StarTech.com 2-Port USB-C KVM Switch, Single-4K 60Hz HDMI Monitor, 100W Power Delivery Pass-through for Each Laptop/Tablet, Bus Powered, USB Type-C/USB4/Thunderbolt 3/4 Compatible (C2-H46-UC2-PD-KVM)
Key Features
- DUAL LAPTOP CHARGING: 100W Power Delivery Pass-Through is enabled using dedicated USB-C Power Adapters (not included), with 10W reserved and up to 90W charging available for each host laptop simultaneously using the two PD 3.0 pass-through ports
- 4K 60HZ USB-C KVM SWITCH: Enables fast switching of a keyboard, video, and mouse using a single USB-C cable connected to a laptop that supports USB-C DP Alt Mode; It features a 4K 60Hz HDMI output, two USB HID ports, and pushbutton switching
- COMPATIBILITY: 2-Port KVM Switch works with any operating system including Windows, macOS, Linux, and ChromeOS; Compatible with all hardware platforms such as Intel, AMD, and Apple M1/M2 devices (MacBook); Works with USB-C, USB4, Thunderbolt 3/4 laptops
- READY TO DEPLOY: Compact KVM is bus powered and includes two 3ft/1m USB-C host cables; Small form factor is sturdy and features attached rubber feet, keeping the KVM in place during use; Streamlined Port Layout; LED Indicators for Port and Charging Status
- OUR ADVANTAGE: Included connectivity tools for IT Pro's and IT help-desk support teams with USB Event Monitoring for logging USB device connections with timestamps, and Windows Layout to restore windows locations upon switching hosts
Description
Power/charge and control two USB Type-C laptops over a single 4K 60Hz HDMI monitor, with pushbutton host selection
This USB Type-C KVM Switch enables users to switch between two USB-C laptops, sharing a 4K 60Hz HDMI monitor, keyboard, and mouse, while simultaneously charging each laptop.
100W Power Delivery Pass-through
Dual-100W Power Delivery 3.0 pass-through ports (10W reserved) enable the KVM Switch to charge each laptop at up to 90W, using its own dedicated USB-C power adapter. The dual PD passthrough ports allow for charging each laptop, even when they are not connected to the selected port.
Universal Compatibility
The 2-Port KVM Switch works with any operating system, including Windows, macOS, Linux, and ChromeOS. It is compatible with all hardware platforms, such as Intel, AMD, and Apple M1 and M2 devices (e.g., MacBook Pro). Additionally, it works with DP Alt Mode-enabled USB-C, USB4, Thunderbolt 3, and Thunderbolt 4 laptops and devices.
Ready for Quick Deployment
The KVM Switch is bus-powered and includes two 3ft/1m USB-C host cables, allowing for rapid deployment. The small form factor is sturdy and features attached rubber feet, keeping the KVM securely in place during use. The streamlined port layout ensures easy access to the mouse, keyboard, and host connections, while the PD Passthrough and HDMI output are conveniently out of the way - located on the other side of the unit.
The StarTech.com Advantage
Specifications
| Ports & interfaces |
|---|
| Console USB ports quantity |
4 |
| Console ports |
HDMI, USB A, USB C |
| Number of computers controlled |
2 |
| Keyboard port type |
USB |
| Mouse port type |
USB |
| Video port type |
HDMI |
| Console HDMI ports quantity |
1 |
| Cable length |
39.4" (1 m) |
| Performance |
|---|
| Chipset |
VLI - VL103R, VLI - VL171, Parade - PS186, VLI - VL817 |
| Data transfer rate (max) |
0.48 Gbit/s |
| HD type |
4K Ultra HD |
| Video bandwidth |
75 Hz |
| Plug and Play |
Yes |
| Maximum resolution |
4096 x 2160 pixels |
| Audio channels |
7.1 |
| Technical details |
|---|
| Product colour |
Black |
| Rack mounting |
No |
| Plug and Play |
Yes |
| Push button |
Yes |
| LED indicators |
Power |
| Hot keys |
No |
| IP control |
No |
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, RoHS |
| Design |
|---|
| Mean time between failures (MTBF) |
50000 h |
| Product colour |
Black |
| Cable length |
39.4" (1 m) |
| Rack mounting |
No |
| Push button |
Yes |
| LED indicators |
Power |
| Hot keys |
No |
| Housing material |
Acrylonitrile butadiene styrene (ABS) |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Power consumption (typical) |
10 W |
| USB Power Delivery up to |
100 W |
| USB Power Delivery |
Yes |
| Video |
|---|
| HD type |
4K Ultra HD |
| Video bandwidth |
75 Hz |
| Maximum resolution |
4096 x 2160 pixels |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, RoHS |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 55 °C |
| Storage temperature (T-T) |
-20 - 50 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Weight & dimensions |
|---|
| Width |
2.76" (70 mm) |
| Depth |
5.51" (140 mm) |
| Height |
0.591" (15 mm) |
| Weight |
7.05 oz (200 g) |
| Package width |
4.72" (120 mm) |
| Package depth |
6.77" (172 mm) |
| Package height |
3.35" (85 mm) |
| Package weight |
15.5 oz (440 g) |
| Packaging data |
|---|
| Package width |
4.72" (120 mm) |
| Package depth |
6.77" (172 mm) |
| Package height |
3.35" (85 mm) |
| Package weight |
15.5 oz (440 g) |
| Packaging content |
|---|
| Cables included |
USB Type-C |
| Quick installation guide |
Yes |
| Other features |
|---|
| IP control |
No |
| Push button |
Yes |
| Hot keys |
No |
| Logistics data |
|---|
| Master (outer) case width |
16.1" (410 mm) |
| Master (outer) case length |
18.5" (470 mm) |
| Master (outer) case height |
12.2" (310 mm) |
| Products per master (outer) case |
20 pc(s) |
