6MP, 1/1.8” RGB CMOS, 2048MB RAM, 8192MB Flash, SD, WDR, 60 fps, PoE, RJ45
Key Features
- 180°/360° view up to 30 fps
- 6 MP with stereographic lens
- Support for customizable dewarped views
- Digital roll for easy installation
- Support for advanced analytics
Description
6 MP indoor fisheye with deep learningOffering 180°/360° coverage and no blind spots, this fisheye camera supports advanced analytics based on deep learning on the edge. Its ultra-compact size makes it ideal for wherever you need high-quality indoor surveillance.
Great video performanceAXIS M4327-P offers a complete overview with outstanding sharpness, great detail, and no blind spots. This 6 MP camera delivers 360° or 180° panoramic overviews at up to 30 fps. It includes Axis Lightfinder and Axis Forensic WDR for true colors and great details in challenging light or near darkness. With its stereoscopic lens and digital PTZ, you can choose what to see in the view areas and at what zoom level in up to four areas simultaneously. Furthermore, built on ARTPEC-8, the latest Axis system-on-chip (SoC), this panoramic camera enables improved image processing and great image quality.
Deep learning on the edgeThis indoor fisheye camera includes a deep learning processing unit (DLPU) enabling improved processing and storage capabilities. Plus, you can collect and analyze even more data than before — on the edge. Additionally, it delivers valuable metadata, facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Thanks to AXIS Object Analytics, it’s possible to detect and classify moving objects in a scene — all tailored to specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge.
Great look and ease of installation
This discreet, ultra-compact, affordable camera is quick and easy to install. With accessory casings available, it can also be repainted to blend in with any surroundings. It’s delivered factory-focused. And, thanks to digital roll functionality, you can remotely adjust the rotation of the camera overview – no need to do it manually on the camera. Furthermore, Axis Zipstream, with support for H.264 and H.265, significantly reduces bandwidth and storage requirements without compromising image quality.
Specifications
| Performance |
|---|
| Type |
IP security camera |
| Connectivity technology |
Wired |
| Placement supported |
Indoor |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Design |
|---|
| Form factor |
Dome |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Housing material |
Plastic |
| Camera |
|---|
| Minimum illumination |
0.03 lx |
| Camera shutter speed |
1/33500 - 1/5 s |
| Lens viewing angle, horizontal |
182° |
| Lens viewing angle, vertical |
182° |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Optical sensor size |
1/1.8" |
| Lens system |
|---|
| Maximum aperture number |
2.2 |
| Fixed focus |
Yes |
| Lens diameter |
0.0433" (1.1 mm) |
| Night vision |
|---|
| Night vision |
Yes |
| LED type |
IR |
| Video |
|---|
| Noise reduction |
Yes |
| Privacy masking |
Yes |
| Noise reduction technology |
2D noise reduction, 3D noise reduction |
| Video compression formats |
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Maximum resolution |
2160 x 2160 pixels |
| Supported graphics resolutions |
1920 x 1440, 2560 x 1440, 2560 x 1920 |
| Frame rate |
60 fps |
| Video streaming |
Yes |
| Total megapixels |
6 MP |
| Network |
|---|
| Ethernet interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Supported network protocols |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa, HTTP/2, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf), IEEE 802.1X (EAP-TLS), IEEE 802.1AR |
| Storage |
|---|
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory |
2048 MB |
| Flash memory |
8192 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Memory |
|---|
| Internal memory |
2048 MB |
| Flash memory |
8192 MB |
| Technical details |
|---|
| Video compression formats |
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Type |
IP security camera |
| Form factor |
Dome |
| Placement supported |
Indoor |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Security |
|---|
| Security algorithms |
EAP-TLS, HTTPS, TLS |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Material |
|---|
| Housing material |
Plastic |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
5.1 W |
| Power consumption (Power over Ethernet (PoE)) |
3.5 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Height |
2.01" (51 mm) |
| Diameter |
3.98" (10.1 cm) |
| Weight |
10.6 oz (300 g) |
| Packaging content |
|---|
| Number of cameras |
1 |
| Other features |
|---|
| Video compression formats |
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
