| Power consumption (PowerSave) |
0.5 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
G |
| Energy consumption (SDR) per 1000 hours |
41 kWh |
| Energy consumption (HDR) per 1000 hours |
63 kWh |
| European Product Registry for Energy Labelling (EPREL) code |
1692522 |
| Weight & dimensions |
|---|
| Height (without stand) |
17.5" (445 mm) |
| Depth (without stand) |
3.54" (90 mm) |
| Width (without stand) |
28.6" (727 mm) |
| Width (with stand) |
28.6" (727 mm) |
| Depth (with stand) |
9.65" (245 mm) |
| Height (with stand) |
23.7" (601 mm) |
| Weight (with stand) |
30.4 lbs (13.8 kg) |
| Weight (without stand) |
20.3 lbs (9.2 kg) |
| Package width |
38" (965 mm) |
| Package depth |
8.98" (228 mm) |
| Package height |
21.9" (555 mm) |
| Package weight |
45.2 lbs (20.5 kg) |
| Packaging data |
|---|
| Package width |
38" (965 mm) |
| Package depth |
8.98" (228 mm) |
| Package height |
21.9" (555 mm) |
| Package weight |
45.2 lbs (20.5 kg) |
| Package type |
Box |
| Sustainability |
|---|
| European Product Registry for Energy Labelling (EPREL) code |
1692522 |
| Other features |
|---|
| Hardware calibration |
Yes |
| Height (without stand) |
17.5" (445 mm) |
| Depth (without stand) |
3.54" (90 mm) |
| Width (without stand) |
28.6" (727 mm) |
| HDMI |
Yes |
| USB Power Delivery up to |
90 W |
| Energy efficiency scale |
A to G |
| Display brightness (peak) |
1600 cd/m² |
| Touchscreen |
No |
| USB Power Delivery (USB PD) |
Yes |
| Package type |
Box |
