Intel Core, 16 GB RAM, Intel UHD Graphics, 300 W, US
Key Features
- AXIS Camera Station client software included; Extensive support and 5-year warranty; Scalable and powerful solution; Supports up to four 4K monitors
Description
Extensively tested and validated with a wide range of Axis products, this powerful workstation can be used either as a client when connected to the server, or as a server when used in combination with AXIS S30 Series. It supports up to four 4K resolution monitors for optimal overview. With a small form factor, it’s ideal wherever space is limited. It comes preloaded with AXIS Camera Station client software. Plus, the integrated AXIS Recorder Toolbox installation wizard ensures quick and easy installation. Furthermore, it includes next business day on-site hardware replacement, 5-year warranty, and one point-of-contact for support.
Specifications
| Processor |
|---|
| Processor manufacturer |
Intel |
| Memory |
|---|
| Internal memory |
16 GB |
| Memory layout (slots x size) |
2 x 8 GB |
| Storage |
|---|
| Storage media |
SSD |
| Optical drive type |
No |
| SSD capacity |
256 GB |
| Number of SSDs installed |
1 |
| Total storage capacity |
256 GB |
| Total SSDs capacity |
256 GB |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel® UHD Graphics |
| On-board GPU manufacturer |
Intel |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ports & interfaces |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
5 |
| USB 2.0 ports quantity |
4 |
| Mini DisplayPorts quantity |
3 |
| Line-in |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
1 |
| DisplayPort version |
1.4a |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| Technical details |
|---|
| Product type |
Workstation |
| Product colour |
Black |
| Chassis type |
SFF |
| Design |
|---|
| Product colour |
Black |
| Chassis type |
SFF |
| Performance |
|---|
| Product type |
Workstation |
| Software |
|---|
| Operating system installed |
Windows 10 IoT Enterprise |
| Power |
|---|
| 80 PLUS certification |
80 PLUS Platinum |
| Power supply input frequency |
50 - 60 Hz |
| Power supply input voltage |
100 - 240 V |
| Power supply |
300 W |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
0 - 45 °C |
| Weight & dimensions |
|---|
| Width |
3.66" (93 mm) |
| Depth |
11.4" (290 mm) |
| Height |
11.5" (293 mm) |
| Weight |
9.92 lbs (4.5 kg) |
| Packaging content |
|---|
| Cables included |
AC, DisplayPort to Mini DisplayPort |
| Display included |
No |
| Other features |
|---|
| On-board graphics card |
Yes |
| Processor manufacturer |
Intel |
