StarTech.com USB-C Triple Monitor Docking Station for MacBook Pro / Air M1 M2 M3 M4 & Windows, Universal 4K HDMI DP Dock, Thunderbolt Compatible, 100W Laptop Charging
Key Features
-
Universal USB-C Dock: High-performance dock works with all major operating systems such as Windows, MacOS, ChromeOS and Ubuntu; Ideal for mixed-device fleets and laptop refresh cycles, simplifying standardization, and user onboarding across departments
-
GPU Agnostic: Bypass GPU limitations for multi-monitor setups, maximize ROI, and future-proof your IT infrastructure with a dock that ensures compatibility across all hardware platforms, including Intel, Apple Silicon, AMD, and Snapdragon X Copilot+ PCs
-
Triple 4K Displays for Expanded Productivity: Connect up to three 4K monitors through a single USB C port; This dock supports two 4K 60Hz monitors via DisplayLink (HDMI 2.0 or DisplayPort 1.2) and a third 4K 30Hz HDMI display through DP 1.2 Alt Mode
-
100W Power Delivery: Docking station includes a fully spec’d power adapter to charge the host laptop while supplying power across all ports; Downstream USB and USB-C ports deliver up to 7.5W (1.5A) for mobile or battery-powered devices
-
The IT Pro's Choice: Our docking stations are rigorously tested in our Innovation Lab to ensure enterprise-grade reliability and cross-platform compatibility; Built to support large-scale deployments, Windows 11 upgrades, and the shift to AI-enabled PCs
Description
Seamlessly standardize across platforms with triple 4K display support
This USB-C Triple 4K Monitor Docking Station enables wide workstation flexibility, featuring compatibility with USB-C, or Thunderbolt 3/Thunderbolt 4 laptops, and supporting multiple combinations of Ultra HD 4K DisplayPort and HDMI monitors.
Enhance Productivity with Triple-4K Video
This triple-4K docking station uses a combination of its integrated DisplayLink® graphics controller and your computer's DP Alt Mode enabled USB-C port to provide three independent 4K displays.
Connect any combination of HDMI and/or DisplayPort monitors to Video Ports 1 and 2 (DisplayLink®); at resolutions up to 4K at 60Hz. Connect an HDMI monitor to Video Port 3 (DP Alt-Mode), at resolutions up to 4K at 30Hz. This high-resolution video performance is ideal for detailed graphics applications, enhancing your productivity by expanding the display capabilities of your laptop.
Full-Featured Docking Station
Connect the docking station to your computer's USB 3.2 Gen 2 (10Gbps) Type-C port to provide a wide range of port connectivity, options and features. The docking station features:
• 2x USB-A and 1x USB-C (USB 3.2 Gen 1 5Gbps) ports for USB peripheral devices.
• 1x USB-A and 1x USB-C (USB 3.2 Gen 2 10Gbps) port that supports BC 1.2 with 7.5W (1.5A) for charging tablets and smartphones.
• 1x Gigabit Ethernet port with WoL (Wake-on-LAN) for a wired Local Area Network (LAN) connection.
• 1x 3.5mm 4-position TRRS Audio Jack for a 3.5mm headset.
100W USB Power Delivery
The USB-C docking station supports 100W USB Power Delivery with the included power adapter. This allows you to charge the connected host device, as well as the devices connected to the BC 1.2 USB charging ports.
For added protection to connected USB devices, the BC 1.2 enabled USB charging ports feature Overcurrent Protection (OCP). OCP prevents USB peripherals from drawing more power than is safely allocated for the port.
Easy Deployment
Connect the dock to your host computer, using the included 3.3ft (1m) USB-C cable. The docking station supports all major operating systems, including Windows, macOS, ChromeOS, and Ubuntu. This dock was designed for seamless integration with any compatible USB-C equipped device within your organization, including Lenovo X1/Thinkpad P Series, Dell Latitudes/Precision/XPS 15, HP Envy, Surface Laptop 3, and M1 Pro/Max/M2 MacBooks. The dock features a side-facing K-Slot for added security in shared workspaces (e.g., BYOD hoteling/hot-desking).
Enhance Productivity and Device Management with the StarTech.com Connectivity Tools Application
Developed to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:
•
Advanced Windows Layout Utility : Setup and save custom windows layouts.
•
Mac Address Pass-Through Utility : Improve network security.
•
USB Event Monitoring Utility : Track and log connected USB devices.
•
Wi-Fi Auto Switch Utility : Enable users to quickly access faster network speeds via wired LAN.
For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-Tools
This product is backed for 3-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.
Specifications
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Host interface |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
3 |
| HDMI version |
2.0 |
| DisplayPorts quantity |
2 |
| Headphone outputs |
1 |
| DC-in jack |
Yes |
| Connectivity technology |
Wired |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery revision |
3.0 |
| USB Power Delivery up to |
100 W |
| DisplayPort version |
1.4 |
| Network |
|---|
| Networking standards |
IEEE 802.3ab |
| Wake-on-LAN ready |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Performance |
|---|
| Maximum digital resolution |
4096 x 2160 pixels |
| Product colour |
Gray |
| Card reader integrated |
No |
| Cable lock slot |
Yes |
| LED indicators |
Power |
| Data transfer rate |
10 Gbit/s |
| Cable lock slot type |
Kensington |
| HD type |
4K Ultra HD |
| Maximum refresh rate |
60 Hz |
| Technical details |
|---|
| Product colour |
Gray |
| Cable lock slot |
Yes |
| Data transfer rate |
10 Gbit/s |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
11" (280 mm) |
| Master (outer) case length |
16.9" (430 mm) |
| Master (outer) case height |
11.4" (290 mm) |
| Storage |
|---|
| Card reader integrated |
No |
| Power |
|---|
| Power source type |
DC |
| Input current |
2.5 A |
| Power plug type |
Type M |
| AC input voltage |
100 - 240 V |
| Power consumption (typical) |
15 W |
| Output voltage |
24 V |
| Output current |
5.41 A |
| Software |
|---|
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Linux operating systems supported |
Yes |
| Other operating systems supported |
ChromeOS |
| Mobile operating systems supported |
Android, iPadOS |
| Indication |
|---|
| LED indicators |
Power |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-10 - 55 °C |
| Operating relative humidity (H-H) |
0 - 85% |
| Weight & dimensions |
|---|
| Weight |
12 oz (339 g) |
| Width |
3.35" (85 mm) |
| Depth |
7.48" (190 mm) |
| Height |
1.18" (30 mm) |
| Package weight |
2.65 lbs (1.2 kg) |
| Package width |
8.07" (205 mm) |
| Package depth |
9.84" (250 mm) |
| Package height |
1.97" (50 mm) |
| Design |
|---|
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Product colour |
Gray |
| Cable lock slot |
Yes |
| LED indicators |
Power |
| Cable lock slot type |
Kensington |
| Packaging data |
|---|
| Package weight |
2.65 lbs (1.2 kg) |
| Package width |
8.07" (205 mm) |
| Package depth |
9.84" (250 mm) |
| Package height |
1.97" (50 mm) |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
USB Type-C |
| AC adapter included |
Yes |
| Logistics data |
|---|
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
11" (280 mm) |
| Master (outer) case length |
16.9" (430 mm) |
| Master (outer) case height |
11.4" (290 mm) |
| Other features |
|---|
| Chipset |
DisplayLink - DL-6950-N, VIA - VL817CO, Parade - PS176C0 |
