98", 4K UHD (3840 x 2160), ADS, 500 nit, 8 ms, Wi-Fi, PIP, PBP, Beacon, Pro:Idiom, SuperSign CMS, webOS 6.0
Key Features
- Brightness : 500 nit (Typ.)
- Resolution : ULTRA HD (3,840 x 2,160)
- Bezel : 17 mm (Even bezel)
- Built-in Speaker (10 W + 10 W)
- Interface : HDMI(3)/ DP/ DVI-D/ USB 2.0/ RS232C/ RJ45/ Audio/ IR
Description
UHD Large Screen Signage Display with LG webOS PlatformSuper High ResolutionDelivering immersive viewing experience by 4 times higher definition picture quality than FHD.
Adequate Brightness LevelThe UM5K series boasts an adequate brightness level of 500 cd/m² for indoor displays, effectively showcasing content and capturing the public’s attention. This makes it an adequate display solution for marketing purposes in various settings, including meeting rooms, airports, retail outlets, and shopping malls.
High-Performance with webOSLG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
Built-in SpeakerContents will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.
Slim DesignBeing slim, a closer installation to the wall is advised. Additionally, this increases the screen’s immersive experience and provides a sophisticated design, improving the installed-space’s décor.
Compatible with AV Control SystemThe UM5K series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.
SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display number of colours |
1.07 billion colors |
| Panel type |
ADS |
| LED backlighting type |
Direct-LED |
| Touchscreen |
No |
| Display technology |
LCD |
| Display diagonal |
110" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Panel life |
50000 h |
| Native aspect ratio |
16:9 |
| Colour depth |
8 bit |
| Native refresh rate |
120 Hz |
| Haze rate |
25% |
| Ports & interfaces |
|---|
| USB connector type |
USB Type-A |
| Remote (IR) input |
1 |
| USB port |
Yes |
| RS-232C |
Yes |
| Wi-Fi |
Yes |
| DisplayPorts quantity |
1 |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
4 |
| DVI port |
Yes |
| DVI-D ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB version |
2.0 |
| USB ports quantity |
1 |
| HDMI input ports quantity |
3 |
| HDMI output ports quantity |
1 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Bezel width (top) |
0.669" (1.7 cm) |
| Bezel width (side) |
0.669" (1.7 cm) |
| Bezel width (bottom) |
0.669" (1.7 cm) |
| Product colour |
Black |
| Panel mounting interface |
1500 x 600 mm |
| VESA mounting |
Yes |
| Performance |
|---|
| Purpose |
Commercial |
| Operating hours (hours/days) |
16/7 |
| Picture-in-Picture |
Yes |
| On Screen Display (OSD) |
Yes |
| HDCP |
Yes |
| Automatic brightness control |
Yes |
| Plug and Play |
Yes |
| HDCP version |
1.4/2.2/2.3 |
| Wi-Fi |
Yes |
| Panel life |
50000 h |
| Power |
|---|
| Power consumption (max) |
570 W |
| Power consumption (typical) |
440 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50-60 Hz |
| Computer system |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Operating system version |
6.0 |
| Weight & dimensions |
|---|
| Display width |
97.4" (2474 mm) |
| Display depth |
3.9" (99 mm) |
| Display height |
55.4" (1408 mm) |
| Display weight |
176.4 lbs (80 kg) |
| Packaging data |
|---|
| Package width |
105.5" (2680 mm) |
| Package depth |
12.6" (320 mm) |
| Package height |
68.1" (1730 mm) |
| Package weight |
242.5 lbs (110 kg) |
| Remote control included |
Yes |
| Packaging content |
|---|
| Remote control included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Technical details |
|---|
| VESA mounting |
Yes |
| USB connector type |
USB Type-A |
| Panel type |
ADS |
| LED backlighting type |
Direct-LED |
| Real Time Clock (RTC) |
Yes |
| Thin Client |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Other features |
|---|
| USB connector type |
USB Type-A |
| Panel type |
ADS |
| Wi-Fi |
Yes |
| Power consumption (PowerSave) |
308 W |
| Power consumption (max) |
570 W |
| Display technology |
LCD |
| Bezel width (top) |
0.669" (1.7 cm) |
| Bezel width (side) |
0.669" (1.7 cm) |
| Bezel width (bottom) |
0.669" (1.7 cm) |
| Audio output |
1 |
| Audio input |
1 |
| Plug and Play |
Yes |
