StarTech.com 6ft (2m) DisplayPort to HDMI Adapter Cable, 8K 60Hz, 4K 144Hz, HDR10, DP 1.4 to HDMI 2.1 Active Video Converter, DisplayPort Desktop to HDMI Monitor, M/M - DisplayPort to HDMI Cord
Key Features
- HIGH PERFORMANCE: 6.6ft (2m) DisplayPort to HDMI Adapter Cable connects a DisplayPort-enabled desktop to an 8K 60Hz/4K 144Hz HDMI Display; Intel 11th Gen Processor & later or a dedicated graphics card with DP 1.4 & DSC is required for maximum performance
- NO DRIVERS OR SOFTWARE: Universal Adapter Cable is compatible with all hardware platforms and any operating system; Utilize integrated or dedicated GPU (Intel/AMD/Nvidia) capabilities enabling high performance graphics with minimal CPU usage
- HOST COMPATIBILITY: DisplayPort to HDMI Cable works with desktops from Dell, HP, Lenovo, and more; Backward compatible with 4K 60Hz and DP 1.2; Apple M1/M2 devices will not achieve 8K 60Hz, unless a dedicated graphics card with DP 1.4 & DSC is installed
- BUILD QUALITY & DESIGN: Integrated video adapter and cable minimizes failure points and signal loss; Built with adaptive receiver equalization to optimize input signal & amplify output signal ensuring display compatibility; Cage shielding prevents EMI
- TECHNICAL SPECIFICATIONS: 6.6ft (2m) DP 1.4 to HDMI Converter Cable is HDMI 2.1 FRL compliant, supporting HDR10, HDCP 1.x/2.2/2.3 and DSC 1.1/1.2a; Unidirectional cable: DP to HDMI; 7.1ch HDMI audio with Dolby Atmos and DTS:X; Outside Cable Diameter: 6mm
Description
Connect an 8K 60Hz or a 4K 144Hz HDMI display to a DisplayPort-enabled desktop at a distance of up to 6.6ft (2m), using this DisplayPort to HDMI Adapter Cable.
High-Resolution HDR Video
This DP to HDMI Cable enables resolutions of up to 8K 60Hz and is HDMI 2.1 FRL complaint. It supports HDR10, HDCP 1.x/2.2/2.3, and DSC 1.1/1.2a. The adapter cable supports 7.1 channel audio with Dolby Atmos and DTS:X.
*DSC support required to reach maximum resolution capabilities on Intel 11th Gen or later
Universal Compatibility
The DisplayPort to HDMI Converter Cable is compatible with desktops from various brands such as Dell, HP, Lenovo, and more. It works with all hardware platforms and any operating system. The DP to HDMI Cable requires no drivers or software and works with dedicated graphics card from Nvidia and AMD.
Thoughtfully Designed
Combining a video adapter and cable minimizes potential points of failure and signal loss. Adaptive receiver equalization optimizes the input signal and amplifies the output signal to ensure compatibility with high-resolution monitors. The cable is equipped with cage shielding to prevent Electromagnetic Interference (EMI).
Specifications
| Features |
|---|
| Converter type |
Active video converter |
| Chipset |
VMM7100 |
| HDMI version |
2.1 |
| DisplayPort version |
1.4 |
| Product colour |
Black, Silver |
| Cable length |
78.7" (2 m) |
| Connector 1 |
DisplayPort |
| Connector 2 |
HDMI |
| Connector 1 gender |
Male |
| Connector 2 gender |
Male |
| Connector contacts plating |
Nickel |
| Jacket material |
Polyvinyl chloride (PVC) |
| Maximum resolution |
7680 x 4320 pixels |
| Supported graphics resolutions |
1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160, 5120 x 1440, 7680 x 4320 |
| HDCP |
Yes |
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Maximum refresh rate |
144 Hz |
| HDCP version |
1.4/2.2/2.3 |
| High Dynamic Range (HDR) supported |
Yes |
| Supported audio channels |
7.1 |
| High Dynamic Range (HDR) technology |
High Dynamic Range 10 (HDR10) |
| Dolby technologies |
DTS:X, Dolby Atmos |
| Cable type |
Round cable |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
0 - 75 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Technical details |
|---|
| Sustainability compliance |
Yes |
| Compliance certificates |
RoHS |
| Other features |
|---|
| Width |
0.827" (21 mm) |
| Height |
0.433" (11 mm) |
| Weight & dimensions |
|---|
| Width |
0.827" (21 mm) |
| Height |
0.433" (11 mm) |
| Cable diameter |
0.236" (6 mm) |
| Weight |
3.84 oz (109 g) |
| Package width |
7.87" (200 mm) |
| Package depth |
8.66" (220 mm) |
| Packaging data |
|---|
| Package width |
7.87" (200 mm) |
| Package depth |
8.66" (220 mm) |
| Quantity per pack |
1 pc(s) |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Master (outer) case width |
16.3" (415 mm) |
| Master (outer) case length |
17.1" (435 mm) |
| Master (outer) case height |
16.5" (420 mm) |
| Products per master (outer) case |
120 pc(s) |
