GbE RJ-45 ports, 56 Gbps, 100-240 V, 30 W, 120 W PoE
Key Features
- (6) GbE PoE+ ports
- (2) GbE PoE++ ports
- (2) 10G SFP+ ports
- 120W total PoE availability
Description
An 8-port, Layer 3 switch with PoE+ and PoE++ output.
Specifications
| Management features |
| Switch type |
Managed |
| Switch layer |
L2/L3 |
| Ports & interfaces |
| SFP+ module slots quantity |
2 |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Copper ethernet cabling technology |
10BASE-T, 10BASE-TX, 100BASE-FX, 100BASE-TX |
| Network |
| Auto-sensing |
Yes |
| Copper ethernet cabling technology |
10BASE-T, 10BASE-TX, 100BASE-FX, 100BASE-TX |
| Networking standards |
IEEE 802.3af, IEEE 802.3at |
| Full duplex |
Yes |
| VLAN support |
Yes |
| Spanning tree protocol |
Yes |
| Port mirroring |
Yes |
| Link aggregation |
Yes |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| 10G support |
Yes |
| Half duplex |
Yes |
| Data transmission |
| Switching capacity |
56 Gbit/s |
| Jumbo frames support |
Yes |
| Static route |
Yes |
| Throughput |
28 Gbit/s |
| Security |
| Authentication |
Port-based authentication |
| Authentication type |
IEEE 802.1x, RADIUS |
| DHCP features |
DHCP server |
| Design |
| Form factor |
1U |
| Product colour |
White |
| LED indicators |
Activity, Link, PoE, Speed, System |
| Housing material |
Metal, Plastic |
| Certification |
CE, FCC, IC |
| Power |
| Power supply included |
Yes |
| AC input voltage |
100 - 240 V |
| Number of power supply units |
1 |
| Input current |
2 A |
| Power source |
AC/DC |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) power per port |
60 W |
| Power over Ethernet plus (PoE+) ports quantity |
6 |
| Total Power over Ethernet (PoE) budget |
120 W |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet 4PPoE (PoE++) ports quantity |
2 |
| Operational conditions |
| Operating temperature (T-T) |
-5 - 45 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Virtual LAN features |
| VLAN support |
Yes |
| Weight & dimensions |
| Width |
7.87" (200 mm) |
| Depth |
9.76" (248 mm) |
| Height |
1.73" (44 mm) |
| Weight |
4.63 lbs (2.1 kg) |
| Packaging content |
| Manual |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
| Technical details |
| Form factor |
1U |
| Product colour |
White |
| Housing material |
Metal, Plastic |
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC) |
| Certificates |
| Certification |
CE, FCC, IC |
| Compliance certificates |
CE, Federal Communications Commission (FCC) |
| Indication |
| LED indicators |
Activity, Link, PoE, Speed, System |
| Packaging data |
| Manual |
Yes |
