1.44 kVA, 1 kW, 110-120V, 50/60Hz, 680J, 225 BTU/h, 45 dB, LCD
Description
DescriptionThis APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1440VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA 5-15R outlets. It has a preinstalled Network Management Card for UPS network-based monitoring and management. It comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
Specifications
| Power |
| Output frequency |
50/60 Hz |
| Output power |
1000 W |
| Input operation voltage (min) |
110 V |
| Input operation voltage (max) |
125 V |
| Output operation voltage (min) |
110 V |
| Output operation voltage (max) |
120 V |
| Surge energy rating |
680 J |
| Output voltage Total Harmonic Distortion (THD) |
5% |
| Output power capacity |
1.44 kVA |
| Input frequency |
50/60 Hz |
| Ports & interfaces |
| Cable length |
94.5" (2.4 m) |
| USB port |
Yes |
| Serial interface |
Yes |
| SmartSlot |
Yes |
| AC outlets quantity |
6 AC outlet(s) |
| AC outlet types |
NEMA 5-15R |
| Power plug |
NEMA 5-15P |
| USB 2.0 ports quantity |
3 |
| Serial ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
| Audible alarm modes |
Alarm when on battery, Low battery alarm |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Automatic Voltage Regulation (AVR) |
Yes |
| Response time |
10 ms |
| LED indicators |
Yes |
| Noise level |
45 dB |
| Audible alarm(s) |
Yes |
| Features |
| Output frequency |
50/60 Hz |
| Audible alarm modes |
Alarm when on battery, Low battery alarm |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Automatic Voltage Regulation (AVR) |
Yes |
| Response time |
10 ms |
| Output power |
1000 W |
| Input operation voltage (min) |
110 V |
| Input operation voltage (max) |
125 V |
| Output operation voltage (min) |
110 V |
| Output operation voltage (max) |
120 V |
| Surge energy rating |
680 J |
| Output voltage Total Harmonic Distortion (THD) |
5% |
| Noise level |
45 dB |
| Audible alarm(s) |
Yes |
| Output power capacity |
1.44 kVA |
| Input frequency |
50/60 Hz |
| Heat dissipation |
225 BTU/h |
| Battery |
| Battery life (max) |
6 year(s) |
| Battery technology |
Lead-Acid |
| Battery recharge time |
3 h |
| Design |
| Rack capacity |
2U |
| Form factor |
Rackmount |
| LED indicators |
Yes |
| Product colour |
Black |
| Cable length |
94.5" (2.4 m) |
| Display type |
LCD |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 118110.2" (0 - 3000 m) |
| Non-operating altitude |
0 - 600000" (0 - 15240 m) |
| Technical details |
| Output frequency |
50/60 Hz |
| Sustainability certificates |
ENERGY STAR |
| Compliance certificates |
cULus |
| Weight & dimensions |
| Package width |
24" (610 mm) |
| Package depth |
23.2" (590 mm) |
| Package height |
9.25" (235 mm) |
| Weight |
58.4 lbs (26.5 kg) |
| Width |
17" (432 mm) |
| Package weight |
71 lbs (32.2 kg) |
| Height |
3.39" (86 mm) |
| Depth |
18.8" (477 mm) |
| Packaging data |
| Quick installation guide |
Yes |
| Cables included |
USB cable |
| Package width |
24" (610 mm) |
| Package depth |
23.2" (590 mm) |
| Package height |
9.25" (235 mm) |
| Package weight |
71 lbs (32.2 kg) |
| Packaging content |
| Quick installation guide |
Yes |
| Cables included |
USB cable |
