| Performance |
|---|
| Number of languages |
19 |
| Languages support |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| PTZ modes |
Digital PTZ |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| PTZ control |
Yes |
| Placement supported |
Indoor |
| Wide Dynamic Range (WDR) |
Yes |
| Certification |
CE, ECE, KC, RCM, UL/cUL, UKCA, VCCI, WEEE |
| Built-in processor |
Yes |
| Design |
|---|
| IK code |
IK10 |
| Form factor |
Dome |
| Product colour |
White |
| Mounting type |
Wall |
| International Protection (IP) code |
IP66, IP67 |
| Housing material |
Aluminum, Polycarbonate (PC) |
| Camera |
|---|
| Minimum illumination |
0.04 lx |
| Tilt angle range |
15 - 90° |
| Pan range |
-30 - 30° |
| Angle of rotation |
175° |
| Camera pan control |
Yes |
| Camera tilt control |
Yes |
| Camera pixel size |
2.8 µm |
| Lens viewing angle, horizontal |
88° |
| Lens viewing angle, vertical |
47° |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Optical sensor size |
1/2.9" |
| Lens system |
|---|
| Maximum aperture number |
2 |
| Zoom capability |
Yes |
| Lens diameter |
0.142" (3.6 mm) |
| Night vision |
|---|
| Night vision |
No |
| Video |
|---|
| Noise reduction |
Yes |
| Privacy masking |
Yes |
| Noise reduction technology |
2D noise reduction, 3D noise reduction |
| Video compression formats |
H.264, H.265, M-JPEG |
| Maximum resolution |
1920 x 1080 pixels |
| Frame rate |
30 fps |
| Video streaming |
Yes |
| Total megapixels |
2 MP |
| Video recording |
Yes |
| Network |
|---|
| Bluetooth |
No |
| Ethernet interface type |
Gigabit Ethernet |
| Networking standards |
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Quality of Service (QoS) support |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Processor |
|---|
| Built-in processor |
Yes |
| Memory |
|---|
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Hard drive |
|---|
| Built-in HDD |
No |
| Technical details |
|---|
| Video compression formats |
H.264, H.265, M-JPEG |
| Type |
IP security camera |
| Form factor |
Dome |
| PTZ control |
Yes |
| Placement supported |
Indoor |
| Product colour |
White |
| Mounting type |
Wall |
| Wide Dynamic Range (WDR) |
Yes |
| Security |
|---|
| Video motion detection |
Yes |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Active tampering alarm |
Yes |
| Password protection |
Yes |
| Pixel counter |
Yes |
| Digest authentication |
Yes |
| Network access storage (NAS) |
Yes |
| Material |
|---|
| Housing material |
Aluminum, Polycarbonate (PC) |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
3.8 W |
| Power consumption (Power over Ethernet (PoE)) |
2.2 W |
| Certificates |
|---|
| International Protection (IP) code |
IP66, IP67 |
| Certification |
CE, ECE, KC, RCM, UL/cUL, UKCA, VCCI, WEEE |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-30 - 55 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 100% |
| Weight & dimensions |
|---|
| Height |
1.97" (50 mm) |
| Diameter |
4.33" (11 cm) |
| Weight |
8.5 oz (241 g) |
| Packaging content |
|---|
| Number of cameras |
1 |
| Manual |
Yes |
| Other features |
|---|
| Video compression formats |
H.264, H.265, M-JPEG |
