| Motherboard |
|---|
| Processor socket |
BGA 1528 |
| Motherboard chipset |
Intel SoC |
| Processor |
|---|
| Thermal Design Power (TDP) |
15 W |
| Built-in processor |
Yes |
| Processor model |
4205U |
| Processor threads |
2 |
| Processor frequency |
1.8 GHz |
| Processor socket |
BGA 1528 |
| Processor lithography |
14 nm |
| Processor cores |
2 |
| Processor family |
Intel® Celeron® |
| Motherboard chipset |
Intel SoC |
| Processor manufacturer |
Intel |
| Processor codename |
Whiskey Lake |
| CPU configuration (max) |
1 |
| Memory |
|---|
| Memory voltage |
1.2 V |
| Memory slots type |
SO-DIMM |
| Number of memory slots |
2 |
| Memory channels |
Dual-channel |
| Supported memory types |
DDR4-SDRAM |
| Supported memory clock speeds |
2133,2400,2666 MHz |
| Maximum internal memory |
64 GB |
| Non-ECC |
Yes |
| Video |
|---|
| On-board graphics card |
Yes |
| Graphics card family |
Intel |
| Storage |
|---|
| Supported storage drive types |
HDD & SSD |
| Storage drive sizes supported |
2.5" |
| Storage drive interface |
Serial ATA III |
| Number of storage drives supported |
1 |
| Compatible memory cards |
SD, SDHC, SDXC |
| Card reader integrated |
Yes |
| Graphics |
|---|
| On-board graphics card |
Yes |
| Graphics card family |
Intel |
| On-board graphics card model |
Intel® UHD Graphics 620 |
| Audio |
|---|
| Built-in speaker(s) |
No |
| Audio chip |
Realtek ALC662 |
| Network |
|---|
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| LAN controller |
Intel® I211 |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| Ports & interfaces |
|---|
| DisplayPort version |
1.2 |
| Combo headphone/mic port |
Yes |
| DC-in jack |
Yes |
| COM ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| HDMI version |
2.0a |
| DisplayPorts quantity |
1 |
| VGA (D-Sub) ports quantity |
0 |
| USB 2.0 ports quantity |
2 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Expansion slots |
|---|
| PCI Express slots version |
2.0 |
| Number of M.2 (M) slots |
1 |
| PCI Express configurations |
1x4, 2x2, 1x2+2x1, 4x1 |
| Design |
|---|
| VESA mounting |
Yes |
| Product type |
Mini PC barebone |
| Housing material |
Plastic |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| On/off switch |
Yes |
| Panel mounting interface |
75 x 75,100 x 100 mm |
| Safety |
CB, BSMI, ETL |
| LED indicators |
HDD, Power |
| Cooling type |
Active |
| Product colour |
Black |
| Chassis type |
Nettop |
| Certification |
RCM, RED, VCCI |
| Performance |
|---|
| Windows operating systems supported |
Windows 10 |
| Linux operating systems supported |
Yes |
| BIOS type |
AMI |
| Processor socket |
BGA 1528 |
| Motherboard chipset |
Intel SoC |
| BIOS memory size |
8 Mbit |
| Audio chip |
Realtek ALC662 |
| Harmonized System (HS) code |
84733080 |
| Processor special features |
|---|
| Intel TSX-NI |
No |
| Intel® Smart Response Technology |
Yes |
| Intel® Secure Key |
Yes |
| Intel® OS Guard |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® Turbo Boost Technology |
No |
| Intel Trusted Execution Technology |
No |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® My WiFi Technology (Intel® MWT) |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
| Intel Flex Memory Access |
Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel 64 |
Yes |
| Idle States |
Yes |
| Execute Disable Bit |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Embedded options available |
No |
| Intel Virtualization Technology (VT-x) |
Yes |
| Colour |
|---|
| Product colour |
Black |
| Technical details |
|---|
| BIOS type |
AMI |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Embedded options available |
No |
| Panel mounting interface |
75 x 75,100 x 100 mm |
| Quick start guide |
Yes |
| Processor cores |
2 |
| Cooling type |
Active |
| Chassis type |
Nettop |
| BIOS memory size |
8 Mbit |
| Sustainability certificates |
ENERGY STAR, ErP |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Packaging data |
|---|
| Power cord included |
Yes |
| Drivers included |
Yes |
| AC adapter included |
Yes |
| Package weight |
2.65 lbs (1.2 kg) |
| Certificates |
|---|
| Certification |
RCM, RED, VCCI |
| Safety |
CB, BSMI, ETL |
| Indication |
|---|
| LED indicators |
HDD, Power |
| Software |
|---|
| Windows operating systems supported |
Windows 10 |
| Linux operating systems supported |
Yes |
| Management features |
|---|
| On/off switch |
Yes |
| Logistics data |
|---|
| Country of origin |
China |
| Harmonized System (HS) code |
84733080 |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, ErP |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| AC adapter output voltage |
19 V |
| AC adapter output current |
3.42 A |
| Power supply type |
External AC adapter |
| Power supply |
65 W |
| Number of power supply units |
1 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
5.59" (142 mm) |
| Depth |
5.59" (142 mm) |
| Height |
1.65" (42 mm) |
| Package weight |
2.65 lbs (1.2 kg) |
| Weight |
14.1 oz (400 g) |
| Packaging content |
|---|
| Power cord included |
Yes |
| Drivers included |
Yes |
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Other features |
|---|
| Embedded options available |
No |
| Chassis type |
Nettop |
| Country of origin |
China |
