Full HD, 4200 ANSI, 3000000:1, 1.07 B, 2, 15W x2, RJ45, HDMI, Audio-out, RS232, USB, 100-240 V, 4.5 kg
Key Features
- 3rd generation laser phosphor technology with up to a 30,000-hour lifespan
- 5,000 ANSI Lumens offering bright images in any environment
- Up to 300" ultra large screen with lower cost-per-inch
- Compact size and light weight reducing cost of transportation and installation
- Installation flexibility: 1.3x optical zoom, H/V keystone, 360° projection, and portrait mode
Description
The LS740W belongs to ViewSonic’s Luminous Superior series, a lamp-free high-brightness projector line up designed for commercial and educational spaces. With its adoption of the 3rd generation laser phosphor technology, it delivers 5,000 ANSI Lumens for up to 30,000 hours, ensuring bright and vivid images without lamp replacement. The lamp-free design offers an eco-friendly and cost-effective solution, while the projector‘s light weight and compact design reduces transportation costs. With up to 300“ projection and high native contrast, it is well-suited for boardrooms, lecture halls, and public spaces. This projector features a 1.3x optical zoom, H/V keystone, 4 corner adjustment, 360° projection, and a portrait mode for easy setup and versatile applications.
Bright, Compact, DurableThe LS740W incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods of use.
Bright Images for Large VenuesDelivering 5,000 ANSI Lumens, the LS740W provides vibrant and clear projection in all lighting conditions for auditoriums, boardrooms, public venues, and other expansive spaces.
Unmatched Contrasts, Enhanced VisibilityThe projector's high native contrast ratio, achieved through its Texas Instruments 0.65" DMD chip, enables deeper blacks and brighter whites. As a result, it delivers more visual depth, clearer images, and enhanced legibility.
Ultra-large Screen with Lower Cost-per-inchThis easy-to-install projector allows for an image size of up to 300”, offering a lower cost-per-inch compared to other types of commercial displays.
Easy and Cost-effective InstallationThe LS740W is 35% lighter in weight and 35% smaller in size compared to its predecessor and even most competing projectors in the market, greatly reducing the cost of transportation and increasing the ease of installation.
Save on Costs and EnergyWith its advanced lamp-free light source, the LS740W offers a highly energy-efficient and cost-saving display solution by consuming up to 51% less power than competing projectors.
Enhanced Installation FlexibilityEquipped with a 1.3x optical zoom, the projector allows users to choose the most ideal set-up location within a range, getting the desired image size without needing to change the existing interior design.
Get Perfectly-shaped Images EffortlesslyHorizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.
Versatile Creative ApplicationsThe projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.
Present the Best with Vibrant ColorsImpress any audience with ViewSonic’s exclusive color technology, elevating your presentation witha true-to-life color experience.
Non-stop 24/7 OperationThe projector's advanced cooling design enables 24/7 operation without any degradation in image quality or performance. This makes it the go-to solution for applications that require continuous projection in retail stores, malls, museums, airports, and other public spaces.
A Simpler Way to Update Projector SoftwareSkip trips to the service center by keeping software up to date easily via USB cable connection with your own laptop.
Directly Power Wireless HDMI DongleThe built-in 5V/1.5A USB-A output conveniently delivers power to a wireless HDMI dongle, eliminating the need for separate power adapters when streaming multimedia content.
Enhanced Dust ResistanceMaintain crystal-clear image quality and product longevity with an advanced IP6X sealed engine design that prevents dust from entering and affecting internal components.
Specifications
| Projector |
|---|
| Number of colours |
1.07 billion colors |
| Projector native resolution |
WXGA (1200x800) |
| Native aspect ratio |
16:9 |
| Screen size compatibility |
40 - 300" |
| Projection distance |
16.9 - 128" (0.43 - 3.25 m) |
| Contrast ratio (typical) |
3000000:1 |
| Vertical scan range |
23 - 120 Hz |
| Horizontal scan range |
15 - 102 kHz |
| Keystone correction, vertical |
-15 - 15° |
| Keystone correction, horizontal |
-15 - 15° |
| Projection technology |
3LCD |
| Projector brightness |
5000 ANSI lumens |
| Smart projector |
No |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Lens system |
|---|
| Fixed focal length |
0.296" (7.51 mm) |
| Zoom capability |
Yes |
| Focus |
Manual |
| Throw ratio |
0.49 |
| Offset |
132% |
| F-number (relative aperture) |
2.8 |
| Digital zoom |
2x |
| Zoom type |
Manual |
| Video |
|---|
| Analog signal format system |
NTSC, PAL, SECAM |
| Full HD |
Yes |
| 3D |
No |
| Supported video modes |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Ports & interfaces |
|---|
| HDMI connector type |
Full-size |
| VGA (D-Sub) ports quantity |
0 |
| HDMI ports quantity |
2 |
| USB 2.0 ports quantity |
1 |
| Composite video in |
0 |
| Audio (L/R) in |
0 |
| Audio (L/R) out |
0 |
| Serial interface type |
RS-232 |
| PC Audio out |
Yes |
| HDMI version |
2.0 |
| DVI port |
No |
| Component video (YPbPr/YCbCr) in |
0 |
| AC (power) in |
Yes |
| Service port type |
USB Type-A |
| USB 2.0 Type-A ports quantity |
1 |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN (RJ-45) ports |
1 |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Interactive |
No |
| HDCP |
Yes |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Danish, German, Hungarian, Arabic, Dutch, Norwegian, English, Indonesian, Swedish, Spanish, Italian, Polish, Thai, Japanese, Portuguese, Turkish, Romanian, Simplified Chinese, Finnish, Korean, Russian, Vietnamese, Traditional Chinese, French, Greek, Czech, Slovak |
| Noise level |
32 dB |
| Noise level (economic mode) |
29 dB |
| Number of OSD languages |
27 |
| HDCP version |
1.4/2.2 |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
30 W |
| Design |
|---|
| Market positioning |
Business |
| Product type |
Standard throw projector |
| Cable lock slot type |
Kensington |
| Product colour |
White |
| Cable lock slot |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power source |
AC |
| Power consumption (typical) |
245 W |
| Power consumption (standby) |
0.5 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Package width |
19.5" (496 mm) |
| Package depth |
7.68" (195 mm) |
| Package height |
15.2" (387 mm) |
| Weight |
9.92 lbs (4.5 kg) |
| Width |
13.3" (337 mm) |
| Depth |
10.4" (265 mm) |
| Height |
5.18" (131.5 mm) |
| Package weight |
14.6 lbs (6.6 kg) |
| Packaging content |
|---|
| Remote control included |
Yes |
| Warranty card |
Yes |
| Quick start guide |
Yes |
| Technical details |
|---|
| Image lag time |
49.9 ms |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Other features |
|---|
| F-number (relative aperture) |
2.8 |
