68.6cm (27") Full HD 1920 x 1080 TFT, 16:9, 16.7M, 8ms, 178°/178°, 1000:1
Key Features
- 68.6cm (27") Full HD 1920 x 1080 TFT
- 8ms, 16:9, 1000:1
- USB, HDMI, DisplayPort
Description
The bezel just got smaller.The 2770L 27” touchscreen
offers up to a 70% reduction
in the bezel compared to
similar models.
Minimalistic design to fit any space.
From 20 degrees to 70 degrees, angle the display where you want it.
Place it on a desktop, mount it on a wall or configure the 2770L to fit your space with VESA-compatibility.
Built-in speakers and integrated IO.
Durable, energy efficient touchscreen.Scratch-resistant glass surface. IK07 impact resistant.
ES8.0 certified for greater energy efficiency.
Increase viewing comfort with low blue light and flicker free features.
Navigate the OSD directly on the touchscreen.We have made it easier to manage your
On-Screen Display (OSD) controls – Now you
can use the touchscreen or the controls you
are used to on the rear side of the monitor.
Specifications
| Display |
|---|
| HDCP |
Yes |
| Screen shape |
Flat |
| Display number of colours |
16.7 million colors |
| Native aspect ratio |
16:9 |
| Maximum refresh rate |
75 Hz |
| HD type |
Full HD |
| Display technology |
LED |
| Contrast ratio (typical) |
1000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Horizontal scan range |
30 - 82 kHz |
| Vertical scan range |
50 - 75 Hz |
| Supported graphics resolutions |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Display resolution |
1920 x 1080 pixels |
| Response time |
8 ms |
| Display diagonal |
27" |
| Display brightness (peak) |
270 cd/m² |
| Touchscreen type |
Multi-user |
| Touchscreen |
Yes |
| Panel type |
TFT |
| Touch technology |
Multi-touch |
| Touchscreen technology |
Projected capacitive system |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Performance |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Mean time between failures (MTBF) |
50000 h |
| Built-in microphone |
No |
| Built-in camera |
No |
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Management features |
|---|
| On Screen Display (OSD) |
Yes |
| Multimedia |
|---|
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Built-in microphone |
No |
| Built-in camera |
No |
| Design |
|---|
| Certification |
CUL, IC
CCC
CE
UKCA
KCC
BSMI
FCC, UL
VCCI, PSE
CB
RCM
EAC
CoC
RoHS, WEEE, REACH
BIS |
| Product colour |
Black |
| Mean time between failures (MTBF) |
50000 h |
| Camera |
|---|
| Built-in camera |
No |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| Headphone out |
Yes |
| HDMI ports quantity |
2 |
| DisplayPorts quantity |
1 |
| HDCP |
Yes |
| Headphone outputs |
1 |
| HDMI |
Yes |
| HDMI version |
1.4 |
| DisplayPort version |
1.2 |
| USB Touch ports quantity |
1 |
| USB Touch port |
Yes |
| Technical details |
|---|
| Height (without stand) |
1.72" (43.8 mm) |
| Depth (without stand) |
14.7" (372.8 mm) |
| Width (without stand) |
24.7" (626.2 mm) |
| Power consumption (sleep) |
0.5 W |
| Mean time between failures (MTBF) |
50000 h |
| HDMI |
Yes |
| Built-in microphone |
No |
| Product colour |
Black |
| Sustainability certificates |
ENERGY STAR |
| Touchscreen type |
Multi-user |
| Touchscreen |
Yes |
| Ergonomics |
|---|
| Wall mountable |
Yes |
| VESA mounting |
Yes |
| On Screen Display (OSD) |
Yes |
| Height adjustment |
No |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (typical) |
19 W |
| Power consumption (off) |
0.16 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
E |
| Energy consumption (SDR) per 1000 hours |
18 kWh |
| European Product Registry for Energy Labelling (EPREL) code |
1476204 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 95% |
| Weight & dimensions |
|---|
| Height (without stand) |
1.72" (43.8 mm) |
| Depth (without stand) |
14.7" (372.8 mm) |
| Width (without stand) |
24.7" (626.2 mm) |
| Weight (without stand) |
13.9 lbs (6.3 kg) |
| Package width |
27.7" (703 mm) |
| Package depth |
5.35" (136 mm) |
| Package height |
19.3" (489 mm) |
| Package weight |
20.8 lbs (9.45 kg) |
| Packaging data |
|---|
| Package width |
27.7" (703 mm) |
| Package depth |
5.35" (136 mm) |
| Package height |
19.3" (489 mm) |
| Package weight |
20.8 lbs (9.45 kg) |
| Cables included |
AC, HDMI, USB |
| Packaging content |
|---|
| Cables included |
AC, HDMI, USB |
| Sustainability |
|---|
| European Product Registry for Energy Labelling (EPREL) code |
1476204 |
| Sustainability certificates |
ENERGY STAR |
| Other features |
|---|
| Power consumption (sleep) |
0.5 W |
| Mean time between failures (MTBF) |
50000 h |
| Certification |
CUL, IC
CCC
CE
UKCA
KCC
BSMI
FCC, UL
VCCI, PSE
CB
RCM
EAC
CoC
RoHS, WEEE, REACH
BIS |
| Height (without stand) |
1.72" (43.8 mm) |
| Depth (without stand) |
14.7" (372.8 mm) |
| Width (without stand) |
24.7" (626.2 mm) |
| HDMI |
Yes |
| Energy efficiency scale |
A to G |
| Display brightness (peak) |
270 cd/m² |
| Touchscreen type |
Multi-user |
| Touchscreen |
Yes |
| Certificates |
|---|
| Certification |
CUL, IC
CCC
CE
UKCA
KCC
BSMI
FCC, UL
VCCI, PSE
CB
RCM
EAC
CoC
RoHS, WEEE, REACH
BIS |
